Eden 11530-EDAMZ Manuale utente

MULTI-PATTERN SPRINKLER PLUS MISTING SYSTEM

Place the tripod in the area

where you want to water.

Push down on the tripod legs

until the spikes are well

seated in the ground.

(Follow the yellow warning

sign on the tripod to avoid

pinching your thumb)

Step 1

Step 2

Simply attach the sprinkler head to the top of the Tripod

(do not overtighen).

Adjust the range tabs and angle cap to change

the spray coverage(from 5° up to 360°) and

spraying angle to water just where you need.

Spray Coverage and

Distance Adjustment

Depending on your watering needs, you can manually select from the

various pattern settings:

FLAT - The at pattern will provide a at wave of water.

FAN - The fan pattern disperses water in a wide fan sharpe.

MIST - This pattern is useful to cool down a small area.

LARGE - This provides a larger watering spray area.

MULTI - This is a combination of the Flat, Fan and Large patterns.

Spray Pattern Adjustments

FLAT FAN MIST LARGE MULTI

11530-EDAMZ

41.5”

(105cm)

27.5”

(70cm)

Step 3

Use the Quick Connect to easily connect and disconnect the sprinkler from the hose.

Connect the Product Adapter to the base of the sprinkler. Attach the lockable Quick Connect

to the end of the hose, then simply snap in the hose to the sprinkler to begin using.

Quick Connect Starter Set

ts standard garden

hoses and watering tools

Note: If you are not using

the Quick Connect System,

simply connect the sprinkler

directly to the hose.

Move the angle cap to control the distance of your watering area. The higher level will create a higher arc for greater

water coverage. The lower level will reduce the watering area. Convenient indicators help you remember your settings

for next time.

The Quick Connect Adapter (1 pc) and Hose Connector with Water

Stop (1 pc) simplify your watering experience. Simply attach the

connector at the end of your hose. Then, connect the adapters to

your watering tools. Interchange various tools in a snap without

turning o the water as the adapter will stop the water ow. No

more kinking or hose twisting as the adapter allows the hose to

swivel 360 degrees.

Level Adjustment Indicator

HIGHER LEVEL (1-3):

Adjust the spray upwards for

maximum distance.

LOWER LEVEL (3-1):

Adjust the spray downwards

to reduce the watering area.

LEVEL (0):

Adjust the spray in between a

dispersed and concentrated

watering area.

40 PSI Large Multi Flat Fan

Radius of Spray 39 ft (12 m ) 37 ft (11.5 m) 29 ft (9 m) 27 ft (8.5 m)

Coverage Area

up to

4860 sq ft

(452 m²)

4470 sq ft

(415 m²)

2730 sq ft

(250 m²)

2440 sq ft

(226 m²)

A

C

A B C D

B

D

Quick and easy connections to 5/8-inch and 1/2-inch garden hoses,

sprinklers, nozzles, and/or any other garden watering tools

11530-EDAMZ

WARNING: This product can expose you to

chemicals including styrene which is known to the

State of California to cause cancer. For more

information go to www.P65Warnings.ca.gov.
