AXIOMTEK EBOX630-830 Manuale utente

EBOX630-830

Fanless Embedded System

User’s Manual

Disclaimers

The information in this manual has been carefully checked and is believed to

be accurate. AXIOMTEK Co., Ltd. assumes no responsibility for any

infringements of patents or other rights of third parties, which may result from

its use.

AXIOMTEK assumes no responsibility for any inaccuracies that may be

contained in this document. AXIOMTEK makes no commitment to update or

to keep current the information contained in this manual.

AXIOMTEK reserves the right to make improvements to this document and/or

product at any time and without notice.

No part of this document may be reproduced, stored in a retrieval system, or

transmitted, in any form or by any means, electronic, mechanical,

photocopying, recording, or otherwise, without the prior written permission of

AXIOMTEK Co., Ltd.

January 2008, Version A1

Printed in Taiwan

iii

Safety Precautions

Before getting started, read the following important cautions.

1. The EBOX630-830 does not come equipped with an operating

system. An operating system must be loaded first before

installing any software into the computer.

2. Be sure to ground yourself to prevent static charge when

installing the internal components. Use a grounding wrist strap

and place all electronic components in any static-shielded

devices. Most electronic components are sensitive to static

electrical charge.

3. Disconnect the power cord from the EBOX630-830 before

making any installation. Be sure both the system and the

external devices are turned OFF. Sudden surge of power

could ruin sensitive components. Make sure the

EBOX630-830 is properly grounded.

4. Make sure the voltage of the power source is correct before

connecting the equipment to the power outlet.

5. Turn OFF the system power before cleaning. Clean the

system using a cloth only. Do not spray any liquid cleaner

directly onto the screen.

6. Do not leave this equipment in an uncontrolled environment

where the storage temperature is below -20℃ or above 60℃.

It may damage the equipment.

7. Do not open the system’s back cover. If opening the cover for

maintenance is a must, only a trained technician is allowed to

do so. Integrated circuits on computer boards are sensitive to

static electricity. To avoid damaging chips from electrostatic

discharge, observe the following precautions:

zBefore handling a board or integrated circuit, touch an

unpainted portion of the system unit chassis for a few

seconds. This will help to discharge any static electricity

on your body.

zWhen handling boards and components, wear a

wrist-grounding strap, available from most electronic

component stores.

Classification

1. Degree of production against electric shock: not classified

2. Degree of protection against the ingress of water: IPX0

3. Equipment not suitable for use in the presence of a flammable

anesthetic mixture with air or with oxygen or nitrous oxide.

4. Mode of operation: Continuous

5. Type of protection against electric shock: Class I equipment

General Cleaning Tips

You may need the following precautions before you begin to clean

the computer. When you clean any single part or component for

the computer, please read and understand the details below fully.

1. When you need to clean the device, please rub it with a piece

of dry cloth.

2. Be cautious of the tiny removable components when you use

a vacuum cleaner to absorb the dirt on the floor.

3. Turn the system off before you start to clean up the

component or computer.

4. Never drop the components inside the computer or get circuit

board damp or wet.

5. Be cautious of all kinds of cleaning solvents or chemicals

when you use it for the sake of cleaning. Some individuals

may be allergic to the ingredients.

6. Try not to put any food, drink or cigarette around the

computer.

Cleaning Tools:

Although many companies have created products to help

improve the process of cleaning your computer and

peripherals users can also use household items to clean their

computers and peripherals. Below is a listing of items you may

need or want to use while cleaning your computer or computer

peripherals.

Keep in mind that some components in your computer may

only be able to be cleaned using a product designed for

cleaning that component, if this is the case it will be mentioned

in the cleaning.

zCloth: A piece of cloth is the best tool to use when rubbing

up a component. Although paper towels or tissues can be

used on most hardware as well, we still recommend you to

rub it with a piece of cloth.

zWater or rubbing alcohol: You may moisten a piece of cloth a

bit with some water or rubbing alcohol and rub it on the

computer. Unknown solvents may be harmful to the plastics

parts.

zVacuum cleaner: Absorb the dust, dirt, hair, cigarette

particles, and other particles out of a computer can be one of

the best methods of cleaning a computer. Over time these

items can restrict the airflow in a computer and cause

circuitry to corrode.

zCotton swabs: Cotton swaps moistened with rubbing alcohol

or water are excellent tools for wiping hard to reach areas in

your keyboard, mouse, and other locations.

zFoam swabs: Whenever possible it is better to use lint free

swabs such as foam swabs.

Note:

We strongly recommended that you should shut down the

system before you start to clean any single components.

Please follow the steps below.

1. Close all application programs

2. Close operating software

3. Turn off power switch

4. Remove all device

5. Pull out power cable

vii

Scrap Computer Recycling

If the computer equipments need the maintenance or are beyond

repair, we strongly recommended that you should inform us as

soon as possible for the suitable solution. For the computers that

are no longer useful or no longer work well, please contact us for

recycling and we will make the proper arrangement.

viii

Trademarks Acknowledgments

AXIOMTEK is a trademark of AXIOMTEK Co., Ltd.

IBM, PC/AT, PS/2, VGA are trademarks of International

Business Machines Corporation.

Intel and Pentium are trademarks of Intel Corporation.

MS-DOS, Microsoft C and QuickBASIC are trademarks of

Microsoft Corporation.

VIA is a trademark of VIA Technologies, Inc.

SST is a trademark of Silicon Storage Technology, Inc.

UMC is a trademark of United Microelectronics Corporation.

Other brand names and trademarks are the properties of their

respective owners.

This page does not contain any information.

Table of Contents

Disclaimers...........................................................................ii

Safety Precautions .............................................................iii

Classification......................................................................iv

General Cleaning Tips....................................................... v

Scrap Computer Recycling..............................................vii

C h a p t e r 1 .....................................................................1

Introduction..........................................................................1

1.1 General Description.................................................1

1.2 Specifications ...........................................................2

1.2.1 Main CPU Board........................................................2

1.2.2 I/O System.................................................................2

1.2.3 System Specification................................................3

1.3 Dimensions ...............................................................4

1.4 I/O Outlets .................................................................5

1.5 Package List..............................................................6

C h a p t e r 2 .....................................................................7

Hardware Installation.........................................................7

2.1 HDD Installation........................................................7

2.2 Install Memory Module.............................................12

C h a p t e r 3......................................................................16

BIOS Setting.......................................................................16

3.1 Entering Setup........................................................16

3.2 Control Keys ...........................................................17

3.3 Getting Help ............................................................17

3.4 The Main Menu........................................................18

3.5 Standard CMOS Setup Menu ................................19

3.6 Advanced BIOS Features ......................................24

3.7 Advanced Chipset Features..................................29
