Simply attach the sprinkler head to the top of the base

and connect to your hose

LOCK

WATER

+

94127EDAMZ

Spray Width tabs (2)

control the width

of the watering area

Spray Range tabs (2) control the length of

the watering area

360° rotating head controls spray direction

Filter prevents sediments

and dirt from getting into

sprinkler

Water ow control knob

adjusts the overall watering area

20 clog-resistant spray nozzles for even watering

Aluminum wide “H” shape

platform design for more

stability

Quick Connect Adapter ts all

standard U.S. garden hoses

4-WAY ADJUSTABLE MINI OSCILLATING SPRINKLER

with METAL BASE

Flow-through design

allows for additional units

to be connected in series

394m²

4250sq.ft

Coverage Area

Up To

Attach the sprinkler head to the top of the base. Connect the Product Adapter to the base of the sprinkler. Attach the lockable

Quick Connect to the end of the hose and simply snap in the hose to the sprinkler to begin using.

Simply remove the end-cap and attach another hose to connect an additional sprinkler if needed.

Set-Up with Quick Connect

Assembly

The Quick Connect Adapter (2 pcs) and Hose Connector

with Water Stop (1 pc) simplify your watering experience.

Simply attach the connector at the end of your hose.

Then, connect the adapters to your watering tools.

Interchange various tools in a snap without turning o the

water as the adapter will stop the water ow. No more

kinking or hose twisting as the adapter allows the hose to

swivel 360 degrees.

A

C

A B C D

B

D

Quick and easy connections to 5/8-inch and

1/2-inch garden hoses, sprinklers, nozzles, and/or

any other garden watering tools

-For outdoor use with cold water only

-Do not spray near electrical connections

-When not in use, rinse the tool with water to remove most of the dirt, dry your tool, and store indoors

This product can expose you to chemicals including styrene, which is known to the State of California to cause cancer.

For more information go to www.P65Warnings.ca.gov

UNLOCK

LOCK

UNLOCK LOCK

Secure twist-and-lock

mechanism prevents

accidental disconnection

Sliding tabs control

the width

(up to 59ft. (18m))

Width Control

Push down tabs

control the length

(up to 36.1ft.(11m))

Range Control

Allows adjustment of

overall watering area.

Allow simple incremental angle

adjustments without moving the

sprinkler and hose.

Water Flow Control 360° Rotation Adjustment

 CAUTION 
