Baumatic TITAN2 Manuale utente

TITAN2 Stainless steel

side by side frost free

fridge/freezer

Get user manuals: See SafeManuals.com

USER MANUAL FOR YOUR BAUMATIC

TITAN2 Stainless steel side by side

541 litre frost free fridge/freezer

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference, for

you or any person not familiar with the operation of the appliance.

DD 11/04/07

Get user manuals: See SafeManuals.com

Contents

Environmental note 4

Important safety information 5 – 6

Specifications of your fridge freezer 7

Dimensions of the appliance 7

Energy efficiency class 7

Cubiccapacities 7

Specifications of your appliance 7

Descriptionoftheappliance 8

Description of the product features 9-10

Using your Baumatic fridge freezer 11

Beforeswitchingon 11

Duringfirstuse 11

Controlpanel 12

Turning on the appliance 13

Setting the thermostat in the freezer 13

Setting the thermostat in the fridge 13-14

Turning on the super freezer option 14

Turning on the super refrigerator option 15

Arranging and storing food in the fridge section 15-16

The freezer compartment 17

Freezingfreshfood 17

Tipsonfreezing 18

Activating the child lock 18

The dispenser 19

Before first use 19

Usingthedispenser 19-20

The ice maker 20

Dispenser and ice maker warnings 21

Lockingtheicemaker 21

Removing and replacing the ice cube storage case 22

Water filter change icon 22

Important user information 22

Cleaning and maintenance 23-25

Defrosting the freezer compartment 25-26

Replacing the light bulb 26-27

Installation 28

Electricalconnection 28

Positioning 29

Installation preparation 30

Removing the freezer door 30-31

Removing the fridge door 32

Replacing the freezer door 33-34

Replacing the fridge door 34-35

The water inlet hose and water filter 35

Connecting the water inlet hose and water filter 35-38

Levelling the appliance and adjusting the doors 39

Fitting the front cover 39

Replacing the water filter 40

Troubleshooting 40-41

Baumatic Ltd. conditions of guarantee 42

Contact details 43

Get user manuals: See SafeManuals.com

Environmental note

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any plug

useless. Cut the cable off directly behind the appliance to prevent

misuse. This should be undertaken by a competent person. Disable

the door lock to make sure that children cannot get stuck inside

the appliance.

oThe packaging materials that Baumatic uses are environmentally

friendly and can be recycled.

oPlease discard all packaging material with due regard for the

environment.

Get user manuals: See SafeManuals.com

Important safety information

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Technical

Department.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

Use of the appliance

oYour appliance is only designed to be used in the

home. It is suitable for storing food that needs to

be chilled and refrigerated. If it is used for any

other purpose or it is not used correctly, then

Baumatic Ltd. will accept no liability for any

damage that is caused.

oAltering the specification of the appliance must not be attempted

for reasons of safety.

Before using your appliance

oCheck the appliance for any signs of transport damage. If you

notice any damage, then you should not connect your appliance

to your mains supply and should contact your retailer.

Refrigerant

oYour appliance contains R600a refrigerant, which is a natural gas

that does not contain CFCs that can damage the environment.

However it is a flammable substance, therefore care should be

taken:

During the transportation and installation of the

appliance, make sure that the refrigeration pipework

does not get damaged.

If it does become damaged then sources of ignition

and open flames should be avoided. Also the room

that the appliance is situated in should be thoroughly

ventilated.

oDo not place any objects on top of the appliance,

as this may damage the table top.

Get user manuals: See SafeManuals.com

Child safety

oPackaging material should be kept away from

children.

oChildren should not be allowed to touch the

controls or play with the appliance.

General safety

oDo not pull on the power supply cable to remove the plug from

your mains supply socket.

oDo not pull out or insert the plug with wet hands.

oDo not attempt to use your appliance outdoors or

any place where it is likely to come into contact

with the elements.

oBefore cleaning the appliance or performing

maintenance work, ensure that the appliance has been

disconnected from your mains supply.

oNever allow the back coils of the appliance to come into contact

with the wall surface.

oAlways ensure that the location where you are installing your

appliance is free of stored items such as papers and other

flammable materials.

oNever block the ventilation openings of the appliance, either on

the inside or its exterior.

oIt is vital to keep your appliance well ventilated,

so that there is proper air flow between the

bottom of the unit and the plinth/kick plate

which it is sitting on.

oDo not place electrical devices inside of the appliance, such as

mixers or ice cream makers.

Service

You should not attempt to repair the appliance

yourself, as this could cause injury or a more serious

malfunction. If you require a service call then please

contact the Baumatic Service Department.

Get user manuals: See SafeManuals.com

Specifications of your fridge freezer

Congratulations on purchasing a Baumatic fridge freezer

Dimensions of your appliance

oHeight: 1790 mm

oWidth: 900 mm

oDepth: 730 mm

Energy efficiency class

oEnergy class: A

Cubic capacities

oGross capacity (fridge): 357 litres

oGross capacity (freezer): 184 litres

oNet capacity (fridge): 334 litres

oNet capacity (freezer): 170 litres

Specifications of the appliance

oFrost free fridge and freezer

oMulti airflow cooling system

oDigital control panel

oIce maker

oWater dispenser

oDeodorizer

oAnti-bacterial surface

o4 Safety glass shelves

oMeat drawer

oFolding wine tray

o2 Salad crispers

o2 Egg racks

oButter compartment

o3 General racks

o2 Bottle racks

o4 Freezer shelves

o6 Freezer storage compartments

o2 Removable plastic drawers

oIce cube tray

oDoor storage

IMPORTANT: When you install your appliance it is important to bear

in mind its climatic rating.

In order to find out the climatic rating of your appliance, you should

check the rating plate. The rating plate is located on the front left edge

of the inside of the fridge section. You will need to open the door of

your appliance to be able to find it. The rating plate will indicate the

ambient temperature range that your appliance will function correctly

within.

Get user manuals: See SafeManuals.com

Description of the appliance

Freezer section

1) Door storage compartments

2) Freezer shelves (x 4)

3) Dried foods compartment

4) Meat storage compartment

Fridge section

5) Refrigerator shelves (x 4)

6) Movable egg container

7) Salad/vegetable drawer

8) Fruit drawer

9) Dairy compartment

10) Door storage compartments

12) Wine rack

Get user manuals: See SafeManuals.com

Description of the product features

Shelves

oThe shelves may be placed in any of the guide slots within the

interior of the appliance. They are protected from sliding out.

oTo remove a shelf: Take off all of the items that are stored on

the shelf that you want to remove. Then lift the front of the shelf

and carefully pull it out of the grooves.

Freezer section door storage compartments

oThe top door storage compartment should not have ice cream or

foods that are going to be stored for a long period of time put in

it.

oIMPORTANT: IT IS IMPORTANT THAT NONE OF THE

SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS

THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE.

Dried foods compartment

oFor storage of dried foods (such as dried herbs, dried vegetables

etc).

Meat storage compartment

oFor storage of meat and fish (we would recommend that they

are stored in a foil cover or a vinyl wrap).

Fridge section door storage compartments

oThe door liner holds various shelves, which are suitable for

storing eggs, cheese, butter and yogurt. As well as smaller

packages, tubes, cans etc.

oThe lower shelves should be used for storing reasonably sized

bottles.

oIMPORTANT: IT IS IMPORTANT THAT NONE OF THE

SHELVES THAT SIT IN THE DOOR ARE OVERLOADED, AS

THIS WILL DRASTICALLY REDUCE THEIR WORKING LIFE.

Movable egg container

oThis case can be placed on any shelf, depending on how the food

in your fridge is arranged.

Get user manuals: See SafeManuals.com

Salad/vegetable drawer

oFor storing salad and vegetables, the drawer is designed to keep

the contents fresh for as long as possible.

Fruit drawer

oFor storing fruits, the drawer is designed to keep the contents

fresh for as long as possible.

oCare should be taken when storing tropical fruit (bananas and

pineapples etc) and tomatoes. As these types of items can easily

deteriorate in a lower temperature.

Dispenser

oWill dispense chilled water, cubed ice or crushed ice.

Digital control panel

oShows the temperature that the fridge and freezer are set at.

oShows what option the water dispenser is set at.

oShows whether the child lock is engaged.

oShows whether the water filter needs changing.

Deodorizer

oAn antibiotic deodorizer that keeps food fresher, prevents the

growth of bacteria and helps to remove odours from the

appliance.

Get user manuals: See SafeManuals.com

Altri manuali per TITAN2

Indice

Altri manuali Baumatic Congelatore

Baumatic

Baumatic BR500 Manuale utente

Baumatic

Baumatic BRZF1759SE Manuale utente

Baumatic

Baumatic BV13A Manuale utente

Baumatic

Baumatic BR23.8A Manuale utente

Baumatic

Baumatic BRZ600.5 Manuale utente

Baumatic

Baumatic BV12.5 Manuale utente

Baumatic

Baumatic BZ555SE Manuale utente

Baumatic

Baumatic RETRO3BL/IV Manuale utente

Baumatic

Baumatic BR221.5 Manuale utente

Baumatic

Baumatic BR110 Manuale utente

Baumatic

Baumatic BF207BLM Manuale utente

Baumatic

Baumatic BV12.3A Manuale utente

Baumatic

Baumatic BR508 Manuale utente

Baumatic

Baumatic BF340BL Manuale utente

Baumatic

Baumatic BF272SL Manuale utente

Baumatic

Baumatic BRZF1760W Manuale utente

Baumatic

Baumatic BV12.2A Manuale utente

Baumatic

Baumatic BZE290SS Manuale utente

Baumatic

Baumatic BV14A Manuale utente

Baumatic

Baumatic BZ110 Manuale utente

Baumatic

Baumatic BZ550W Manuale utente

Baumatic

Baumatic TITAN1 Manuale utente

Baumatic

Baumatic BR221.3A Manuale utente

Baumatic

Baumatic QUATTRO.MR Manuale utente

Manuali Congelatore popolari di altre marche

Siemens

Siemens GU..D SERIES Manuale utente

Omcan

Omcan FR-CN-0155 Manuale utente

Beko

Beko FNE290E24W Manuale utente

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuale utente

Electrolux

Electrolux EUF2042AOX Manuale utente

Dometic

Dometic CoolFreeze CFX95DZ Manuale utente

Electrolux

Electrolux EUF7000W1 Manuale utente

Polar Electro

Polar Electro CT330 Manuale utente

MPM

MPM MPM-145-SK Series Manuale utente

SAF

SAF PRESTOTIG 200AC/DC Guida rapida

Zanussi

Zanussi ZFT11407WA Manuale utente

AEG

AEG A63190GT Manuale utente

AEG

AEG A81000TNW0 Manuale utente

Matsui

Matsui MUC50S15E Manuale utente

NEFF

NEFF G4344X8 Manuale utente

Frigidaire

Frigidaire FV 1246 H Manuale utente

Frigidaire

Frigidaire FFC13K1AW Manuale utente

Electrolux

Electrolux EU 2400C Manuale utente
