Behringer Minimic Mic800 Manuale utente

Technical Specifications

Version 1.0 October 2005

MINIMIC MIC800

MIC800

MINIMIC

Ultra-Compact Microphone Modeling Preamp

VUltra-compact 9.5" microphone modeling preamp for studio and stage

applications

VHigh-end preamplifier for all microphone, instrument and line-level sources.

Perfectlycomplementsstudio-gradecondensermics

VUltra-flexiblePreampModelingallowsyoutoquickly optimize yourrecordings

VChoosebetween16 preampvoicings designedforelectricandacousticguitars,

keyboards, bass guitars, drums, vocals, etc.

VAuthenticVTCTubeModelingtechnologycreates thewarmth ofvacuumtubes

VEquippedwithBEHRINGER’s sophisticatedoutputlimiter—preventstheoutput

signalfrombeing distorted

VDedicatedLowCutfiltereliminatesunwantednoise,e.g.floorrumble

V+48 V phantom power and 20 dB Pad for utmost flexibility

VVintage-styleVUmeterforpreciselevelindication

VHigh-qualitypotentiometersandilluminatedswitchesforlong-term reliability

VUltralow-noiseaudiooperationalamplifiersofferoutstandingsoundperformance

VAll Mini Series components can be stacked on top of each other to create an

ultra-compactsignalprocessorsolution

VHigh-qualitycomponentsandexceptionallyruggedconstructionensurelong

life

VConceivedand designed byBEHRINGERGermany

MINIMIC MIC800

DEUTSCH

SPECIFICATIONS

MIC INPUT

Type XLR connector (balanced)

Impedance approx. 2.6 kΩ (balanced)

Max. input level -2 dBu, +18 dBu with pad

LINE INPUT

Type ¼" TRS connector (balanced)

Impedance approx. 20 kΩ (balanced)

Max. input level +19 dBu, +28 dBu with pad

OUTPUT

Type ¼" TS connector (unbalanced)

Impedance approx. 130 Ω

Max. output level +15 dBu

SYSTEM SPECIFICATIONS

Frequency response MIC: 10 Hz to 90 kHz, ±3 dB

LINE: 10 Hz to 67 kHz, ±3 dB

Dynamic range 100 dB, 20 Hz to 20 kHz

Distortion 0.016 % typ. @ -16 dBu input

Signal-to-noise ratio: 86 dBu @ +4 dBu, a-weighted

BUTTONS

PAD 20 dB

Ø (phase inversion) 180°

PHANTOM power +48 V

CONTROLS

INPUT GAIN +26 dB to +60 dB

LOW CUT 15 to 360 Hz

OUTPUT LEVEL -oo dB to +10 dB

POWER SUPPLY

Mains connection external power supply, 9 V~ / 750 mA

Mains voltage

USA/Canada 120 V~, 60 Hz

U.K./Australia 240 V~, 50 Hz

China 220 V~, 50 Hz

Europe 230 V~, 50 Hz

Japan 100 V~, 50 - 60 Hz

Power consumption approx. 5 W

DIMENSIONS/WEIGHT

Dimensions (H x W x D) approx. 1.89" (48 mm) x 9.55" (243 mm) x 4.72" (120 mm)

Weight approx. 0.84 lbs. (0,380 kg)

BEHRINGER constantly strives to maintain the highest quality standards. Modifications may be made, if necessary, without prior

notice. The specifications and appearance of the equipment may therefore differ from those listed or illustrated.

MIC800

MINIMIC MIC800

Technicalspecificationsandappearancesubjecttochange without notice. Theinformation contained

herein is correct at the time of printing. The names of companies, institutions or publications pictured

or mentioned and their respective logos are registered trademarks of their respective owners. Their

use neither constitutes a claim of the trademarks by BEHRINGER®nor affiliation of the trademark

owners with BEHRINGER®. BEHRINGER®accepts no liability for any loss which may be suffered by

anyperson who relieseitherwholly or inpart uponanydescription, photograph orstatement contained

herein. Colours and specification may vary slightly from product. Products are sold through our

authoriseddealers only.Distributors and dealersare not agentsof BEHRINGER®and have absolutely

no authority to bind BEHRINGER®by any express or implied undertaking or representation. No part

of this manual may be reproduced or transmitted in any form or by any means, electronic or

mechanical, including photocopying and recording of any kind, for any purpose, without the express

written permission of BEHRINGER Spezielle Studiotechnik GmbH. BEHRINGER®is a registered

trademark.

Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide II, Germany.

Tel. +49 2154 9206 0, Fax +49 2154 9206 4903
