AXIOMTEK CAPA318 Manuale utente

4 9418E318010E

Version A2 ctober 2018

Printed in Taiwan

Quick Start

CN2

The basic procedures required to power on CAPA318:

(1). Require power at minimum 2.22A. Ensure that power supply is

OFF before connecting to CAPA318 and that all necessary

peripheral devices are plugged properly.

(2). Make sure all of the jumpers and switch are at default settings;

especially SW1 (1-2 close).

(3). Firmly install DDR3L memory module into connector SDIMM1

until fully seated.

(4). Firmly insert power to ATX1.

(5). Install a momentary on/off button/switch onto CN2, pin 5 and 6.

(6). Turn on the power supply.

(7). Press the on/off button/switch to power on CAPA318.

CAPA318 Series Quick Installation Guide

9418E318010E 1

Version A2 ctober 2018

Printed in Taiwan

Checklist



CPU

oard x1



USB cable x1 (optional)



Product information CD



Audio cable x1 (optional)



Quick

nstallation

uide



COM

cable x1

(optional)

Note: Please contact your local vendors if any damaged or missing items. DO

NOT apply power to the board if there is any damaged component.

Connectors

Connector

Description

CN1

USB 2.0 Wafer Port 3 and 4

CN2

Front Panel Connector

CN3 Inverter Connector

CN4

SMBus/

C Con

nector

CN5

LVDS Connector

CN6

SMBus Connector

CN9 SATA Power Connector

CN11

Digital I/O Connector

CN1

COM2

Wafer

Connector

CN13

Audio Connector

CN14

Audio Jack

FAN1

Fan Connector

COM1

COM1 Connector

SATA1 SATA Connector

USB1

USB 3.0 Port

and

VGA1

VGA Connector

ATX1

ATX Power

Connector

LAN1~2

Ethernet Port 1 and 2

SCN1

Full

size PCI

Express Mini Card

and mSATA

Connector

SCN2

Full

size PCI

Express Mini Card Connector

SCN3 SIM Card Slot

SDIMM1

DDR3L

DIMM Connector

CAPA

Intel

Pentium

/Celeron

Processor

3.5

”

Board

2 9418E318010E

Version A2 ctober 2018

Printed in Taiwan

Jumper Settings

Before applying power to the CAPA318, please make sure all of the

jumpers are in factory default positions.

Jumper/Switch

Description Setting

JP1 LVDS +3.3V/+5V/+12V Voltage Selection

Default: +3.3V 1-2 Close

JP2 Restore BIOS Optimal Defaults

Default: Normal Operation 1-2 Close

SW1 Auto Power On

Default: Disable 1-2 Close

Note: Please refer to the CAPA318 series product information CD for the

complete user’s manual, drivers and utilities. User’s manual and related

documents are in Acrobat PDF format.

Board Layout

Top View

9418E318010E 3

Version A1 ctober 2018

Printed in Taiwan

Bottom View

Side View
