Beko LRP 1685 X Manuale utente

Tall Larder Fridge LRP 1685 X

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in a 1st-class

manufacturing facility and checked under the most meticulous quality control

procedures, will provide you with years of good service.

For this, we recommend you to carefully read the entire manual of your

product before using it and keep it at hand for future reference.

This manual

 Will help you use your appliance quickly and safely.

 Read the manual before installing and operating your product.

 Follow the instructions, especially those for safety.

 Keep the manual in an easily accessible place as you may need it later.

 Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information or useful usage tips.

AWarning against dangerous conditions for life and property.

BWarning against electric voltage.

1 Your refrigerator 4

2 Warnings 5

Electrical requirements........................... 7

Warning! This appliance must be

earthed.......................................................... 7

Energy saving tips.....................................8

Compliance with WEEE Directive and

Disposing of the Waste Product: .......9

Compliance with rohs directive: .........9

Package information................................9

3 Installation 11

Transportation Instructions................ 11

Installation Instructions ....................... 11

Reversing The Doors .............................14

4 Before operating 16

Starting........................................................16

5 Using your freezer 17

6 Maintenance and

cleaning 19

7 Do’s and Don’ts 20

8Guarantee Details 21

9 How To Obtain Service 22

C Figures that take place in this instruction manual are schematic and may not

correspond exactly with your product. If the subject parts are not included in the

product you have purchased, then it is valid for other models.

1Your refrigerator

Congratulations on your choice of a Beko quality Appliance which has been

designed to give you service for many years.

1. Indicator panel

2. Butter & Cheese sections

3. Egg tray

4. Adjustable door shelves

5. Bottle shelves

6. Adjustable front feet

7. Chiller

8. Chiller cover and glass

9. Movable shelves

10. Wine cellar OPTIONAL*

2Warnings

 Do not connect your

appliance to the

electricity supply until

all packing and transit

protectors have been

removed.

 If transported

horizontally leave to

stand upright for at

least 4 hours before

switching on to allow

compressor oil to settle

 If you are discarding an

old refrigerator with a

lock or latch fitted to the

door, disable the lock/

latch, ensure that it is

left in a safe condition to

prevent the entrapment

of young children.

 This appliance must

only be used for its

intended purpose i.e the

storing and freezing of

edible foodstuff.

 Do not dispose of the

appliance on a fire.

At Beko , the care

and protection of our

environment is an

ongoing commitment.

This appliance which is

among the latest range

introduced is particularly

environment friendly.

Your appliance

contains non CFC / HFC

natural substances

in the cooling system

(Called R600a) and

in the insulation

(Called cyclopentane)

which are potentially

flammable if exposed

to fire. Therefore, take

care not to damage,

the cooling circuit /

pipes of the appliance

in transportation

and in use. In case of

damage do not expose

the appliance to fire

or potential ignition

source and immediately

ventilate the room

where the appliance is

situated.

 We suggest you contact

your local authority for

disposal information

and facilities available.

 See Installation

Instructions on page

8 for information on

suitable location.

 To obtain the best

possible performance

and trouble free

operation from your

appliance it is very

important to carefully

read these instructions.

 On delivery, check to

make sure that the

product is not damaged

and that all the parts

and accessories are in

perfect condition.

 Ensure that the

plug remains readily

accessible. Do not use

multiple adapter or

extension cable.

 Failure to observe

these instructions may

invalidate your right to

free service during the

guarantee period.

 Keep ventilation

openings, in the

appliance enclosure or

in the built-in structure,

clear of obstruction.

 Do not use mechanical

devices or other means

to accelerate the

defrosting process,

other than those

recommended by the

manufacturer.

 Do not damage the

refrigerant circuit.

 Do not use electrical

appliances inside

the food storage

compartments of

the appliance, unless

they are of the type

recommended by the

manufacturer.

 We suggest you keep

these instructions in

a safe place for easy

reference.

 This appliance can

be used by children

aged from 8 years and

above and persons

with reduced physical,

sensory or mental

capabilities or lack

of experience and

knowledge if they have

been given supervision

or instruction

concerning use of the

appliance in a safe

way and understand

the hazards involved.

Children shall not play

with the appliance.

Cleaning and user

maintenance shall not

be made by children

without supervision.

 Children should be

supervised to ensure

that they do not play

with the appliance.

Electrical requirements

Before you insert

the plug into the wall

socket make sure that

the voltage and the

frequency shown on the

rating plate inside the

appliance corresponds to

your electricity supply.

Rating label is on the left

hand side of fridge inner

liner.

We recommend that this

appliance be connected

to the mains supply via a

suitable switched

and fused socket. The

appliance must be

positioned so that the

plug is accessible.

Should the mains lead

of the appliance become

damaged or should it

need

Replacing at any time,

it must be replaced by

a special purpose made

mains lead which can

only be obtained from a

Beko authorised service

agent.

Warning! This appliance

must be earthed

If the fitted moulded

plug is not suitable for

your socket, then the

plug should be cut off

and an appropriate plug

fitted. Destroy the old

plug which is cut off as

a plug with bared cord

could cause a shock

hazard if inserted into a

socket elsewhere in the

house.

Themouldedplugonthis

appliance incorporates

a 13 A fuse. Should the

fuse need to be replaced

an ASTABEAB approved

BS 1362 fuse of the same

rating must be used. Do

not forget to refit the

fuse cover. In the event of

losing the fuse cover the

plug must not be used

until a replacement fuse

cover has been fitted.

Colour of the

replacement fuse cover

must be the same colour

as that visible on the pin

face of the plug. Fuse

covers are available from

any good electrical store.

Important! Fitting A

Different Plug

As the colours of the

wires in the mains lead

of this appliance may

not correspond with

the coloured markings

identifying the terminals

in your plug proceed as

follows: (See diagram).

1. Connect the green-

yellow or green (Earth)

wire to the terminal

in the plug marked ‘E’

or with the symbol

or coloured green and

yellow or green.

2.Connect the blue

(Neutral) wire to the

terminal in the plug

marked ‘N’ or coloured

black.

3.Connect the brown

(Live) wire to the

terminal in the plug

marked ‘L’ or coloured

red.

With alternative plugs

a 13 A fuse must be

fitted either in the plug

or adaptor or in the main

fuse box. If in doubt

contact a qualified

electrician.

Energy saving tips

1. Ensure your appliance

is installed in a well

ventilated area.

2.Ensure the time

between buying chilled/

frozen food and placing

them in your appliance

is kept at minimum,

particularly in summer.

We recommend you use

a cool bag or a special

carrier bag to carry

perishable food.

3.Do not leave the door (s)

of your appliance open

longer than necessary

and ensure they are

closed properly after

each opening.

FITTED WITH

BS 1362 13A FUSE ALWAYS

FIT BS 1362 REPLACEMENT

CARTRIDGE FUSE

GREEN &

YELLOW

GREEN

BLUE

BLACK

BROWN

RED

22mm.

6mm.

6mm. 32mm.

12mm.

FUSE

CORD GRIP

4.Defrost frozen

food in the fridge

compartment, so that

frozen food acts as an

ice pack to assist cooling

in the fridge.

5.Energy consumption

of this appliance

is measured while

freezer compartment

is loaded without use

of top shelf lid and

the drawers except

the bottom drawer.

It is advised that any

freezer compartment

is loaded without use

of drawers except the

bottom drawer in order

to achieve maximum

loading capacity.

Compliance with WEEE

Directive and Disposing

of the Waste Product:

This product complies

with EU WEEE

Directive

( 2 0 1 2 / 1 9 / E U ) .

Thisproductbears

a classification

symbol for waste

electrical and electronic

equipment (WEEE).This

product has been

manufactured with high

quality parts and

materials which can be

reused and are suitable

for recycling. Do not

dispose of the waste

product with normal

domestic and other

wastes at the end of its

service life. Take it to the

collection center for the

recycling of electrical and

electronic equipment.

Please consult your local

authorities to learn about

these collection centers.

Compliance with rohs

directive:

The product you have

purchased complies

with EU RoHS Directive

(2011/65/EU). It does

not contain hleverful

and prohibited materials

specified in the Directive.

Package information

Packaging materials

of the product are

manufactured from

recyclable materials in

accordance with our

National Environment

Regulations. Do not

dispose of the packaging

materials together

with the domestic or

other wastes. Take

them to the packaging

material collection points

designated by the local

authorities.

Indice

Altri manuali Beko Frigorifero

Beko

Beko CN 136241 X Manuale utente

Beko

Beko B5RCNA365HW Manuale utente

Beko

Beko CSA31036 Manuale utente

Beko

Beko FC140 Manuale utente

Beko

Beko CNG4792VPS Manuale utente

Beko

Beko TFF654APW Manuale del proprietario

Beko

Beko GN162330ZXPN Manuale utente

Beko

Beko BCHA275K4SN Manuale di istruzioni

Beko

Beko CNA365EC3X Manuale utente

Beko

Beko B3RMLNE444HW1 Manuale utente

Beko

Beko SS 140000 S Manuale utente

Beko

Beko CNE520E23ZDX Manuale utente

Beko

Beko TSE1424N Manuale utente

Beko

Beko CSA31020 Manuale utente

Beko

Beko BCSA240K3SN Manuale di istruzioni

Beko

Beko RDNE535E30DZXB Manuale utente

Beko

Beko RCSA365K20W Manuale utente

Beko

Beko RBI 2300 HCA - ANNEXE 713 Manuale utente

Beko

Beko FNE 19906 Manuale utente

Beko

Beko B-735CDA538 Manuale utente

Beko

Beko RCSA330K30WN Manuale di istruzioni

Beko

Beko GN1426234ZDX Manuale utente

Beko

Beko nstallation & operating instructions and washing... Manuale utente

Beko

Beko BCSA240K3S Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Teledyne

Teledyne 6712FR and Istruzioni operative

Matsui

Matsui MTT50W12E Manuale utente
