Barton RCL-4002 Manuale utente
Ready Care Lift
(RCL-4002)
(RCL-4500)
(RCL-6002)
Operation Manual
(Model RCL-4002 Shown)
Rev A March 2007
Page #
Warnings 1
Warranty 2
Ready Care Lift (Model 4002) Specifications 3
Ready Car Lift (Model 4500) Specifications 4
Bariatric Ready Care Lift (Model 6002) Specifications 5
Ready Care Lift Overview 6
Assembly 7
Operation 8
Operation (special instructions for lifting from a vehicle 10
Slings
- Loading in a Seated Position 11
- Loading in a Recumbent Position 12
- Positioning the Legs 13
- Sling Care 14
Transfers 15
Interchangeable Battery System Overview 17
IBS Technical Data 18
Placing and Removing the Battery Pack 19
Installing the Charging Station 20
Ready Care Lift Scale (optional) 22
Scale Attachment (optional) 23
Scale Operation (optional) 24
Ready Care Lift - Major Components 25
Hanger Assmebly - Detail View 26
Interchangeable Battery System - Bariatric 27
Placing and Removing the Battery - Bariatric 28
Maintenance 29
Troubleshooting 30
Note: The maintenance checklist located in the back of the manual should be
photocopied and used to record your Ready Care Lift inspections.
Reminder:
Do not forget to complete and return the warranty card located in the back of the
Ready Care Lift manual.
Ready Car Lift Overview 9
TABLE OF CONTENTS
DO NOT ATTEMPT TO SETUP OR OPERATE THE READY CARE LIFT
WITHOUT THOROUGHLY REVIEWING THE CONTENTS OF THIS
MANUAL! FAILURE TO DO SO MAYRESULTIN SERIOUS INJURY,
EQUIPMENT FAILURE,AND/OR VOID WARRANTY.
If you have any questions regarding the setup or operation of the Ready
Care Lift, please contact:
AFFIX DEALER CONTACT
INFORMATION HERE
Or contact Barton Medical:
1-800-387-7103
THE READY CARE LIFT FROM BARTON MEDICAL HAS BEEN INSPECTED TO
C.S.A. (CANADIAN STANDARDS ASSOCIATION) GUIDELINES.
WARNINGS
1
WARRANTY
Warranties are limited to manufacturer’s defects and exclude the effects of normal wear
and tear, unintended use, operator abuse, concussive impacts and external factors
including exposure to heat lamps, vapours, chlorine and other corrosive substances.
Barton Medicals’ liability under warranties is limited to replacing defective parts and does
not extend to consequential damages. Warranties are voided by unauthorized repairs or
modifications to the equipment.
Structure
(includes structural frame)
Lifetime warranty. Does not include damage to enamel caused from wear and/or operator
abuse.
Arm Grips, Safety Straps
Ninety day warranty against manufacturers defects.
All Other Components
All other components of the Ready Care Lift, including castors and Interchangeable Battery
System have a one year warranty.
Please complete the warranty card and return it immediately to:
Canada/International:
Barton Medical Canada
5510 Mainway
Burlington, Ontario
L7L 6C4
United States:
Barton Medical Corporation
5725 Hwy 290 West, Suite 103
Austin TX 78735
Or Fax it to: 905-336-1708
This manual contains operating, maintenance and service instructions for the Ready Care
Lift.
It is the user's responsibility to ensure the correct use of Ready Care Lift and coordinate
the maintenance schedule to maintain good operating condition.
Specifications remain subject to change to allow the introduction of design improvements
and will be done without notice.
2
PRODUCT NUMBER: RCL-4002
OPERATION: Electric Actuator
POWER SOURCE: 24 V (4.5 Amp)
BOOM, Highest Position: 70” (178 cm)
BOOM, Lowest Position: 23” (58 cm)
MAXIMUM CAPACITY: 500 lbs (182 kg)
OVERALL LENGTH: 45½” (116 cm)
BASE/LEG WIDTH, Closed: Inside - 21¼” (54 cm)
Outside 25¾” (65 cm)
BASE/LEG WIDTH, Open: Inside - 44” (112 cm)
Outside 49” (125 cm)
FRONT CASTERS, Dual wheel: 3” (8 cm)
REAR CASTERS, Single w/brake: 4” (10 cm)
OVERALL WEIGHT: 120 lbs (54.4 kg)
CONSTRUCTION: Rectangular steel tubing
FINISH: Polyester powder coat, baked
EMERGENCY STOP SWITCH: Standard
EMERGENCY LOWERING SWITCH: Standard
LOW BATTERY LEVEL LIGHT: Standard
LOW BATTERY AUDIBLE INDICATOR: Standard
ELECTRIC HAND CONTROL: Standard
BATTERY CHARGING
(on unit or at remote location): Standard
CHARGING TIME (FROM EMPTY): 9 hours (4.5 Amp battery with
500mA charging)
LIFTS PER CHARGE (under maximum load): 36 Cycles
READY CARE LIFT SPECIFICATIONS
3
PRODUCT NUMBER: RCL-4500
OPERATION: Electric Actuator
POWER SOURCE: 24 V (4.5 Amp)
BOOM, Highest Position: 65-¾” (167 cm)
BOOM, Lowest Position: 29” (73.7 cm)
MAXIMUM CAPACITY: 500 lbs (182 kg)
OVERALL LENGTH: 45½” (116 cm)
BASE/LEG WIDTH, Closed: Inside - 21¼” (54 cm)
Outside 25¾” (65 cm)
BASE/LEG WIDTH, Open: Inside - 44” (112 cm)
Outside 49” (125 cm)
FRONT CASTERS, Dual wheel: 3” (8 cm)
REAR CASTERS, Single w/brake: 4” (10 cm)
OVERALL WEIGHT: 110 lbs (49.9 kg)
CONSTRUCTION: Rectangular steel tubing
FINISH: Polyester powder coat, baked
EMERGENCY STOP SWITCH: Standard
EMERGENCY LOWERING SWITCH: Standard
LOW BATTERY LEVEL LIGHT: Standard
LOW BATTERY AUDIBLE INDICATOR: Standard
ELECTRIC HAND CONTROL: Standard
BATTERY CHARGING
(on unit or at remote location): Standard
CHARGING TIME (FROM EMPTY): 9 hours (4.5 Amp battery with
500mA charging)
LIFTS PER CHARGE (under maximum load): 40 Cycles
READY CAR LIFT SPECIFICATIONS
4
PRODUCT NUMBER: RCL-6002
OPERATION: Electric Actuator
POWER SOURCE: 2 X 12-Volt sealed, lead acid
BOOM, Highest Position: 71” (180 cm)
BOOM, Lowest Position: 23.75” (60 cm)
MAXIMUM CAPACITY:700 lbs. (272 kg.)
OVERALL LENGTH: 53.5” (136 cm)
BASE WIDTH, Closed: inside: 21” (53.5 cm)
outside: 25” (63.5 cm)
BASE WIDTH, Open: inside: 49” (124.5 cm)
outside: 53.25” (135 cm)
FRONT CASTERS, Dual wheel: 3” (7.6 cm)
REAR CASTERS, Single w/brake: 4” (10.2 cm)
OVERALL WEIGHT: 136 lbs. (61.8 kg.)
CONSTRUCTION: Rectangular steel tubing
FINISH: Polyester powder coat, baked
EMERGENCY STOP SWITCH: Standard
EMERGENCY DOWN SWITCH: Standard
BATTERY CONDITION INDICATOR: Standard
ELECTRIC HAND CONTROL: Standard
BATTERY PACK: Standard
BATTERY CHARGING (On or Off
Unit with charging station): Standard
SLING Optional
SCALE Optional
Actuator:
Thrust.....................................10 000 N (~2250 Lb)
Stroke Length.........................350 mm (13.78”)
BARIATRIC READY CARE LIFT SPECIFICATIONS
5
Foot Pedal
Tie Rod
Tie Rod End
VIEW A
Detailed View of Foot Pedal Assembly
Textured
Sure Grip
A
(see detailed view)
Interchangeable
Battery System
Mast
Actuator
Lift Arm
Steering
Handles
Rear Locking
Casters
Sling
Hanger
Lift Arm
End Cap
READY CARE LIFT OVERVIEW
6
1. Without using a knife, open the carton and remove the packaging which secures the
lift in the box. When removing the mast be careful as the lifting arm and actuator are
fastened to the mast.
2. Once all the parts have been removed from the carton, ensure you have all the
components which make up the lift. If there is a discrepancy please call your supplier
or Noram Solutions at 1-800-387-7103
3. Place the base on the floor and lock the rear castors to prevent movement while
assembling. Remove the three hex head bolts and plastic caps from the centre of the
base.
4. Position the mast over the corresponding holes in the base with the angle in the mast
tilting away from the lift and the actuator positioned between the legs of the lift.
5. Tighten all three bolts and replace the white caps over the bolt heads.
6. Remove the pivot bolt from the top of the mast and position the lifting arm between
the sides of the mast. Slip one nylon washer on both sides of the lifting arm, between
the lifting arm and the sides of the mast. Insert bolt and secure with nylock nut and
washer.
7. Remove the electronics pack from the small parts box.
8. Mount the electronics pack on the back of the Ready Care Lift mast using the two
machine screws (already attached to the mast).
9. Remove the battery pack from the small parts box and place it on the electronics
pack (see Placing and Removing the Battery Pack on page 17).
10. Take the plug end from the actuator and connect it to the actuator port on the
bottom of the electronics pack (see Electronics Pack Bottom View on page 14).
11.Test the emergency stop button by depressing it. Using the hand control (it is
attached to the electronics pack during shipping) push the up and down buttons. The
lifter should be inoperable. Disengage the emergency stop button by turning it in the
direction of the arrows (clockwise). Push the up and down buttons on the hand
control. The lifter should now operate up and down.
ASSEMBLY
7
CHARGE YOUR READY CARE LIFT EVERY NIGHT USING THE CHARGER PROVIDED.
1. The lift should not be operated (more than two lifts) when the battery level indicator begins to
flash yellow. Be sure to charge as soon as possible. Extended use of the battery pack when
the low battery indicator is flashing may permanently affect the capacity of the batteries in
the pack.
2. The battery pack should be charged while on the lift. Plug the charger into the charging port
on the bottom of the electronics pack (see Electronics Pack Bottom View on page 14).
3. The battery pack may also be charged using a separate wall-mounted charging station
(optional). The battery pack is simply removed from the lift (see Placing and Removing the
Battery Pack on page 17) and placed onto the charging station. Charging begins
automatically. (Note: The charger remains plugged into the charging station).
4. The battery charger provided with the lifter is automatic (when plugged in, it begins to charge
automatically and shuts off when charging is completed). When charging, the yellow LED
on the electronics pack (or optional charging station) indicates that the battery is charging.
When the LED on the electronics pack (or optional charging station) turns green, the battery
is fully charged. There is no danger of overcharging the batteries.
5. The hand control is electric and controls the raising and lowering of the lift arm. To raise the
lift arm, simply press the up button on the hand control. To lower the lift arm, press the down
button (see Hand Control Overview on page 14).
6. There is an emergency lowering switch located on the bottom of the electronics pack (see
Electronics Pack Bottom View on page 14). This will enable the lift to be lowered in the event
the hand control should fail or the electronics malfunction. If there is a malfunction do not
use this lowering method on a continuous basis. The problem should be corrected by
qualified service personnel.
7. There is an emergency stop button located on the front of the electronics pack (see
Interchangeable Battery System Overview on page 14). This will cut power to the motor in
case of a malfunction. Push the button to cut power to system. Turn the button in the
direction of the arrows (clockwise) to reactivate power to the system.
8. Examine slings regularly.Never use slings that are torn or are showing signs of wear.
Replace slings immediately to ensure the safety of your patients.
9. We strongly recommend that you have your lifter inspected and tested by qualified service
personnel at least once a year. Service contracts can be arranged through your local Noram
dealer.
OPERATION
8
