Baumatic BT06.8ME Manuale utente

BT06.8ME

BT08.8ME

60 cm Integrated

hood

User Manual for your Baumatic

BT06.8ME/BT08.8ME

60 cm Integrated

hood

NOTE: This User Instruction Manual contains important

information, including safety & installation points, which will

enable you to get the most out of your appliance. Please keep it

in a safe place so that it is easily available for future reference; for

you or any person not familiar with the operation of the appliance.

GS 03/01/12

Contents Page

Environmentalnote 4

IMPORTANT SAFETY INFORMATION 5 – 7

Specifications of your cooker hood 8 – 9

BT06.8ME 8

BT08.8ME 9

Using your Baumatic cooker hood 10 – 11

Beforefirstuse 10

To use your cooker hood 10 – 11

Turning the cooker hood off 11

Cleaning your Baumatic cooker hood 12

Generalcleaning 12

The grease filter 12

Maintenance 13 - 17

Removing and cleaning the grease filter 13 - 14

Changingalightbulb 15-16

Fitting the carbon filters 16 - 17

Installation 18 - 27

Electrical connection 18 – 19

Before beginning installation 19 - 20

Installing your cooker hood 20 – 22

Fitting the décor door 23 - 25

Connecting to external ducting 25 - 26

Extraction mode or recirculation mode? 26

Completing the installation 26 - 27

Troubleshooting 27 – 28

Baumatic consumables 29

Contactdetails 30

ENVIRONMENTAL NOTE

Note: Before discarding an old appliance, switch off and

disconnect it from the power supply. Cut off and render any

plug useless. Cut the cable off directly behind the appliance to

prevent misuse. This should be undertaken by a competent

person.

CONFORMITY TO W.E.E.E. DIRECTIVE

IMPORTANT SAFETY INFORMATION

Your safety is of the utmost importance to Baumatic.

Please make sure that you read this instruction booklet

before attempting to install or use the appliance. If

you are unsure of any of the information contained in

this booklet, please contact the Baumatic Customer

Care Department.

IMPORTANT: Any installation work must be

carried out by a qualified electrician or

competent person.

oThe hood must be installed in accordance with the installation

instructions and all measurements followed.

oIf the cooker hood is installed for use above a gas appliance then

the provision for ventilation must be in accordance with the Gas

Safety Codes of Practice BS.6172, BS.5440 & BS.6891 (Natural

Gas) and BS.5482 (LP Gas) 1994, the Gas Safety (Installation &

Use) Regulations, the Building Regulations issued by the

Department of the Environment, the Building Standards

(Scotland) (Consolidated) Regulations issued by the Scottish

Development Department.

oIt is dangerous to alter the specifications or to modify this

product in any way. Do not tamper with or attempt to modify

the appliance in any way.

oWhen installing the hood, ensure that the following

recommended distances are observed between the highest point

on the hob top (including the burners) and the bottom of the

cooker hood:

¾Electric cookers: 700 mm

¾Gas cookers: 700 mm

¾Coal/ oil cookers: 800 mm

IMPORTANT: DO NOT SET YOUR COOKER HOOD LESS

THAN 700mm ABOVE YOUR COOKER.

oWhen installed between adjoining wall cabinets, the cabinets

must not overhang the hob.

oThe edges of the cooker hood are sharp – be mindful of this as

you handle your appliance, especially during installation and

cleaning. DO NOT CLEAN IN BEHIND THE GREASE FILTER!

oIf the room where the cooker hood is to be used contains a fuel

burning appliance such as a central heating boiler then its flue

must be of the sealed or balanced flue type.

oIf other types of flue or appliances are fitted, ensure that there is

an adequate supply of air in the room.

oWhen the hood is being used in extraction mode, ensure that the

ducting is fire retardant and that there are no bends greater

than 90 degrees as this will reduce the efficiency of the hood.

oEnsure the ducting for the extractor mode has the same

diameter as the outlet hole all the way through.

oKeep young children from using, playing with

or tampering with the cooker hood. Older

children and infirm persons should be

supervised if they are using the cooker hood.

oYour cooker hood is for domestic use only.

oPlease dispose of the packing material carefully – children are

especially vulnerable to it.

oDirty oil is an even greater fire risk.

oAlways put lids on pots and pans when cooking

on a gas cooker.

oThe manufacturer refuses to accept any responsibility for

damages arising to the hood or for it catching on fire, from a

failure to observe the fire safety advice contained in these

instructions.

oRemember that when in extraction mode, your cooker hood is

removing air from your room. Ensure that proper ventilation

measures are being observed.

oNote that the cooker hood removes odours from your

kitchen, not steam.

oWarning - Always ensure that the cooker

hood has been disconnected from the

power supply before carrying out any work

on the hood, including cleaning and

replacing light bulbs.

oDo not connect the ducting system of this appliance to an

existing ventilation system being used for any other purpose.

oDo not install above a cooker with a high level grill.

oNever leave frying pans unattended during use

as overheated fats and oils might catch fire.

oThe cooker hood should not be exposed to a direct heat source

from the cooking device underneath it, i.e. naked flame from a

gas burner or heat from electric hob zones without a pan on

them.

oDo not attempt to use the cooker hood if it is damaged in any

way. Never attempt to use it without the grease filter fitted or if

the filter is excessively greasy!

oNever flambé cook under this cooker hood.

oThe lights on this appliance should only be used during operation

of the cooker hood. They should not be left on permanently and

used as a lighting source.

THE MANUFACTURER DECLINES ALL

RESPONSIBILITY IN THE EVENT OF FAILURE TO

OBSERVE THE INSTRUCTIONS GIVEN HERE, FOR

INSTALLATION, MAINTENANCE AND SUITABLE

USE OF THE HOOD.

Specifications of your cooker hood

BT06.8ME

Dimensions:

Height: 395 mm

Width: 600 mm

Depth: 282 mm

Specifications:

o1 x Integrated axial motor

oSlider control operation

oNon-return airflow flap

o3 Speeds

o1 Light

o1 synthetic grease filter

oExtraction capacity: 250 m³ / hr

oRecirculation capacity: 147 m³ / hr

oNoise level: 45 / 50 / 55 dB

Optional extras:

o1 pair of ST1 carbon filters for air recirculation mode

BT08.8ME

Dimensions:

Height: 395 mm

Width: 600 mm

Depth: 282 mm

Specifications:

oTwin integrated axial motor

oSlider control operation

oNon-return airflow flap

o3 Speeds

o1 Light

o1 synthetic grease filter

oExtraction capacity: 440 m³ / hr

oRecirculation capacity: 208 m³ / hr

oNoise level: 47 / 50 / 55

Optional extras:

o1 pair of ST1 carbon filters for air recirculation mode

Using your Baumatic cooker hood

Before first use

IMPORTANT: THIS PROCESS MUST BE FOLLOWED

BEFORE THE COOKER HOOD IS USED FOR THE FIRST

TIME.

oYou should clean the appliance using a brand new cloth, with

warm soapy water before using the appliance for the first time.

You should then dry it thoroughly using a soft cloth.

To use your cooker hood

oMake sure that it has been installed by a suitably qualified

person, as per the information contained in Baumatic’s

installation instructions.

oFind the control panel, which can be located by opening the front

panel and looking on the right hand side of the cooker hood.

oThere are two sliders on the control panel, which perform

separate functions.

Light ON/OFF slider

0 = Light bulb off

1 = Light bulb on
