Avaya CU-360 Istruzioni per il montaggio

Avaya IX

Collaboration

Unit CU360

QUICK TIPS

avaya.com

Video enable your meeting space

Restricted mode

An advanced settings in the Security section allows

locking the CU360 in “restricted mode”. When the

system is in “restricted mode”, Android features are

locked, and the device acts in “kiosk mode”, as pure

videoconferencing device. The Advanced Settings

are password covered, accessible only to System

Admin.

From the Recent Calls section, use the right arrow

to choose the desired call and then select Add to

Favorites.

Adding Contacts from Recent Calls

P/N B01700514479

are trademarks of Avaya Inc. and are registered in the United

States and other countries. All other trademarks identified by ®,

TM, or SM are registered marks, trademarks, and service marks,

respectively, of Avaya Inc.

01/19 •Quick Tips for Avaya CU360 Collaboration unit.

Android is a trademark of Google LLC.

- Select Record The remaining time available

for recording will be displayed.

You have several choices for controlling the Avaya

CU360:

Using the TV display:

• You can use the remote control.

• You can use an Android™ compatible keyboard /

mouse wired or wireless (not included).

• You can use an Android™ compatible touch-

screen monitor.

Using a Tablet or Smart Phone

• You can use the Avaya Scopia® Control App or

the Avaya Collaboration Control App.

• These applications can be downloaded from

either the Apple App Store or the Google Play

Store.

• Note: The default password is 1234

Using any Internet Browser

See instructions in the Quick Start Guide to connect

to the CU360 IP Address. Default User / Password is

Admin / 1234

• Download and launch the Avaya Equinox Client or

Avaya Conference Client App (available from the

CU360 web interface, App Store or Google Play

Store).

• Right click the icon of Avaya Equinox Client

or Avaya Conference in the system tray and

select Screen Link > Enter a manual location.

• Enter the IP address of the endpoint displayed in

the top left of the CU360 screen.

• Enter the password displayed and your

presentation will start.

• The Present button can be toggled to start and

stop the presentation.

Use “Split and Share”

• Toggle to the “Present” button and select “App”.

• The display will split into two parts. The

dimensions of the two parts can be adjusted.

The remote control provided in the box is a pre-

paired wireless device. If a new remote is used, out

of the box, please follow the pairing procedure

described in the customer letter provided with the

accessory. Once paired, press the power button on

the remote control.

Dial the number and Select the Call Button.

Select Disconnect on the Remote Control.

Accept call by selecting the OK Key or the Call Button.

During a videoconference, press OK on the remote

control or the icon on the ﬂoating bar to access all

available videoconferencing features from the meeting

menu.

- Connect a USB storage device to the USB port on

the CU360 back panel.

- From the meeting menu, select OK, and select

Meeting Options > Recording.

- The meeting will be recorded in MP4 format, up to

720p30 resolution.

Control the Avaya CU360 Before You Begin

Making a Video Call

Ending a Call

Answering a Call

Accessing Videoconferencing Features

Recording a Video Conference

Share Content Change layout

Video mute /

unmute

Increase

volume

Decrease

volume

Control far /

near camera

Start / stop

presentation

Mouse

Call /

Accept Call

Power Button

Zoom in

Back

OK button

Zoom out

Decline Call /

Disconnect

Change PiP

position

Voice activation

Start / Stop

Recording

Home

Audio mute /

unmute

Arrow keys

(Pan Tilt zoomed

camera / navigate)

Delete
