Barco ULTRA REALITY 7000 Manuale utente

The new standard in reliability, maintainability, and performance

GenesisTM Series raster/calligraphic projectors

Barco’s GENESIS™ Series provide the

ultimate in digital, high-performance

raster/calligraphic projection The

GENESIS™ Series uses Barco’s proprietary

design and delivers a level of

performance and dependability

unmatched by any other system 2x

increase in pixel count translates into

increased calligraphic performance in

day/night/dusk/NVG modes Feature-

for-feature, the GENESIS™ Series projectors

offer outstanding value and performance

for a broad range of Level C and Level D

full-flight simulation applications

Barco Genesis™ Advantages

The GENESIS™Series projectors offer many advantages not found in other types of CRT

projectors:

•All digital calligraphic interface

•Superior image definition

•2x increase in lightpoint drawing capacity

•Calligraphic performance with dynamic range far exceeds any other projection

technology

•Dynamic multi-level, four-sided edge blending

•Extreme distortion capability with superior geometry alignment performance results in

highest picture quality with no pixel loss

•Interlace and non-interlaced operation with frame extension

•Liquid- or air-coupled lens compatibility

•Industry-standard, 9-inch projection CRTs

•CE/UL compliant

•Advanced architecture offers unparalleled image stability

•Lens focus adjustment and Scheimpflug adjustment for optimum focus

•Enhanced diagnostics for remote monitoring and support

•Simplified alignment requiring less training and support

•Exceeds all full-flight, motion-based requirements

•1-year warranty

www.simulation.barco.com

Barco Simulation

US Headquarters:

600 Bellbrook Avenue - Xenia, OH 453 5-4053

Tel. +1 (937) 372-7579 • Fax +1 (937) 372- 645

email: simulation.us@barco.com

European Headquarters:

Noordlaan 5, B 520 Kuurne - Belgium

Tel. +32 56 36 2 11 • Fax +32 56 36 6 51

email: info.simulation@barco.com

March 2005

Barco Simulation is an ISO 9001 registered company.

The information and data given are typical for the equipment described.

However any individual item is subject to change without any notice.

The latest version of this product sheet can be found on www.simulation.barco.com.

ENESIS

and xRACU are trademarks of Barco.

DESIGNED UNDER

ISO

AutoAli n™

This proven, revolutionary system enables you to quickly and easily setup and

maintain a multiple projector system with minimal user intervention Advanced

technology allows you to perform repeatable and accurate alignments that exceed

typical human performance standards Barco's AUTOALIGN system provides an

automated approach to efficiently perform routine alignment tasks, resulting in

rapid channel and display system alignment

Experienced, Reliable Worldwide Support

Barco is committed to providing world-class, worldwide service and support

including after-sales technical support, product and application training, and

documentation services Our customer support specialists provide professional,

accurate, and timely responses 7 days a week, 24 hours a day, every day of the

year All systems are backed by a 1-year warranty

For assistance in evaluating your visual display needs, please visit us on the

web or call our sales office.

Desi ned for Lower Cost of Ownership

Simulation systems demand the highest reliability and ease of maintenance

GENESISSeries projectors offer unrivaled efficiency through a fully focused digital

architecture They are designed with a minimum number of LRUs (line replaceable

units) for easy maintenance Modular unit design allows you to exchange

components or perform repairs quickly to minimize downtime and increase uptime

Universal Compatibility

GENESISSeries projectors seamlessly integrate with any available raster/calligraphic or

raster image generator Projectors can be configured to optimize the visual system

performance and packaging constraints

Remote Ali nment and Control

GENESISSeries projectors are equipped with a user-friendly control interface for setup

and maintenance

•Alignment data can be stored and easily recalled

•Diagnostics provide simulator visual system alert functionality

•Unit can be used as a remote interface to other IG systems

•Full control via Ethernet

AutoAlign

The RACU features a user-

friendly, full-color, touch-screen

display. On-screen menus guide the

operator through the alignment process.
