PS™ / BS™/ PSL™ / BSL™

Installation Instructions

IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS

This set of instructions works for:

PS - Path Star™

BS - Bollard Star™

PSL - Louvered Path Star™

BSL - Louvered Bollard Star™

(33mm)

1 5/16"

(76mm)

Specify

Length

BS-LED

S000891

1 3/8"

(35mm)

(4) 3/8" Dia. (10mm)

Bolt Holes

Slip Anchor

(38mm)

2" Dia. (51mm)

O.C.

Slip Conduit Hole

1 1/2"

3 1/2" O.C.

(89mm)

68° Angle = A

90° Angle = B

(127mm)

Anchor Base

RELEASE DATE

5-23-18

Warning Flammable Hot Surface

TECHNOLOGY

with TECHNOLOGY

psl bsl

PSL

BSL

• Product must be installed by a qualified person in a manner

consistent with its intended use and in compliance with the

National Electrical Code, Canadian Electrical Code, and all Local

and Provincial Codes.

• Follow product label information and instructions.

• Qualified Personnel must perform all servicing or relamping of

this product.

• Before wiring to power supply and during servicing or relamping,

turn off power at fuse or circuit breaker before service.

• The use of accessory equipment not recommended by the

manufacturer or installed contrary to instructions may cause an

unsafe condition. The use of damaged components may cause

an unsafe condition and void product warranty.

IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY

AND INSTALLATION INSTRUCTIONS

• Do not block light emanating from product in whole or part,

as this may cause an unsafe condition.

• Never operate the fixture with missing or damaged lens.

Lens must be cleaned on regular basis.

• Entire fixture may become extremely hot. Do not touch hot

lens or fixture body. Do not touch the lamp at any time. Use

a clean, dry, soft cloth to handle the lamp. Oil from skin may

damage the lamp and cause it to rupture.

• Replace lamp only with correct wattage and type of lamp

marked on fixture label.

• All gaskets, o-rings and sealing surfaces must be kept clean

during installation and service; failure to do this may cause an

unsafe condition and void product warranty.

INSTRUCTIONS PERTAINING TO

A RISK OF FIRE, OR INJURY TO

PERSONS IMPORTANT SAFETY

INSTRUCTIONS

Lighted lamp is HOT!

WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:

Turn off/unplug and allow to cool before replacing lamp.

Lamp gets HOT quickly! Contact only switch/plug when

turning on.

Do not touch hot lens, guard, or enclosure (see diagram/

picture).

Keep lamp away from materials that may burn.

Do no touch the lamp at any time. Use a soft cloth. Oil

from skin may damage lamp.

Do not operate the luminaire fitting with a missing or

damaged shield.

SAVE THESE INSTRUCTIONS

· Suitable for wet locations • Suitable for mounting within 4 ft. of the ground.

IMPORTANT LISTINGS AND CERTIFICATIONS

High Voltage

TOOLS

NEEDED:

By Others

1/8” Allen Wrench

Waterproof Wire Connectors

Mounting Hardware

Drill

& Low Voltage

RELEASE DATE

5-23-18

40429 Brickyard Drive • Madera, CA 93636 • USA

559.438.5800 • FAX 559.438.5900

www.bklighting.com • [email protected]

B-K LIGHTING

IMPORTANT SAFETY INFORMATION LISTED ON REVERSE

READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS

Remote Transformer

5. Make watertight connections from remote

transformer to fixture source leads using

waterproof wire connectors (By Others). See

wiring diagram.

4. Pull low voltage wire or pull branch circuit

wires necessary for installation (By Others)

through anchor base.

Anchor base can accommodate up to two (2)

1/2” conduits.

7. Place fixture on anchor base and tighten four

(4) #10-32 stainless steel button head cap

screws using a 1/8” Allen wrench.

120V 12V

Fixture

COM

Remote

Transformer

COM

120V 12V

Fixture

COM

GROUND

Integral

Transformer

COM

GROUND

Integral Transformer

6. Use waterproof wire connectors

(By Others) to make watertight connections

from transformer primary leads to branch circuit

wires. Connect incoming ground to ground wire

provided in fixture body. See wiring diagram.

WIRING DIAGRAM

3.50

1.50

1. Determine suitable anchors (By Others) to

attach anchor base to architectural surface.

2. Place provided template in final mounting

position according to designed lighting plan.

3. Drill holes into surface for maximum 7/16”

fasteners (By Others) on locations illustrated

on template. Base mounting hole locations is

1-1/2” on center by 3-1/2” on center apart.

PROJECT:

TYPE:

(33mm)

1 5/16"

(76mm)

Specify

Length

BS-LED

S000891

1 3/8"

(35mm)

(4) 3/8" Dia. (10mm)

Bolt Holes

Slip Anchor

(38mm)

2" Dia. (51mm)

O.C.

Slip Conduit Hole

1 1/2"

3 1/2" O.C.

(89mm)

68° Angle = A

90° Angle = B

(127mm)

PS™ / BS™/ PSL™ / BSL™

Installation Instructions

REFERENCE NUMBER

INS000733

TECHNOLOGY

with TECHNOLOGY

Anchor Base Installation

TRANSFORMER HOUSING MUST BE INSTALLED ABOVE GRADE.

TRANSFORMER HOUSING INSTALLED BELOW GRADE WILL VOID WARRANTY

& Low Voltage

120V 12V

Fixture

COM

Remote

Transformer

COM

120V 12V

Fixture

COM

GROUND

Integral

Transformer

COM

GROUND

WIRING DIAGRAM

8. Use 1/8” Allen wrench to loosen #10-24 stainless

faceplate screws to remove faceplate. for access

to source.

3 1/2"

1 1/2"

4 X

7/16" Dia.

NOTES: Full Scale Anchor Bolt Template

DRAWING NUMBER

BASE,PS,MACH,ALU

511085

5/15/08

THIS DOCUMENT CONTAINS PROPRIETARY INFORMATION OF B-K LIGHTING AND ITS RECEIPT OR POSSESSION

DOES NOT CONVEY ANY RIGHTS TO REPRODUCE, DISCLOSE ITS CONTENTS, OR TO MANUFACTURE, USE OR

SELL ANYTHING IT MAY DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN

AUTHORIZATION OF B-K LIGHTING IS STRICTLY FORBIDDEN.

WARNING!

Template must print at proper scale.

Verify dimensions prior to use.

REFERENCE NUMBER

INS000733.1

40429 Brickyard Drive • Madera, CA 93636 • USA

559.438.5800 • FAX 559.438.5900

www.bklighting.com • [email protected]

B-K LIGHTING

DESCRIBE. REPRODUCTION, DISCLOSURE OR USE WITHOUT SPECIFIC WRITTEN AUTHORIZATION OF B-K LIGHTING, INC. IS STRICTLY FORBIDDEN.

PS™ / PSL™

Installation Instructions

IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE THESE INSTALLATION INSTRUCTIONS

1 3/8"

35mm

68° Angle = A

S000733

PS-LED

1 3/8"

(35mm)

3/8" Dia. (10mm)

Bolt Holes

(38mm)

Slip Anchor

2" Dia. (51mm)

Slip Conduit Hole

1 1/2" O.C.

3 1/2"O.C.

(89mm)

Optional

Stability

Flange

5 7/8" Dia.

(149mm)

(203mm)

76mm

90° Angle = B

(127mm)

Standard

Base Pipe

Stake

TOOLS

NEEDED:

By Others

1/8” Allen Wrench

Waterproof Wire Connectors

Mounting Hardware

This set of instructions works for:

PS - Path Star™

PSL - Louvered Path Star™

18 Gauge Wire

Anchor Base

on Power PipeTM

Stability Flange

RELEASE DATE

5-23-18

Warning Flammable Hot Surface

TECHNOLOGY

with TECHNOLOGY

• Product must be installed by a qualified person in a manner

consistent with its intended use and in compliance with the

National Electrical Code, Canadian Electrical Code, and all Local

and Provincial Codes.

• Follow product label information and instructions.

• Qualified Personnel must perform all servicing or relamping of

this product.

• Before wiring to power supply and during servicing or relamping,

turn off power at fuse or circuit breaker before service.

• The use of accessory equipment not recommended by the

manufacturer or installed contrary to instructions may cause an

unsafe condition. The use of damaged components may cause

an unsafe condition and void product warranty.

IMPORTANT SAFETY INFORMATION - READ, FOLLOW, AND SAVE ALL SAFETY

AND INSTALLATION INSTRUCTIONS

• Do not block light emanating from product in whole or part,

as this may cause an unsafe condition.

• Never operate the fixture with missing or damaged lens.

Lens must be cleaned on regular basis.

• Entire fixture may become extremely hot. Do not touch hot

lens or fixture body. Do not touch the lamp at any time. Use

a clean, dry, soft cloth to handle the lamp. Oil from skin may

damage the lamp and cause it to rupture.

• Replace lamp only with correct wattage and type of lamp

marked on fixture label.

• All gaskets, o-rings and sealing surfaces must be kept clean

during installation and service; failure to do this may cause an

unsafe condition and void product warranty.

INSTRUCTIONS PERTAINING TO

A RISK OF FIRE, OR INJURY TO

PERSONS IMPORTANT SAFETY

INSTRUCTIONS

Lighted lamp is HOT!

WARNING - To reduce the risk of FIRE OR INJURY TO PERSONS:

Turn off/unplug and allow to cool before replacing lamp.

Lamp gets HOT quickly! Contact only switch/plug when

turning on.

Do not touch hot lens, guard, or enclosure (see diagram/

picture).

Keep lamp away from materials that may burn.

Do no touch the lamp at any time. Use a soft cloth. Oil

from skin may damage lamp.

Do not operate the luminaire fitting with a missing or

damaged shield.

SAVE THESE INSTRUCTIONS

· Suitable for wet locations • Suitable for mounting within 4 ft. of the ground.

IMPORTANT LISTINGS AND CERTIFICATIONS

High Voltage

psl bsl

PSL

& Low Voltage

Proper soil preparation is recommended before installation. See the DIG-IT guide at www.bklighting.com/dig-it for more information.

RELEASE DATE

5-23-18

40429 Brickyard Drive • Madera, CA 93636 • USA

559.438.5800 • FAX 559.438.5900

www.bklighting.com • [email protected]

B-K LIGHTING

IMPORTANT SAFETY INFORMATION LISTED ON REVERSE

READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS

1 3/8"

35mm

68° Angle = A

S000733

PS-LED

1 3/8"

(35mm)

3/8" Dia. (10mm)

Bolt Holes

(38mm)

Slip Anchor

2" Dia. (51mm)

Slip Conduit Hole

1 1/2" O.C.

3 1/2"O.C.

(89mm)

Optional

Stability

Flange

5 7/8" Dia.

(149mm)

(203mm)

76mm

90° Angle = B

(127mm)

Standard

Base Pipe

Stake

PS™ / PSL™

Installation Instructions

REFERENCE NUMBER

INS000733.1

Finished grade Concrete

Finished grade

Finished grade Optional

Stability Flange

Pea gravel

or sand

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade Concrete

Below Ground

Finished grade

Pea gravel

or sand

3. Pull branch circuit wiring necessary for

installation (By Others) to Power Pipe™. Place

Power Pipe™ in hole.

Allow foradditional cable tomake connections

to fixture leads and future service. Do not cut

PVC.

Finished grade Concrete

Finished grade

Finished grade Optional

Stability Flange

Pea gravel

or sand

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade Concrete

Below Ground

Finished grade

Pea gravel

or sand

2. Slide optional Stability Flange onto Power

Pipe™. Use optional Stability Flange to aid in

installation of Power Pipe™.

1. Excavate trench according to designed lighting

plan. Dig hole a minimum of 18” deep and 10”

wide to accommodate Power Pipe™ at desired

fixture locations.

Power Pipe with Anchor Base Mounting Option

Finished grade Concrete

Finished grade

Finished grade Optional

Stability Flange

Pea gravel

or sand

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade Concrete

Below Ground

Finished grade

Pea gravel

or sand

4. Back fill with pea gravel or sand prior to pour.

Finished grade Concrete

Finished grade

Finished grade Optional

Stability Flange

Pea gravel

or sand

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade

Pea gravel

or sand

Pea gravel

or sand

Above Ground

Finished grade Concrete

Below Ground

Finished grade

Pea gravel

or sand

5. Pour concrete (By Others).

Label on Power Pipe™ indicates installation

depth with finished grade.

Remote

Transformer

Remote Transformer

6. Make watertight connections from remote 12V

transformer to LED source leads (18 gauge wire)

using waterproof wire connectors (By Others).

See wiring diagram.

TECHNOLOGY

with TECHNOLOGY

TRANSFORMER HOUSING MUST BE INSTALLED ABOVE GRADE. POWER PIPE™ IS LABELED AT GRADE LEVEL.

TRANSFORMER HOUSING INSTALLED BELOW GRADE WILL VOID WARRANTY

& Low Voltage

Soil Prep

Conduit

trench

B. Dig hole 10” wide and 24” deep.

Conduit

Trench

Excavated

for Housing

C. Prep soil according to DIG-IT Guide.

A. Determine Soil Type by referencing DIG-IT Guide.

Prep soil according to DIG-IT Guide.

1 3/8"

35mm

68° Angle = A

S000733

PS-LED

1 3/8"

(35mm)

3/8" Dia. (10mm)

Bolt Holes

(38mm)

Slip Anchor

2" Dia. (51mm)

Slip Conduit Hole

1 1/2" O.C.

3 1/2"O.C.

(89mm)

Optional

Stability

Flange

5 7/8" Dia.

(149mm)

(203mm)

76mm

90° Angle = B

(127mm)

Standard

Base Pipe

Stake

PS™ / PSL™

Installation Instructions

TECHNOLOGY

with TECHNOLOGY

& Low Voltage

RELEASE DATE

5-23-18

40429 Brickyard Drive • Madera, CA 93636 • USA

559.438.5800 • FAX 559.438.5900

www.bklighting.com • [email protected]

B-K LIGHTING

IMPORTANT SAFETY INFORMATION LISTED ON REVERSE

READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS

REFERENCE NUMBER

INS000733.1

Integral Transformer

7. Pull branch circuit wires necessary for

installation (By Others) through Power Pipe™.

Use waterproof wire connectors (By Others) to

connect transformer primary leads to branch

circuit wires. Connect incoming ground to

ground wire provided in fixture body. See

wiring diagram.

120V 12V

Fixture

COM

Remote

Transformer

COM

120V 12V

Fixture

COM

GROUND

Integral

Transformer

COM

GROUND

WIRING DIAGRAM

8. Place fixture on anchor base and tighten four (4)

#10-32 stainless steel button head cap screws

using a 1/8” Allen wrench.

Integral

Transformer

9. Use 1/8” Allen wrench to loosen #10-24 stainless

faceplate screws to remove faceplate for access

to source.

120V 12V

Fixture

COM

Remote

Transformer

COM

120V 12V

Fixture

COM

GROUND

Integral

Transformer

COM

GROUND

WIRING DIAGRAM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali B-K lighting Luce esterna

B-K lighting

B-K lighting PRECISION2 CO2 Series Manuale utente

B-K lighting

B-K lighting Yukon Bollard Manuale utente

B-K lighting

B-K lighting DENALI ST-DE-TR-A Manuale utente

B-K lighting

B-K lighting ARTISTAR UPLIGHT Manuale utente

B-K lighting

B-K lighting Precision 2 CO2 Series Manuale utente

B-K lighting

B-K lighting HP2 SERIES Manuale utente

B-K lighting

B-K lighting BKSSL MINI-MICRO iLUME Manuale utente

B-K lighting

B-K lighting GARDEN STAR Manuale utente

B-K lighting

B-K lighting Litestick Manuale utente

B-K lighting

B-K lighting ARTISTAR UPLIGHT Manuale utente

B-K lighting

B-K lighting HP2RM Manuale utente

B-K lighting

B-K lighting HP2 SERIES Manuale utente

B-K lighting

B-K lighting Tenaya 2 Series Manuale utente

B-K lighting

B-K lighting CO2 Manuale utente

B-K lighting

B-K lighting PM4RM ROUND CAMLOCK Guida all'installazione

B-K lighting

B-K lighting GARDEN STAR GR-K Manuale utente

B-K lighting

B-K lighting Brick Star Manuale utente

B-K lighting

B-K lighting Well Star WS Series Manuale utente

B-K lighting

B-K lighting EC Guida all'installazione

B-K lighting

B-K lighting HP2 SERIES Manuale utente

B-K lighting

B-K lighting MB2 Manuale utente

B-K lighting

B-K lighting Precision2 HP2 Series Manuale utente

B-K lighting

B-K lighting CK Manuale utente

B-K lighting

B-K lighting ALPINE Series Manuale utente

Manuali Luce esterna popolari di altre marche

Sealey

Sealey LED37 Manuale utente

nordlux

nordlux VEJERS Guida utente

SImx

SImx ELITE LED LHTC637 Manuale utente

GEV

GEV CAROLINE 10833 Manuale utente

NEBO

NEBO NEB-LSP-0020 Manuale utente

WE-EF

WE-EF PFL540 LED Manuale utente

Lindby

Lindby 9949029 Manuale utente

HEPER

HEPER DOGO Side LW6048.585-US Istruzioni per l'installazione e il funzionamento

HEPER

HEPER LW8034.003-US Istruzioni per l'installazione e il funzionamento

Maretti

Maretti VIBE S 14.6080.04.A Manuale utente

BEGA

BEGA 84 253 Manuale

HEPER

HEPER MINIMO Istruzioni per l'installazione e il funzionamento

LIGMAN

LIGMAN BAMBOO 3 Manuale utente

Maretti

Maretti TUBE CUBE WALL 14.4998.04 Manuale utente

Maxim Lighting

Maxim Lighting Carriage House VX 40428WGOB Manuale utente

urban ambiance

urban ambiance UQL1273 Manuale utente

TotalPond

TotalPond 52238 Manuale utente

Donner & Blitzen

Donner & Blitzen 0-02661479-2 Manuale utente
