Avocent AMX5000 Manuale utente

AMX

MULTI-USER, MULTI-PLATFORM

SWITCHING FOR REAL-TIME

DATA CENTER AND TEST LAB

ENVIRONMENTS

Avocent AMX®switching systems help you efficiently manage

yourITenvironment.They are easy to install, let you leverage

your existing UTP infrastructure and deliver advanced

administrative tools.

ABOUT AMX

UserTier

AMX User Stations

and AMX Switch

Matrix Tier

AMX Switches

ServerTier

AMX Switches

and AMIQ

server interface modules

AMX switching system

matrix configuration can

accommodate up to

128 users and 4,096

target devices.

Based on field-proven technology, the AMX analog matrix

switching systems provide real-time access, high resolution

video, smart cable management and advanced security.

Security features include LDAP authentication and SNMP.

AMX switching systems easily integrate with Microsoft Active

Directory and other LDAP services. You benefit by using the

same username and password that already exists in your nor-

mal network authentication process. Our enhanced SNMP lets

you set up traps in the AMX switch for establishing convenient

report alarms to an external logging destination.

AMX Switches & Appliances - Family Overview

The Avocent®AMX analog matrix switching solution supports

consolidated control of multi-user, multi-rack server environments.

AMX switch solutions provide end-to-end UTP connectivity for

access from the serverto the desk and feature full-system management

with an advanced Java-based administration tool, optimal video

resolution and the patented OSCAR®graphical user interface.

Designed to support diverse applications, the AMX switch is ideal for demo labs,

designer environments and test labs. Leading TV networks, including FOX, ABC and

CNBC, use AMX KVM switching solutions to control access to their machine room

computers and broadcast devices.

smarter SWITCHING SOLUTIONS

“Easy to install,

leverages existing

cabling, has intuitive

GUI, provides excellent

video quality.”

-Network World

AMX BENEFITS in the test lab

There are several AMX switching system features beneficial to the test

lab environment:

Share mode

Any number of AMX system users share access to any one server.

Control of the server’s keyboard and mouse passes from user to user,

as requested, on a time out basis.

Private mode

One tester has sole access to a server.This is critical to the success

of tests that cannot be interrupted by other users.

Scan mode

A tester switches between the videos of a number of selected

servers. The scan is stopped by simply moving the mouse or typing

on the keyboard.

DDC

Each AMX AMIQ module provides Digital Data Channel (DDC) support

for plug and play functionality testing of server video ports.

Hotkey switching

Allows a user to quickly switch between a number of servers without

using an on-screen display. This is particularly useful for testers who

connect to a small number of servers but make frequent switches.

Real-time access and high resolution video are two of the top reasons test labs use

Avocent AMX switching systems.

The AMX switch, which uses standard UTP cabling, is particularly effective in test labs

where multiple users simultaneously access and monitor testing simulation on hundreds of

servers. Access to such servers is critical because testing simulation typically requires a

large amount of hardware, software and integration testing. The AMX switching solution

provides users in multiple locations with real-time access to the test machines either from

offices down the hall or, when used with an Avocent remote IP access device, from outside

the building.

Test labs with large numbers

of users and computers will

benefit from the AMX switching

system matrix configuration. It

can accommodate a maximum

of 128 users and 4,096 servers.

Ideally, your data center servers and other devices are located in a physically secure location. Your KVM solutions

therefore must adapt to existing physical security guidelines. With AMX KVM switches, multiple users share

access to equipment located in a secure server room.

AMX switching systems can also force user station connections. This is a beneficial procedure for controlling

an automated video wall operation, a growing fixture in today’s data centers.

•Your equipment is secured in a server room

•Server access is easily shared by

multiple users

•Auto configuration for simplified installation

•Plug and play installation

•Integrate with video wall software

•Multi-platform support

•Compatible with VT100 serial-based devices

•Low cost per port

•Conserves rack space.

•Full non-blocked access

•Enhanced security with LDAPauthentication

•Convenient user activity/event log

•High resolution video up to 1,000 feet from

the server

•Standard UTP cabling reduces cable bulk

•On-screen graphical user interface

•Centralized management software

•Scalable to grow with your expanding

IT infrastructure

AMX BENEFITS in the data center

AMX KVM analog matrix switching systems offer a variety of compelling reasons

for use in multi-rack, multi-platform and multi-operating system data centers:

The AMX5000, AMX5010, AMX5020 and AMX5030 matrix switches simplify

management in your evolving server installation.They give you access from a

single point or simultaneous access for up to 16 users throughout your data

center. They are solutions with a highly scalable architecture that easily

accommodates additional servers and users.

The AMIQ module is an enhanced UTP server interface that eliminates bulky

cabling connections. It also delivers real-time, high bandwidth video for KVM

switching up to 1,000 feet away from the server. The AMIQ module has built-in

memory that eases configuration by assigning and retaining unique server

identification codes for each attached server. This unique security feature

prevents unauthorized access to a server through cable manipulation.

The AMX switch features the Avocent-patented OSCAR®graphical user

interface, which lets you conveniently switch between connected devices.

The AMWorks®Java-based system administration tool is included free with

each switch for centralized management. It’s a highly functional software that

supports customized user profiles and provides multi-level security. Use

AMWorks software to build a userdatabase and assign access and password

protection for each of your servers.

You can view all activities that take place on AMX KVM switching systems,

including user login, switches made to servers and changes made to system

connections or setup.The database is centrally stored and can be downloaded

to the switch via the network connection port available on all AMX5000,

AMX5010, AMX5020 and AMX5030 switches.

AMX5000 • AMX5010 • AMX5020 • AMX5030 • AMIQ • AMWorks

AMX switches & software

AMWorks Java-based system

administration tool

AMX5010 Switch

AMIQ Module

The AMX5111, AMX5121 and AMX5130 user stations simplify

access.They connect yourusers to the AMXswitching system

and deliver optimal real-time video to their desks.

User stations connect to the user’s PS/2 and USB keyboard

and mouse and send the KVM signals overan industry-standard

UTP cable to the Avocent AMX5000, AMX5010, AMX5020

and AMX5030 analog matrix switches. This UTP connectivity

and analog switching technology provide multi-useraccess and

control to any server in your KVM matrix system.The AMX5130

user station supports serial switching up to 38.4Kbps and lets

the user switch stereo speakers and a microphone.

Userstations automatically compensate for varying cable types

and lengths such as CAT 5, CAT 5e and CAT 6 including

GigaFlex. AMX5121 and AMX5130 user stations offer skew

compensation adjustments between RGB signals each time a

switch is made to a server.

Avocent AMX user stations work with our OSCAR graphical

user interface to provide you with switching support in

share, private and scan modes. The OSCAR interface uses

intuitive menus for point and click system configuration and

server selection.

AMX5111 • AMX5121 • AMX5130

AMX user stations

AMX switching solutions

provide flexibility and

optimal performance

for today’s growing

IT installations,

security-driven

environments and

diverse applications.

AMX5130 user station shown here.

Universal

AC Power

Video port PS2 keyboard and

mouse connections USB keyboard and

mouse connections

Connection to

AMX switch or

local computer

using UTP cabling

Stereo speakers and

mono microphone

connectors (AMX5130

user station only)

Serial port

Corporate Headquarters

4991 Corporate Drive, Huntsville, AL 35805

TEL 866.277.1924 FAX 256.430.4030

wwwwww..aavvoocceenntt..ccoomm

Avocent, the Avocent logo, The Power of Being There, AMX, AMWorks, and

OSCAR are registered trademarks of Avocent Corporation or its affiliates. All

other marks are the property of their respective owners.

0606-AMX-BRO
