BenQ GV1 Manuale utente

Digital Projector

Quick Start Guide

Portable Entertainment Series | GV1 V1.04

Projecteur numérique

Guide de démarrage rapide

Gamme de divertissement portable | GV1

Package contents

GV1 Projector Adapter Plug Head USB-C™ Cable Remote Control

USA

AUS CHN

UK EU

Carry Bag Quick Start Guide Regulatory Statements Warranty Card

Digital Projector

Quick Start Guide

Portable Entertainment Series | GV1

Projecteur numérique

Guide de démarrage rapide

Gamme de divertissement portable | GV1

• Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specications are subject to change

without notice.

• Some of the accessories may vary from region to region.

• The warranty card is only supplied in some specic regions. Please consult your dealer for detailed information.

Product Overview

IR Sensor

Focus

Ring

Projection Lens Power

Key

DC-IN Power Jack

USB-C™ Port

Speaker

Switch Mode

Key

Volume

Down [-]

Key

Volume

Up [+] Key

LED Indicators

Scenario Status Power Key Switch Mode Key

LED Behavior Schema LED Behavior Schema

Charging with

Adapter

Battery <20% Red - breathing N/A

Battery 20-60% Yellow - breathing N/A

Battery >60% Green - breathing N/A

Battery 100% Green - solid N/A

Battery Mode

Battery <20% Red - ashing N/A

Battery 20-60% Yellow - solid N/A

Battery > 60% Green - solid N/A

Bluetooth Speaker

Mode

Ready to Pair/Pairing Depends on power status Blue - ashing

Pair successful Depends on power status Blue - solid

System Update

System update in progress Green - ashing Blue - ashing

System updated has failed Red - solid Red - solid

System update is successful and

system is restarting Green - solid Blue - solid

Error

LED Error Yellow - solid Red - ashing

Fan Error Red - solid Red - ashing

Optical Engine Temperature Error N/A Red - solid

Battery Temperature Error N/A Red - ashing

Driver Board Error Red - ashing Red - ashing

The plug head shown may be different depending on region.

Attaching the Plug Head Removing the Plug Head

Powering / Charging the Projector

3”

* : Charge the battery fully to ensure successful OTA update.

• See "LED Indicators" on page 4 for charging behavior for the Power Key/LED Indicator.

• Once the projector is fully charged the adapter can be disconnected.

• For initial power up, press and hold the Power Key/LED Indicator for 3 seconds. To turn off or on the projector after initial power up, simply short-

press the Power Key/LED Indicator.

• For AC/DC adapter, the socket-outlet shall be installed near the equipment and shall be easily accessible.

Adjusting the Projector Angle

15°

max

Adjusting the Focus

Remote Control

Power

Arrow keys

Volume keys

Home

Back

OK button

Turns the projector

on and off (after initial

power up from the

keypad)

Moves the selection

Opens the projector‘s

Settings menu

Enters the Home

menu of the BenQ

Launcher Adjusts the projector’s

volume

Returns to the

previous menu

Conrms the selection

Connecting Devices

Bluetooth Speakers

(On Projector Mode)Wireless AP

Devices with USB-C™

DisplayPort

For Android™ devices

with USB-C™ DisplayPort

USB-C™

Flash Drive

Smartphone, Tablet,

Laptop/PC - Wireless

Connection
