Baumatic CAN52.3ME Manuale utente

CAN52.3ME

CAN75.3SS

Canopy hood

User Manual for your Baumatic

CAN52.3ME 52 cm

CAN75.3SS 75 cm

Canopy ood

NOTE

This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance

GS 12/04/12

Contents Page

Environmental note 4

IMPORTANT SAFETY INFORMATION 5 – 7

Specifications of your cooker hood 8 – 10

CAN52.3ME 8

CAN75.3SS 9 - 10

Using your Baumatic cooker hood 10 - 11

Before first use 10

To use our cooker hood 10 - 11

Cleaning your Baumatic cooker hood 11 – 12

General cleaning 11

The grease filter 12

Maintenance 12 – 16

Removing and cleaning the grease filter 12 - 13

Changing a light bulb 13 - 14

Fitting the carbon filters 14 - 16

Installation 16 - 21

Electrical connection 17

Before beginning installation 17 - 18

Installing our cooker hood 18 - 20

Connecting to external ducting 20 - 21

Completing the installation 21

Extraction mode or recirculation mode? 21 - 22

Troubleshooting 22 – 24

Baumatic consumables 25

Contact details 26

ENVIRONMENTAL NOTE

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply Cut off and render any

plug useless Cut the cable off directly behind the appliance to

prevent misuse This should be undertaken by a competent

person

oThe packaging materials that Baumatic uses are environmentall

friendl and can be rec cled.

oPlease discard all packaging material with due regard for the

environment.

IMPORTANT SAFETY INFORMATION

Your safet is of the utmost importance to Baumatic.

Please make sure that ou read this instruction booklet

before attempting to install or use the appliance. If

ou are unsure of an of the information contained in

this booklet, please contact the Baumatic Customer

Care Department.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person

oThe hood must be installed in accordance with the installation

instructions and all measurements followed.

oIf the cooker hood is installed for use above a gas appliance then

the provision for ventilation must be in accordance with the Gas

Safet Codes of Practice BS.6172, BS.5440 & BS.6891 (Natural

Gas) and BS.5482 (LP Gas) 1994, the Gas Safet (Installation &

Use) Regulations, the Building Regulations issued b the

Department of the Environment, the Building Standards

(Scotland) (Consolidated) Regulations issued b the Scottish

Development Department.

oIt is dangerous to alter the specifications or to modif this

product. Do not tamper with it or attempt to modif the

appliance in an wa .

oWhen installing the hood, ensure that the following

recommended distances are observed between the highest point

on the hob top (including the burners) and the bottom of the

cooker hood:

Electric cookers: 700 mm

Gas cookers: 700 mm

Coal/ oil cookers: 800 mm

IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS

THAN 700mm ABOVE YOUR COOKER

oWhen installed between adjoining wall cabinets, the cabinets

must not overhang the hob.

oThe edges of the cooker hood are sharp – be mindful of this as

ou handle our appliance, especiall during installation and

cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTERS!

oIf the room where the cooker hood is to be used contains a fuel

burning appliance such as a central heating boiler then its flue

must be of the sealed or balanced flue t pe.

oIf other t pes of flue or appliances are fitted, ensure that there is

an adequate suppl of air in the room.

oWhen the hood is being used in its extractor function, ensure

that the ducting is fire retardant and that there are no bends

sharper than 90 degrees as this will reduce the efficienc of the

hood.

oEnsure the ducting for the extractor function has the same

diameter as the outlet hole all the wa through.

oKeep oung children from using, pla ing with

or tampering with the cooker hood. Older

children and infirm persons should be

supervised if the are using the cooker hood.

oYour cooker hood is for domestic use onl .

oPlease dispose of the packing material carefull – children are

especiall vulnerable to it.

oDirt oil is an even greater fire risk.

oAlwa s put lids on pots and pans when cooking

on a gas cooker.

oThe manufacturer refuses to accept an responsibilit for

damages arising to the hood or it catching on fire, from a failure

to observe the fire safet advice contained in this instruction

booklet.

oRemember that when in extraction mode, our cooker hood is

removing air from our room. Ensure that proper ventilation

measures are being observed.

oNote that it removes odours from your room, not steam

oWarning - Always ensure that the cooker

hood has been disconnected from the

power supply before carrying out any work

on the hood, including replacing light bulbs

oDo not connect the ducting s stem of this appliance to an

existing ventilation s stem which is being used for an other

purpose.

oDo not install above a cooker with a high level grill.

oNever leave fr ing pans unattended during use

as overheated fats and oils might catch fire.

oThe cooker hood should not be exposed to a direct heat source

from the cooking device underneath it, i.e. naked flame from a

gas burner or heat from electric hob zones without a pan on

them.

oDo not attempt to use the cooker hood if it is damaged in an

wa . Never attempt to use it without the grease filters fitted or

if the filters are excessivel greas !

oNever flambé cook under this cooker hood.

oThe lights on this appliance should onl be used during operation

of the cooker hood. The should not be left on permanentl and

used as a lighting source.

THE MANUFACTURER DECLINES ALL

RESPONSIBILITY IN THE EVENT OF FAILURE TO

OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR

INSTALLATION, MAINTENANCE AND SUITABLE

USE OF THE HOOD

Specifications of your cooker hood

CAN52.3ME

Product dimensions

Height: 158 mm

Width: 520 mm

Depth: 321 mm

Your canopy hood is fitted with:

oSlider control operation

oIntegrated axial motor

o3 speeds

o1 washable aluminium grease filter

oNon-return airflow flap

o2 halogen lights

oNoise level: 45 / 50 / 55 dB

Extraction capacit : 250 m³ / hr

Optional extras: 1 pair ST1 carbon filters for air recirculation

mode

DK5 1 metre length ducting kit 125 mm Ø

DK10 3 metre length ducting kit 125 mm Ø

with flat channelling included.

CAN75.3SS

Product dimensions

Height: 245 mm

Width: 740 mm

Depth: 295 mm

Your stainless steel canopy hood is fitted with:

oSlider control operation

oIntegrated axial motor

o3 speeds

o1 washable aluminium grease filter

oNon-return airflow flap

o2 halogen lights

oNoise level: 61 / 65 / 68 dB

Extraction capacit : 750 m³/hr

Optional extras: 1 pair S1 Carbon filters for air recirculation

mode

DK5 1 metre length ducting kit 125 mm Ø

DK10 3 metre length ducting kit 125 mm Ø

with flat channelling included.

All of the optional extras are available from the Baumatic

Spares Department.

Using your Baumatic cooker hood

Before first use

IMPORTANT: THIS PROCESS MUST BE FOLLOWED

BEFORE THE COOKER HOOD IS USED FOR THE FIRST

TIME

oYou should use a good qualit stainless steel cleaner on ALL of

the stainless steel areas of our cooker hood, before it is used

for the first time.

oThis will help to leave a silicone water-resistant film to protect

the stainless steel surfaces.

To use your cooker hood

oMake sure that it has been installed b a suitabl qualified

person, as per the information contained in Baumatic’s

installation instructions.

oFind the control panel, which is located at the front right of the

canop .

oThere are two sliders on the control panel, which perform

separate functions.

1) Light control The light can be used even when the motor is

OFF.

0 = Light OFF

1 = Light ON

2) Motor speed control

= Low speed

= Medium speed
