User Manual

F7D4101ak 8820ak00386

Play

WIRELESS USB ADAPTER

Table Of Contents

Introduction ...............................................1

Benefits of a Home Network.................................... 1

Advantages of a Wireless Network .............................. 2

Placement of your Wireless Networking Hardware for Optimal

Performance................................................. 3

Overview..................................................7

Product Features ............................................ 7

Applications and Advantages .................................. 8

Product Specifications ........................................ 9

System Requirements........................................ 11

Package Contents ........................................... 11

Installing and Setting up the Adapter........................12

A. Installation Process for Windows Vista and 7 .................. 12

B. Installation Process for Windows XP .........................20

Connecting to a Secure Wi-Fi®Network ........................ 27

Troubleshooting ......................................... 28

Technical Support ...........................................34

Information.............................................. 35

FCC Statement.............................................. 35

Belkin International, Inc., Limited 3-Year Product Warranty......... 37

INTRODUCTION

Thank you for purchasing the Belkin Play Wireless USB Adapter.

Now you can take advantage of this great new technology and gain

the freedom to network your home and office computers wirelessly.

This Adapter allows you to connect a notebook or desktop computer

to your network. Please be sure to read through this User Manual

completely, and pay special attention to the section titled, “Placement

of your Wireless Networking Hardware for Optimal Performance.”

Benefits of a Home Network

Your Belkin Home Network will allow you to:

• Share one high-speed Internet connection

with all the computers in your home

• Share resources, such as files, and hard drives among

all the connected computers in your home

• Share a single printer with the entire family

• Share documents, music, video, and digital pictures

• Store, retrieve, and copy files from one computer to another

• Simultaneously play games online, check Internet email, and chat

INTRODUCTION

Advantages of a Wireless Network

 you’ll no longer need a dedicated “computer

room”—now you can work on a networked laptop or

desktop computer anywhere within your wireless range

  Belkin Easy Installation

Wizards make setup simple

 set up and access printers, computers, and

other networking devices from anywhere in your home

  the wide range of Belkin networking

products let you expand your network to include

devices such as printers and gaming consoles

 you can spare the expense and hassle

of retrofitting Ethernet cabling throughout the home or office

  choose from a

wide range of interoperable networking products

INTRODUCTION



Hardware for Optimal Performance

Your wireless connection will be stronger the closer your computer

is to your wireless router (or access point). Typical indoor operating

range for your wireless devices is between 100 and 200 feet. In the

same way, your wireless connection and performance will degrade

somewhat as the distance between your wireless router (or access

point) and connected devices increases. This may or may not be

noticeable to you. As you move farther from your wireless router

(or access point), connection speed may decrease. Factors that

can weaken signals simply by getting in the way of your network’s

radio waves are metal appliances or obstructions, and walls.

If you have concerns about your network’s performance that might

be related to range or obstruction factors, try moving the computer

to a position between five and 10 feet from the wireless router (or

access point) in order to see if distance is the problem. If difficulties

persist even at close range, please contact Belkin Technical Support.

Note: While some of the items listed below can affect network

performance, they will not prohibit your wireless network from

functioning; if you are concerned that your network is not operating

at its maximum effectiveness, this checklist may help.

INTRODUCTION



Place your wireless router (or access point), the central

connection point of your network, as close as possible

to the center of your wireless network devices.

To achieve the best wireless network coverage for your “wireless

clients,” (i.e., computers enabled by Belkin Adapters or Cards):

• Ensure that your wireless router’s (or access point’s)

antennas are parallel to each other, and are positioned

vertically (toward the ceiling). If your wireless router (or

access point) itself is positioned vertically, point the

antennas as much as possible in an upward direction.

• In multistory homes, place the wireless router (or access point) on a

floor that is as close to the center of the home as possible. This may

mean placing the wireless router (or access point) on an upper floor.

• Try not to place the wireless router (or access

point) near a cordless 2.4GHz phone.

2. Avoid Obstacles and Interference

Avoid placing your wireless router (or access point) near devices

that may emit radio “noise”, such as microwave ovens. Other

objects that can inhibit wireless communication can include:

• Refrigerators

• Washers and/or dryers

• Metal cabinets

• Large aquariums

• Metallic-based, UV-tinted windows

• Microwaves

If your wireless signal seems weak in some spots, make sure

that objects such as these are not blocking the signal’s path

between your computers and wireless router (or access point).

INTRODUCTION

3. Cordless Phone Placement

If the performance of your wireless network is impaired after

attending to the above issues, and you have a cordless phone:

• Try moving cordless phones away from the wireless router

(or access point) and your wireless-enabled computers.

• Unplug and remove the battery from any cordless phone that

operates on the 2.4GHz band (check manufacturer’s information).

If this fixes the problem, your phone may be interfering.

• If your phone supports channel selection, change the channel

on the phone to the farthest channel from your wireless network

as possible. For example, change the phone to channel 1 and

move your wireless router (or access point) to channel 11.

(Your channel selection will vary depending on your region.)

See your phone’s user manual for detailed instructions.

• If necessary, consider switching to a

900MHz or 5GHz cordless phone.



In locations where homes or offices are close together, such

as apartment buildings or office complexes, there may be

wireless networks nearby that can conflict with yours. Use the

Site Survey capabilities of your Belkin Wireless Networking

Utility to locate any other wireless networks, and move

your wireless router (or access point) and computers to a

channel as far away from other networks as possible.

Experiment with more than one of the available channels in

order to find the clearest connection and avoid interference

from neighboring cordless phones or other wireless devices.

For more Belkin wireless networking products,

use the detailed Site Survey and wireless channel

information included in your User Manual.

INTRODUCTION

5. Secure Connections, VPNs, and AOL

Secure connections typically require a user name and password, and

are used where security is important. Secure connections include:

• Virtual Private Network (VPN) connections, often

used to connect remotely to an office network

• The “Bring Your Own Access” program from America

Online (AOL), which lets you use AOL through broadband

provided by another cable or DSL service

• Most online banking websites

• Many commercial websites that require a user

name and password to access your account

Secure connections can be interrupted by a computer’s power

management setting, which causes it to “go to sleep.” The simplest

solution to avoid this is to simply reconnect by re-running the

VPN or AOL software, or by re-logging into the secure website.

A second alternative is to change your computer’s power

management settings so it does not go to sleep; however,

this may not be appropriate for portable computers. To

change your power management setting in Windows,

see the “Power Options” item in the Control Panel.

If you continue to have difficulty with Secure Connections,

VPNs, and AOL, please review steps 1–4 in the previous

pages to be sure you have addressed these issues.

These guidelines should allow you to cover the maximum possible

area with your wireless router. Should you need to cover an even wider

area, we suggest the Belkin Wireless Range Extender/Access Point.

For more information regarding our networking products,

visit our website at www.belkin.com/networking

or call Belkin Technical Support.





The Adapter complies with the IEEE 802.11n specification

to communicate with other 802.11n-compliant

wireless devices at up to 300Mbps*.

The Adapter is also compatible with 802.11a/g devices

at 54Mbps as well as 802.11b products at 11Mbps.

The Adapter can operate on the same 2.4GHz

frequency band as 802.11b/g Wi-Fi®products or 5GHz

frequency band as 802.11a Wi-Fi products.

• 2.4GHz or 5GHz band operation

• USB 2.0 interface, for operation in virtually any

computer with a USB 2.0 bus-power port

• WPA, WPA2, 64-bit WEP (Wired Equivalent

Privacy), or 128-bit WEP encryption

• Wireless access to networked resources

• Data rate of up to 300Mbps* (802.11n), 54Mbps

(802.11a/g), or 11Mbps (802.11b)

• Easy installation and use

• LED power and network link/activity indicator



Applications and Advantages

• Wireless roaming with a laptop around the home or

 Offers the freedom of networking without cables

 Provides

immediate high-speed wireless connectivity at home,

work, and hotspot locations without compromising

the use of existing 802.11b/g products

 The Adapter is

backward-compatible with existing Wi-Fi (IEEE 802.11b/g) products

  Enables networking

in buildings with solid or finished walls, or open

areas where wiring is difficult to install

 Adapts easily in offices

or environments that frequently rearrange or change locations

 Provides

the easy and quick, small network installation SOHO users need

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Belkin Adattatore

Belkin

Belkin Dual-Band Wireless A+G USB Network Adapter... Manuale utente

Belkin

Belkin F1DN002A Manuale utente

Belkin

Belkin USB/SCSI Adapter F5U115-UNV Manuale utente

Belkin

Belkin F5U003 Manuale utente

Belkin

Belkin F1D084Eea Manuale utente

Belkin

Belkin F8T014 Manuale utente

Belkin

Belkin BASIC F7D1101 Manuale utente

Belkin

Belkin MIRACAST VIDEO ADAPTER Manuale utente

Belkin

Belkin F5D8051 Manuale utente

Belkin

Belkin F8Z452ea Manuale utente

Belkin

Belkin F9L1103 Manuale utente

Belkin

Belkin F3H1381REVISED Manuale utente

Belkin

Belkin F8T001 Manuale utente

Belkin

Belkin N Wireless Manuale utente

Belkin

Belkin F5U114-MAC Manuale utente

Belkin

Belkin Wireless Gplus Notebook Card Manuale utente

Belkin

Belkin BLUETOOTH WITH XP SERVICE PACK2 Guida rapida

Belkin

Belkin F5U111 Manuale utente

Belkin

Belkin F8T001 Manuale di istruzioni

Belkin

Belkin F8T008 Dimensioni

Belkin

Belkin F8E449 Manuale utente

Belkin

Belkin Powerline AV Networking Adapters Manuale utente

Belkin

Belkin F5U103 Manuale utente

Belkin

Belkin F5D7050 Manuale utente

Manuali Adattatore popolari di altre marche

PCB Piezotronics

PCB Piezotronics 090B274 Manuale utente

Auvidea

Auvidea J20 Manuale del prodotto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuale utente

Akribis

Akribis ITF-21-BISS-MIT Manuale utente

Tenda

Tenda W54U Manuale utente

ROHO

ROHO AGILITY Manuale utente

PROLiNK

PROLiNK WN2001 Manuale utente

Hawking

Hawking HUF2 Manuale utente

Airlink101

Airlink101 AWLC4030 Manuale utente

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuale utente

Philips

Philips SWA4554S/10 Manuale utente

JVC

JVC TS-C9D2B Manuale di istruzioni

NETGEAR

NETGEAR A6100 Manuale utente

D-Link

D-Link DWA-121 Manuale utente

Philips

Philips SWA2037 Manuale utente

Basalte

Basalte 0610-20 Manuale utente

Yealink

Yealink EHS40 Manuale utente

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuale utente
