Specifications
Mechanical
Height 1.74 in. (4.4 cm)
Width 10.9 in. (27.9 cm)
Depth 11.5 in. (29.2 cm)
Weight 4.41 lbs (2.0 kg)
Environmental
Operating Temperature 32°F to 104°F (0°C to 40°C)
Storage Temperature –4°F to 140°F (–20°C to 60°C)
Power
Operating Voltage 100–240 VAC
Power Frequency 50/60 Hz autosensing
Input Power 25 W max.
Supported Hardware
AMX5111/5121
Computers PS/2, Sun and USB
Monitors VGA, SVGA, XGA, SXGA, up to 1600 x 1200 @ 75 Hz
resolution, VESA 848 x 480, 1360 x768, 1440 x 900,
1680 x 1050
Peripherals PS/2 keyboard and mouse, USB keyboard and mouse,
Microsoft IntelliMouse®
RS-232 Serial Port User station diagnostics, serial force mode
AMX5130
Computers PS/2, Sun and USB with audio and serial
Monitors VGA, SVGA, XGA, SXGA, up to 1600 x 1200 @ 75 Hz
resolution, VESA 848 x 480, 1360 x768, 1440 x 900,
1680 x 1050
Peripherals PS/2 keyboard and mouse, USB keyboard and mouse,
IntelliMouse
Audio 3.5 mm stereo speakers, 3.5 mm mono microphone
RS-232 Serial Port User station diagnostics, serial force mode,
serial devices (38,400 baud max.)
Standards and Warranty
Safety and EMC Approvals and Markings UL, FCC, cUL, CE, VCCI, C-Tick
Warranty Two year
Part Number Model Description
AMX5111-001 AMX5111 user station PS/2 and USB desktop user
station with AMIQ-PS2
module for a local
computer connection
AMX5121-001 AMX 5121 user station PS/2 and USB desktop user
station with automatic
skew compensation and
AMIQ-PS2 module for a
local computer connection
AMX5130-001 AMX 5130 user station PS/2 and USB desktop user
station with automatic
skew compensation, audio,
serial and AMIQDM-PS2
module for a local
computer connection
Features
Multiplatform Support – compatible with PS/2, Sun and USB (including PC, Mac
and Sun USB keyboards) servers; and serial VT100
devices
Sharper Images – video resolution up to 1024 x 768 at 1,000 ft; automatically
adjusts for signal losses each time a switch is made to a server
Cable Flexibility – automatically compensates for varying UTP cable types and
lengths: CAT 5, CAT 5e and CAT 6 including GigaFlex
Graphical Interface – works with patented OSCAR on-screen GUI to assist you
with configuration and server selection
Force and Multivideo Mode – support the Avocent LongView® 1000 extender;
add video-only user stations such as a video wall or
a second video display for dual-display computers
Interface Support – ships with the AMIQDM-PS2 or AMIQ-PS2 server interface
module for convenient connections to a local PS/2-based
server
Serial Force Mode – enables serial devices such as Creston Controller to force
any user station to connect to a specific target
Compatible – with PS/2 and USB keyboard and mouse, including IntelliMouse
Widescreen video support – 16:9 and 16:10 ratios
Additional feature for AMX5121
Skew Adjustment – adjusts for skew between RGB signals each time a switch is
made to a server enabling video resolutions of 1280 x 1024
at 1,000 feet
Additional features for AMX5130
Audio Support – provides switching of stereo speakers and mono microphone
Serial Support – provides switching of serial up to 38.4 Kbps
