BARCO PROJECTION SYSTEMS

Date :

05092000

INSTALLATION MANUAL

LENS LD(0.8:1) FOR ELM SERIES

R9840420

Art. No. :

R5976127

Rev :

LD(0.8:1)

Kit

BARCO  1  Projection Sy tem

LD(0.8:1) Lens R9840420

What has to be

done

Thi new len ha to be in talled on an ELM erie projector

Necessary Tools no tool nece ary

To be continued on next page.

Lens Formula To calculate the di tance between the projector front ide (metal plate) and the creen

(PD) for a given creen width (SW), u e the following formula for

BarcoELM G10 :

Metric y tem (PD and SW in meter) :

PD = 0.8 x SW - 0.03

Inch y tem (PD and SW in inch) :

PD = 0.8 x SW - 1.18

BarcoELM R12 :

Metric y tem (PD and SW in meter) :

PD = 0.64 x SW - 0.03

Inch y tem (PD and SW in inch) :

PD = 0.64 x SW - 1.18

Installing the

Lens

The len i delivered with an adapter ring mounted. To in tall the len , follow the next

procedure or look into the owner manual :

Switch on the projector.

Pu h 3x on the HELP key.

Pu h the é key to open the len bridge (motor part of the

len hou ing).

Take the len out of it packing material and remove the

len cover .

Turn the len into the len holder by turning clockwi e.

Pu h the ê key to clo e the len bridge.

Pre EXIT to return to operational mode.

Step Action

BARCO  2  Projection Sy tem

LD(0.8:1) Lens R9840420 (Continued)

Lens Cleaning

Procedure

To minimize the po ibility of damaging the optical coating or cratching expo ed len

urface, we have developed recommendation for cleaning the len .

FIRST, we recommend you try to remove any material from the len by blowing it off

with clean, dry deionized air. DO NOT u e any liquid to clean the len e .

A Toray eeTM cloth i included with the len kit.

Proceed a follow :

Alway wipe len e with a CLEAN Toray eeTM cloth.

Alway wipe len e in a ingle direction. Do not wipe back and for-

ward acro the len urface a thi tend to grind dirt into the coating.

Do not leave cleaning cloth in either an open room or lab coat pocket,

a doing o can contaminate the cloth.

If mear occur when cleaning len e , replace the cloth. Smear are

the fir t indication of a dirty cloth.

Do not u e fabric oftener when wa hing the cleaning cloth or oftener

heet when drying the cloth.

Do not u e liquid cleaner on the cloth a doing o will contaminate the

cloth.

Step Action

Order number for a new Toray eeTM cloth : R379058.

Toraysee Cloth

Order Number
