Baratza Maestro Plus Manuale utente

Conical Burr Coffee Grinder

Operations Manual

Skilled in the art of grinding

Operations manuals are available in the following languages at

www.baratza.com

English .pdf Spanish .pdf French .pdf

Thank you for purchasing the Maestro Plus Conical Burr Cof-

fee Grinder. With the Maestro Plus, it’s now easier than ever

to make professional quality coffee. Below are detailed descrip-

tions of the features that make the Maestro Plus stand out from

other grinders in its class.

Precise, conical burrs

The slow rotating conical burrs of the Maestro Plus preserve

the aroma and avor of the freshly ground beans. Forty steps of

adjustment provide the ne tuning needed for Espresso, Drip, and

French Press Coffee.

Front mounted pulse button

Front-mounted pulse button makes it easy to grind directly into

an espresso brew basket. The discharge chute is designed to

accommodate any home or commercial espresso brew basket.

The Maestro Plus also has a sixty second timer, with segmented

graphics, for easily repeatable grind times.

Innovative burr calibration system

The range of grind and the accuracy of the settings is truly im-

pressive. The Maestro Plus has 40 distinct settings of grind from

Espresso to French Press. An innovative calibration system al-

lows all the manufacturing tolerances of the grinder to be elimi-

nated, resulting in identical, accurate performance from each

grinder. Furthermore the Maestro Plus ring burr is supported

on three points, providing a stable platform for a more accurate

grind.

Table of Contents

Introduction ............................................................................................. 1

Table of Contents .................................................................................... 2

Parts Identication .................................................................................. 3

Safety Information.................................................................................... 4

Initial Operation ....................................................................................... 5

Setting the Grind Control ........................................................................ 5

Adjustable Self Timer .................................................................. 6

Front Mounted Pulse Button ....................................................... 6

Care and Cleaning .................................................................................. 7

Cleaning the Housing and Hopper .............................................. 7

Cleaning the Burrs ...................................................................... 7

Remove the Ring Burr ................................................................ 7

Replacing the Ring Burr ............................................................. 8

Replacing the Bean Hopper ....................................................... 8

Automatic Cleaning .................................................................... 9

Troubleshooting .................................................................................... 10

Warranty and Service ........................................................................... 11

Notes .....................................................................................................12

BEFORE USING YOUR GRINDER

Prior to using your Maestro Plus grinder for the rst time you should

wash the bean hopper and ground coffee bin in warm soapy water. See

the section on Care and Cleaning for instruction on how to remove and

reinstall these parts.

Whole Bean Hopper

Grind Adjustment Scale

Pulse Button

Adjustable Self-Timer

Ground Coffee Bin

Hopper Lid

Grind Setting Indicator

•

Solid Steel Base

•

Grind Adjustment Ring

Parts Identication

Burr Alignment and Lifting Tabs

Removable Ring Burr

Silicone Seal (cutaway)

Grind Adjustment Tab

Center Cone Burr

•

Important Information

Please read the information below very carefully. It contains im

portant tips for the use, the safety and the maintenance and care

of this appliance. Please keep these operating instructions for

future reference.

Use only with 120-Volt current. Use only on alternating current

(AC).

Only clean the grinder housing with a dry or slightly damp cloth.

Do not use this grinder for anything other than its intended use

(i.e. grinding whole roasted coffee beans).

Disassemble your grinder only as directed in the care and

cleaning section of this manual. If you cannot remedy a mal

function check www.baratza.com and visit our FAQ page. If you

need further assistance e-mail us at suppor[email protected] or

call us at 877-701-2021.

Baratza will not accept any liability for damage or injury if the

grinder is used other than for its intended purpose or is

improperly operated or repaired. All warranty claims will be void.

For Your Safety

Do not operate the grinder with a damaged cord or plug, or if

the grinder malfunctions.

Do not leave your grinder unattended while turned ON.

Shut off and unplug the grinder from the electrical outlet when

not in use and before cleaning.

To unplug, grasp plug and remove from the outlet-never pull on

cord.

Keep your grinder out of the reach of children.

Do not immerse the grinder, plug or cord in water or any other

liquid.

Caution

Always unplug the electrical supply cord prior to cleaning.

�

•

Initial Operation

Place the Maestro Plus Grinder on a level surface. Insert the plug into a

120V AC outlet. Remove the lid from the hopper by lifting off. Pour the

desired quantity of roasted whole coffee beans into the hopper up to a

maximum of 8 oz. Replace the lid. Ensure the ground coffee bin is fully

inserted.

Setting the Grind Control

Slowly rotate the bean hopper

clockwise or counter clockwise

to align the indicator on the bean

hopper with the desired number

setting on the grind scale. Select

the correct grind for the brew pro-

cess you are using. 40 grind set-

tings are available. The settings

shown in the table below can be

used as a general guideline. The actual grind size for a particular setting

will vary depending on many factors, including: degree of roast (light vs.

dark), freshness, humidity, type of bean, oil content, etc. With use, you

will determine the setting that is right for your taste, brewing style and

your favorite beans.

Note: Partially ground coffee beans may remain between the burrs after

the grinder is turned off, adjusting the grind may be easier when the

grinder is running. Avoid running the grinder at very ne settings without

beans as it can damage the burrs.

Setting Type of Coffee Grind

1 to 14 Espresso Fine

16 to 32 Filter / Drip Medium

34 to 40 Press Coarse

Adjustable Self Timer

The Maestro Plus is equipped with a 60

second timer switch. Each segment around

the timer represents about 10 seconds of run

time. The grinder switches off automatically

once the time has elapsed. If you want to

interrupt grinding before the time has elapsed,

simply turn the timer switch counterclockwise

until the grinder switches off.

The quantity of ground coffee you need depends on

the type of bean, coarseness of the grind, brewing

method and personal taste. With use, you will nd

the most suitable settings for your personal taste.

Front Mounted Pulse Button

For short duration grinding, the Maestro Plus is

equipped with a front mounted pulse button. It can

be used for grinding directly into an espresso-brew-

ing basket. Remove the grounds bin and position the espresso-basket

inside the grinder directly below the pulse button (see photo). Push

and hold the pulse button to grind. Grinding will stop when the button is

released.

Note: It is important that the espresso

basket is held below the discharge

chute so the coffee powder can free fall

into the basket. Holding the basket up

tight to the discharge chute will cause

coffee to back up and jam your grinder.

Care and Cleaning

Cleaning the Housing and Hoppers

Switch the grinder off and remove the plug

from the power supply. Remove any remaining

beans from the bean hopper (it may be easiest

to tip the grinder over and pour the beans into

a bowl.). Remove the hopper by twisting it in a

counterclockwise direction as far as it will turn,

and then lift the bean hopper from the housing.

Wash the hopper, hopper lid, and ground coffee

bin in warm soapy water, rinse and dry.

Caution

Do not put the bean hopper, hopper lid, or

ground coffee bin in the dishwasher. Hand wash

only. Do not immerse the grinder housing in

water.

Cleaning the Burrs

If the grinder is used daily, the burrs should be

cleaned every few weeks. Cleaning enables the

burrs to achieve the most consistent grind pos-

sible. Cleaning also removes coffee oils, which

can degrade the avor of the ground coffee. Do

not wash the burr.

Remove the Ring Burr

Pull the silicone seal off the top of the ring Burr.

Remove the ring burr by lifting it straight up out

of the grinder by the lifting tabs. If the burr does

not lift out, ensure that the grind adjustment tab

is turned fully counterclockwise.

Cleaning the Ring Burr

Use the bristle brush (included with your grinder)

to remove any loose coffee residue on the ring

burr, the center cone burr and in the adjustment

area. Vacuum or blow out the residual coffee.

Wash the silicone seal in warm soapy water and

dry.

Replacing the Ring Burr

Replace the ring burr by lining up the red tab on

the ring burr with the red arrow on the adjustment

ring, if it is not aligned rotate the adjustment ring

fully counter clockwise. Wiggle and push down

rmly on the ring burr to ensure that it seats prop-

erly.

Replacing the Silicone Seal

After replacing the ring burr, replace the silicone

seal by lining up the two slots in the silicone seal

with the small tabs on the top of the ring burr and

slide the seal onto the ring burr.
