B&G Mini DB Manuale utente
Before Starting
Operation
Fogging Start/Stop Seq ence
• Gasoline. The only fuel for this fogger is 87 octane gasoline.
Do not mix oil with the fuel. Do not add fuel to the fuel tank
when the engine is running.
• Insecticide ormulation. Formulations used must be mixed
according to product label directions.
• Sa ety equipment. Follow insecticide label directions that
require operator to use personal safety equipment.
• Improper use. Do not leave the fogger unattended when
motor is operating, or when nozzles are operating. Do not
operate the fogger indoors without proper ventilation.
• Public sa ety. People, including children playing, should not
be in a treatment area.
1. Motor switch turned n
2. Move Choke Lever up
3. Press / release the Primer Bulb until gas is visible in the bulb
4. When gas is in the Primer Bulb, press bulb 2 times to
deliver gas to carburetor
5. Pull start cord 1 or 2 times until there is resistance, then
pull quickly to start the engine
6. Move the Choke Lever down when the engine is running
smoothly
• Be certain that oil has been added to the engine. Some
oil may be visible when the cap is removed, but the
bottle o oil supplied with the ogger must be added
be ore starting.
• Turn the flow valve to the ff position (horizontal) before
starting the engine.
• Turn the throttle to the idle position, completely to the right.
• Turn the flow valve to the ff position (horizontal) before
starting the engine.
• Nozzle Adjustment: The flow of formulation to the nozzle
is regulated by a control valve. Before starting the engine,
turn the control valve to the ff position (horizontal).
• Start Fogging: Turn n (vertical position) the control valve
on the formulation line to the nozzle.
• Control valve: When fogging application is complete: 1st
move throttle to idel position; 2nd turn off the engine, 3rd
turn control valve to the ff position.
Starting the Engine
• Fill ormulation tank with insecticide. It is best to start
with a full tank. It will hold 32 ounces.
• Fill uel tank with fresh gasoline.
• Move throttle to idle position (completely to the right).
• Start engine and allow it to run 30 seconds be ore
adjusting the throttle and turning n the control valve to
begin fogging.
• Formulation tank lush. A professional flushing solution
must be used to get complete cleaning. Empty formulation
tank and add about 8 ounces of flushing solution. Fog until
the formulation tank is empty and fogging stops.
Safety Preca tions
39974 Rev 3/17
Mini DB Fogger
INSTRUCTI N MANUAL
B&G Help Line
800-544-8811
135 REGION SOUTH DRIVE • JACKSON, GA 30233
Toll Free 800-544-8811 • Phone 678-688-5601
www. gequip.com • Fax 678-688-5633
Engine Oil
• Every use check the oil level and add oil to fill line.
• 1st month or 10 hours of use - change engine oil.
• Every 6 months or 50 hours of use - change oil.
Spark Plug
• Every year or 100 hours of use - clean, set the gap.
• Every 2 years replace spark plug.
Tro ble Shooting Ro tine Engine
Maintenance
Engine Won’t Start
• Choke should be closed to start the engine.
• Engine switch should be ON.
• Carburetor flooded, allow 5 -10 before restarting; do not
press primer bulb more than 2 times.
• Spark plug may be dirty or with incorrect gap; gap should
be 0.024 - 0.028 inches (0.60 - 0.70 mm).
No Fog Produced
• Nozzles cogged with dirt, obstructing opening.
• Check / replace belt that drives the blower motor.
1
2
3
4
5
6
7
# Description Order #
1 Throttle Control assembly 39959
2 Hose to nozzle (15 inches) RM58212
3 Engine Kill switch ay 39938
4 Control valve, ball (formulation flow) 22273
5 Formulation tank Ay 39970
6 Blower assembly 39961
7 Nozzle Ay 62313
8 Carry strap (not shown) M-00254
