Avenview HDMI-C5-R Manuale utente
HDMI-C5 Series
Part #: HDMI-C5-R
www.avenview.com
2
Description
HDMI-C5-R receiver can receive HDMI signal over Cat5 / 5e / 6 cable from HDMI-C5 Series
Transmitter and Transceivers. The HDMI-C5-R receiver is a cost effective solution for digital
signage, public information display, and large scale demonstration, where crystal-clear, high-
resolution digital video needs to be shown.
Features
HDMI over Cat 5 / 5e / 6 cable.
Video Amplifier Bandwidth: 1.65GHz
Maximum distance between HDMI-C5-SR Transceiver and HDMI-C5-R Receiver (distance
is based on UTP cable skew 30ns/100m):
480p / 720p / 1080i = 30m (100ft)
1080p = 15m (50ft)
Compatible with receiving signal from HDMI-C5-S, HDMI-C5-SR, HDMI-C5-4, HDMI-C5-8
HMDI Input / Output Connector: HDMI digital signal
Compact Size
Connection Diagram of HDMI-C5-Series
www.avenview.com
3
Cable and Accessories
HDMI Cable (not included)
Package Content
HDMI-C5-R
Receiver
HDMI 1 Port Receiver
User Manual
4
Copyright 2007, Avenview® Inc. All rights reserved.
Features, availability and specifications are subject to change without notice.
