Axis OfficeBasic USB Wireless Manuale utente

AXIS OfficeBasic Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Guide d'installation de l'AXIS OfficeBasic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

AXIS OfficeBasic Installationsanleitung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Guida all'installazione di AXIS OfficeBasic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Guía de instalación de AXIS OfficeBasic. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

AXIS OfficeBasic

Print Server

Contents

AXIS OfficeBasic Installation Guide Page3

AXIS OfficeBasic Installation Guide

Package contents

Overview

To install your Axis print server in

Windows Vista, Windows XP,

Windows 2000 and Windows Server

2003, see the instructions on the

following page. To install on

Macintosh, see page 6.

To perform the installation in

Windows you will need:

• The Axis print server and its

power adapter.

• A printer with either a parallel

port or a USB port.

• AXIS AddPrinter, the free installation tool included on the CD supplied with your Axis print

server (you can also download it from www.axis.com).

• You may also need a printer driver for your printer. Some printer drivers are already included in

Windows, or may be on your Windows installation CD/DVD. Printer drivers can often be found

on the CD supplied with the printer, or they can be downloaded from the manufacturer's Web

site.

Item Notes

Network Print Server AXIS OfficeBasic

Power adapter Model PS-H, country-specific

USB cable 0.7 meter

Adhesive holder and clip Mounting kit

CD Documentation and installation software

Printed Materials • AXIS OfficeBasic Installation Guide (this document)

• Axis Warranty Document

AXIS OfficeBasic

(USB1)

Network connector

Power connector

Test button

Power indicator

Network

indicator

Parallel printer port

(LPT1)

USB printer port

Page 4 AXIS OfficeBasic Installation Guide

Installation in Windows

1. a) Connect the printer to the Axis

print server.

b) Power up the printer.

c) Connect the print server to the

network.

d) Power up the print server.

2. Start AXIS AddPrinter and click

Next.

3. Now identify and select your

network printer from the list shown

in the window. Click Next.

4. If your print server is configured to

use a dynamic IP address you will

now have the opportunity to

change this to a static IP address

(recommended).

If the print server already has a

static IP address, this step will be

skipped. For more information on

network settings you may need to

contact your network administrator.

After the IP address has been

configured, click Next.

Notes:

• Some printers may show in the list as "parallel printer"

or “serial printer”, but this will change when the

printer driver is installed.

• The print server’s serial number can be found on the

label on the product’s casing.

• If the function is supported by your printer, pressing

the print server’s Test button once will print a test

page showing the IP address.

Printer

Axis Print Server

Work station

AXIS OfficeBasic Installation Guide Page5

5. If AXIS AddPrinter does not

automatically find a suitable driver

for your printer, this dialog will be

displayed. If your printer brand

and model is available from this

list, select it and click Next.

If your printer is not listed, click

Have Disk. You can now browse to

the driver file, e.g. on the CD that

came with the printer, or use the

Search Folder feature to let AXIS

AddPrinter find the driver for you.

6. After the printer driver has been

selected and installed, you will see

a summary of the printer

installation. The printer name can

be changed and you can e.g.

choose to print a test page. Click

Finish.

Ready to print

Your printer has now been installed on

the network and is ready for use.

To reset the print server to the factory

default settings, please see page 7.

Notes:

• Printer driver files are often named setup.inf. Alternatively, the file name may include part of the printer name, e.g. mynewprinter.inf

• When inserting the CD provided with your printer into the CD drive, this may start an automatic installation process that will

interfere with the installation via AXIS AddPrinter. Click Cancel to stop the automatic installation and instead let AXIS AddPrinter

find the .inf file.

Page 6 AXIS OfficeBasic Installation Guide

Installation in Mac OS X

This section describes how to set up your Axis print server for printing in Mac OS X 10.2 and

later. For installation on an older Mac OS, refer to the user’s manual on www.axis.com

1. From the Apple menu, select

Go > Applications > Utilities

and start the Print Center.

2. Click Add in the Printer List.

3. From the drop-down list, select

Bonjour.

4. Highlight the printer you wish

to install. The default print

server name is AXISxxxxxx

Network Print Server_<port>,

where xxxxxx represents the

last six digits of the print

server’s serial number.

5. Select the printer brand and

model from the drop-down list.

If the printer’s PPD is already

installed, the brand and model

are selected automatically.

6. To complete the installation,

click Add. The printer is now

added to the Printer List.

Notes:

• The print server’s serial number can be found on

the label on the product casing.

• To configure printer settings, click Printers >

Configure Printer. For more information see the

Axis OfficeBasic User’s Manual.

• If the print server using Bonjour is already

installed, and the print server name or service

name is changed, the print server must be

removed from the Printer List and then

re-installed with the new Bonjour service name.

• If you change the service name from Setup >

TCP/IP > Bonjour > Service Name, this name will

then override the Print Server Name setting as

set in the admin tools in the product’s Web

interface.

AXIS OfficeBasic Installation Guide Page7

Resetting to the Factory Default Settings

This will reset all the product parameters (including the IP address) to the factory default

settings:

1. Disconnect the power adapter cable.

2. Press and hold the Test button and reconnect power, keeping the button pressed the whole

time.

3. Keep the button pressed until the Network indicator remains constantly lit. This should

take about 20 seconds. Then release the button.

4. Restart the print server again, by disconnecting and reconnecting the power adapter.

Guide d'installation de l'AXIS OfficeBasic Page9

Guide d'installation de l'AXIS OfficeBasic

Contenu de l'emballage

Présentation

Pour installer votre serveur

d'impression sous Windows Vista,

Windows XP, Windows 2000 et

Windows Server 2003, reportez-vous

aux instructions de la page suivante.

Pour une installation sur un

Macintosh, reportez-vous page 12.

Pour effectuer une installation sous

Windows, les éléments suivants sont

nécessaires :

• Le serveur d'impression Axis et

son alimentation.

• Une imprimante dotée d'un port parallèle ou d'un port USB.

• AXIS AddPrinter, l'outil d'installation gratuit inclus dans le CD fourni avec votre serveur

d'impression Axis (vous pouvez également le télécharger sur www.axis.com).

• Il est possible que vous ayez également besoin d'un pilote d'installation pour votre imprimante.

Certains pilotes d'imprimante sont inclus dans Windows ou peuvent se trouver sur le CD/DVD

d'installation de Windows. Les pilotes d'imprimante sont généralement inclus sur le CD fourni

avec l'imprimante ou peuvent être téléchargés sur le site Internet du fabricant.

Article Remarques

Serveur d'impression réseau AXIS OfficeBasic

Transformateur - Modèle PS-H, propre à chaque pays

Câble USB 0,7 mètre

Support adhésif et clip Kit de montage

CD Documentation et logiciel d'installation

Documentation imprimée • Guide d'installation de l'AXIS OfficeBasic (le présent document)

• Document de garantie d'Axis

AXIS OfficeBasic

(USB1)

Port USB imprimante

Connecteur de réseau

Connecteur

d'alimentation

Bouton de test

Voyant d'alimentation

Voyant de

réseau

Port parallèle imprimante

(LPT1)

Port USB imprimante

Page 10 Guide d'installation de l'AXIS OfficeBasic

Installation sous

Windows

1. a) Connectez l'imprimante au

serveur d'impression Axis.

b) Allumez l'imprimante.

c) Connectez le serveur

d'impression au réseau.

d) Allumez le serveur d'impression.

2. Lancez AXIS AddPrinter et cliquez

sur Suivant.

3. Identifiez et sélectionnez votre

imprimante réseau dans la liste

affichée dans la fenêtre. Cliquez sur

Suivant.

4. Si votre imprimante réseau est

configurée pour utiliser une adresse

IP dynamique vous pouvez à cette

étape la modifier pour en faire une

adresse IP statique (recommandé).

Si le serveur d'impression est déjà

doté d'une adresse IP statique, cette

étape ne s'affiche pas à l'écran.

Pour de plus amples informations à

propos de vos paramètres réseau,

contactez votre administrateur

réseau.

Une fois l'adresse IP configurée,

cliquez sur Suivant.

Remarques

• Il est possible que certaines imprimantes soient indiquées

dans la liste comme étant des « imprimantes parallèles » ou

des « imprimantes série », mais cela sera modifié une fois le

pilote d'imprimante installé.

• Le numéro de série du serveur d'impression est indiqué sur

l'étiquette du boîtier du produit.

• Si cette fonction est prise en charge par votre imprimante,

une pression sur le bouton Test du serveur d'impression

entraînera l'impression d'une page de test indiquant l'adresse

IP.

Imprimante

Serveur d'impression Axis

Station de travail
