CreaBook i540
User Manual
This manual is mainly for Windows 10. There might be some slight
differences if you use other windows systems.
This manual contains the common functions of most models. Maybe it
does not fit very well with your model for some functions, or maybe some
of your model functions are not contained in this manual.
The illustrations in this manual may differ from the actual products. Please
prevail in kind.
Ŷ
Note:
Before using the computer, please read the safety precautions and
important tips carefully and patiently!
Chapter 1 - Know your computer.............................................
Front View.............................................................
Left View...............................................................
Right View............................................................
Bottom View.........................................................
Using the keyboard..............................................
Chapter 2 - Operating Windows10..........................................
Configuring the operating system in initial use.....
Operating System Interface..................................
Start menu............................................................
Keep the computer in sleep mode or shut down..
Tasks view............................................................
Connect to the wireless network..........................
Chapter 3 - Troubleshooting...................................................
Display issues......................................................
Sleep problems....................................................
Voice problems....................................................
Battery problems.................................................
Other problems...................................................
Content
1
1
2
3
4
5
7
7
7
8
9
10
11
12
12
12
13
13
13
EN
When you close the display, please be careful not to leave pens
or any other objects between the display and the keyboard.
Otherwise, the display may be damaged.
Chapter 1 - Know your computer
Front View
Attention:
2
3
1
4
5
1
EN
The LCD display with LED backlight provides
brilliant visual output.
Use the camera for video communication and
taking photos.
Capture sound which can be used for video
conferencing, voice narration or audio
recording.
Press this button to turn on the computer.
The touch pad functions as a conventional
mouse.
One piece multi-touch.
Click Pad: To move the pointer on the screen,
slide your fingertip over the pad in the
direction where you want the pointer to move.
Left-click area: Clicking in this area
corresponds to the functions of clicking the left
button of a conventional mouse.
Right-click area: Clicking in this area
corresponds to the functions of clicking the
right button of a conventional mouse.
1. LCD
2.
3. Built-in Mic
4. Power button
5. Touch pad
2
Build-in
Camera
EN
Left View
Right View
3.Type-C port Connects to Type-C devices (USB 3.1).
Connects to USB devices (USB 3.1).
Indicates the power status
Indicates the battery status
Connects to devices with HDMI input.
Connects to the DC adapter.
1.Security Slot
2.Earphone jack
3.LAN port
4.USB port
5.USB port
6.Micro SD card slot
For connecting the Kensington security
lock.
Connects to earphone
Connects network with RJ45 port
Connects to USB devices (USB 3.1).
Connects to USB devices (USB 2.0).
Accepts micro SD card (not supplied).
ss ss
USB Port:
You can connect a USB device to your computer by inserting its
USB plug (Type-A) into the USB port on your computer.
K
ss
1 2 3 4 5 6
6 5 4 3 2 1
3
1.DC power adapter jack
2.HDMI port
4.USB port
4.Power LED
4.Battery LED
EN
Bottom View
Micro SD Card Slot:
The computer supports the following types of memory cards:
Micro Secure Digital (SD) card
Micro Secure Digital High Capacity (SDHC) card
Micro Secure Digital Extended Capacity (SDXC) card
Note:
You can only insert one memory card each time.
Please insert memory card until into the bottom of the slot.
Gently pull the memory card out of the slot if you want to
remove it.
Before removing the memory card, safely remove hardware
and eject media utility to disable the card to avoid the loss or
error of data
1 1
1.
2.
3.
4.
4
EN
1.Speaker Provide audio output
Keyboard Function:
Scroll Lock
Using the keyboard
Keyboard function keys
Pressing certain function key to enter the corresponding system
settings immediately.
5
Turn the laptop
to sleep Turn on/off flight
mode
Muten
Volume up
Switch display
Number Lock
Turn on/off Touch-
pad
Setting
Volume down
Turn off display
Turn up display
brightness
Turn down display
brightness
Print screen, Take
a screenshot
EN
Function key combinations:
Through the using of the function keys, you can change operational
feature instantly. To use this function, press and hold ; then
press one of the function keys.
The keypad function Combinations:
Through the using of the Keypad keys, you can change operational
features instantly. To use this function, press + ; turn on
the keypad functions，then press one of the function keys. If you
press + again，the keypad function will be turned off.
6
EN
Chapter 2 - Operating Windows10
Configuring the operating system in initial use
You need to configure the operating system the first time you use it.
The configuration process may include the following steps:
1. Accepting the End User License Agreement
2. Configuring the Internet connection
3. Registering the operating system
4. Creating a user account
Operating System Interface
Windows 10 comes with a powerful and useful start menu.
To open the start menu, do one of the followings:
• Press the Windows key on the keyboard
• Select Start on the lower-left corner of the desktop
1. Settings button
2. Power button
3. Start button
4. Search bar
7
EN
NOTE: You can also drag apps from the most used or apps columns to
add them to the start menu.
The power button is on the Start menu, by clicking it, the computer
can be shut down, restarted or changed into sleep mode.
Power Button
Settings Button
8
Select the Start button on the taskbar, open the start menu.
Start Button
Search for anything, anywhere.
Search Bar
Settings let you perform basic tasks. You can also search for more
settings with the settings search bar in the upper-right corner.
To open the settings, do the following: Open the Start menu and
select Settings .
Start menu
You can personalize the start menu with your favorite apps.
To personalize the Start menu, do the following:
Right-click the application which you want to add to the Start menu,
then select Pin to Start menu.
EN
