BEA Iris Overhead Safety for Door Manuale utente
Header-mmounted
safety
utilizing
active
infrared
technology.
Utilizes the most reliable
technology for presence
detection. Provides a curtain
of protection.
Excellent
Safety
Solution
For
The
Industrial
Market
Can be used in conjunction with
the Falcon for an activation and
safety solution in an industrial
setting. Includes a 30’ cable to
accommodate the size of an
industrial door
Overhead safety for
small industrial doors.
®
Provides
Safety
Where
It
Is
Needed
Most
Provides safety throughout the door
opening and door closing cycles through
a precise curtain of safety for people
or equipment stopped in the threshold.
Minimal
Installation
and
Maintenance
Required
Replaces the labor-intensive inductive
loops with an easy-to-mount overhead
installation. All adjustments executed
through the BEA remote control.
Ability to be mounted up to 13’
when using the narrow lens with
infinite learn time capability.
Quality
Intelligence
Precision
WWW.BEASENSORS.COM
THE IRIS I
INDUSTRIAL
1
2
4
3
5
Contact
Information
BEA
Inc.
RIDC Park West
100 Enterprise Drive
Pittsburgh PA, 15275
Phone +1.412.249.4100
Fax +1.888.523.2462
Toll Free 1-800.523.2462
BEA
West
2401 Pine Street
Los Angeles, CA 91767
Phone +1.909.596.3011
Fax +1.909.596.5411
Toll Free 1-877.232.9378
Provides threshold safety up to 13’ on small Industrial doors.
Provides optimal safety around the threshold of an
automatic sliding door with 2 rows of 24 focused
infrared spots. EagleHM SuperScan Falcon FlexIR
24Vac Bodymount BodyGuard Matrix
1
2
3
4
Cable
Mounting Screws
Manual Set-up Push Buttons
Presence Sensor
Cover
LED Indicator
I.R. Remote Receiver
Front Lenses
5
DIMENSIONAL DRAWINGS
APPLICATIONS
RELATED PRODUCTS
COMPONENTS
6
7
WWW.BEASENSORS.COM
67
Overhead safety for
small industrial doors.
8
8
TECHNICAL SPECS
Supply
voltage
12V (– 5%) to 24V (+10%) AC/DC
Mains
frequency
50 - 60 Hz
Power
consumption
< 3 W
Mounting
height
6’8” TO 13’
2-ccolor
LED
RED (presence detection)
ORANGE (signal saturation,
error)
Temperature
range
-22°F to +131°F
Degree
of
protection
IP54
Norm
conformity
EMC 89/336/EEC
Dimensions
10.3” (L) x 2.2”(H) x 1.43” (D)
Weight
8 oz.
Housing
material
ABS + LURAN S
Minimum
length
of
cable
30’ (9 m) 9 conductor (10IRIS-I)
Range
of
Remote
Control
16’
Detection
mode
Presence
Response
time
< 128ms
Technology
Focused active infrared and
self-monitored microprocessor
Spot
diameter
(standard)
4” max
Number
of
spots
24 or 12 spots by curtain
Number
of
curtains
2
Detection
field
(@ 7’ Ht.)
Width
Depth
Wide
6’6” 13.75”
Narrow
3’3” 13.75”
Angle
From - 4° to + 4° (adjustable)
Output
specification
Relay
Max.
contact
voltage
42V AC/ DC
Max.
contact
current
1A (resistive)
Max.
switching
power
30W (DC) / 60VA (AC)
Output
holdtime
1s (fixed)
54.81
2.16
261.20
10.28
225.22
8.87
R9.50
.37
98.23
3.87
24.58
.97
35.62
1.40
3D Perspective
Bottom
Front
Side
THE IRIS I
INDUSTRIAL
2.16 in
54.81 mm
8.87 in
225.22 mm
10.28 in
261.20 mm
.37 in
R 9.50 mm
.97 in
24.58 mm
1.40 in
35.62 mm
3.87 in
98.23 mm
