Eden 97063-EDAMZ Manuale utente

97063-EDAMZ

Place your multi-adjustable sprinklers

throughout your garden to get water right

where you want it. Once the system is in

place, use a programmable water timer to set

a watering schedule and let your system do

all the work. The system is completely

modular and can grow with your needs.

FLEX-DESIGN SPRINKLER SET

Attach the garden hose

to the Hose Connector

Connect the hose

to your faucet or

water timer

Place the sprinklers in the

area you want to water

Space sprinklers 3 - 13 ft. (1 - 4m) apart for best

coverage. Each sprinkler waters up to 32 ft.

diameter (10m)

Cut the hose to match the

distance between sprinklers

Attach the hoses to the

sprinkler by unscrewing the

side hose connector

Insert the hose into the

side hose connection then

tighten the connector

Apply STOP End Cap

at the end of circuit

Connect the Sprinklers:

Get Started:

Best Distance 3-13ft (1-4m)

STOP End Cap

Hose Connector

T-Connector

5” extensions to water over taller plants

Convenient STOP end cap

Adjustable spray angle and direction

Hose connector for

unit-to-unit connections

Flow control and shut o at each sprinkler

Sturdy spikes can be easily

placed into the soil

1/2" 50 ft. garden hose

Turn the Water On!

97063EDAMZ

Adjust the Spray:

Adjustable Spray

Direction

360˚

Adjustable Spray

Width

1-360˚ waters up to

Flow Control to adjust the spray

distance

32ft.(10m)

If your faucet is in the middle of your watering area, use the T-Connector to split the water ow into two directions.

T-Connector Set Up:

Best distance

3 ~ 13ft

(1~4m)

Best distance

3 ~ 13ft

(1~4m)

Best distance

3 ~ 13ft

(1~4m)

Best distance

3 ~ 13ft

(1~4m)

Best distance

3 ~ 13ft

(1~4m)

Best distance

3 ~ 13ft

(1~4m)

Best distance

3 ~ 13ft

(1~4m)

SETUP METHOD-1 SETUP METHOD-2

Add Height:

Add the 5” extensions where needed to water over taller plants.

Stack multiple extensions together to further increase the

watering height (up to 2 max).

WARNING: This product can expose you to chemicals including styrene,

which is known to the State of California to cause cancer. For more

information go to www.P65Warnings.ca.gov.
