Besiter BST-0802 Manuale utente

( Emergency Product )

Infrared Forehead

Thermometer

User Manual

Model: BST-0802

Please read the product instrucon manual carefully or

purchase and use the contraindicaons or precauons under

the guidance of medical staﬀ. For details, please refer to the

instrucon manual and keep it in a safe place for future reference

Accuracy Body temperature mode：±0.2°C (35°C~42.5°C)

Measuring Distance 3~5CM

Operang ambient

Temperature 10°C~40°C

Operang

Environment humidity ≤80%

Power Supply DC 3V (2 x AA baery）

Auto-oﬀ Funcon 15 S

Dimension 77 x 43 x 150 mm (L x W x H)

N.W 113g (Exclude baery）

Measuring Range Body temperature mode：35°C~42.5°C

I Product descripon

II Technical Parameters

The thermometer consists of a housing, an LCD screen, a sensor and a

control circuit.

Infrared Sensor

-button

+button

Set key

Screen

Trigger

battery cover

handle

buzzer

III Applicaon

The body temperature of the subject is displayed by measuring the heat

radiaon from the forehead.

IV Precauons, contraindicaons, warnings

1. Precauons

(1) Please read this manual carefully before use.

(2) The ambient temperature of this product is 10

°C

to 40

°C

, and the

opmal temperature is 25

°C

(3) Please do not use this product in an environment above 40

°C

or below

°C

(4) Please do not place the product too close to a charged object to avoid

electric shock.

(5) Please do not use this product in an environment with relave

humidity greater than 80%.

(6) Please do not place this product too close to the electromagnec

model (such as radio, mobile phone, etc.).

(7) Please do not expose this product to the sun or near the stove, let alone

expose it to the water.

(8) Do not pile the foundaon or drop the product. Do not use it if it is

damaged.

(9) The hair on the forehead, sweat, hat or scarf will aﬀect the accuracy

of the measurement data.

(10) Please make sure that the measurement distance is not more than 5cm.

(11) In order to obtain accurate, stable and reliable measurement data, this

product should be used indoors for 15~20 minutes when the room

temperature varies greatly.

(12) When the forehead sweats or other reasons cause the forehead

temperature to not normally respond to body temperature, please measure

it from behind the earlobe.

(13) When cleaning is required, please gently wipe the surface of the meter

with alcohol.

(14) In case of problems with the product, please contact the distributor

and do not aempt to repair it by yourself.

2. Contraindicaonst

Body temperature does not have a standard value, please consult your

doctor if you have a fever

3. warning

•Make sure to remove the hair and sweat from your forehead before

measuring.

• Use of this product is not a substute for a doctor's diagnosis

•Contact your distributor if a problem occurs with the product and do

not aempt to repair it yourself.

•The protecve glass outside the LCD frame is very important, it is also

the fragile part of the meter, please be careful to use.

•Do not charge non-rechargeable baeries and do not throw them into ﬁre.

•Please do not expose this product to the sun or put it with water.

V Advice before use

Infrared forehead thermometers have high requirements on the

surrounding environment. The correct method of use is the key to

accurate tesng.

(1)This product is an infrared forehead thermometer that professionally

measures the temperature of the human body. According to the

diﬀerence of human skin, the measured temperature will be diﬀerent.

(2) When the room temperature changes greatly, the infrared frontal

thermometer should be placed in the room for 20 minutes before use.

(3) When the person to be measured comes from a place with a large

diﬀerence in temperature from the measurement environment, they

should stay in the test environment for at least 5 minutes, and wait unl

the temperature is consistent with the environment before measuring.

(4) The environment around the person to be tested must be stable.

Do not test in places with large air ﬂow such as fans and air outlets of air

condioners.

VI Instrucons

1 Quick Use

(1) Insert baeries.

(2) Press the measurement buon to turn on the infrared forehead

thermometer and the display will acvate.

(3) the front end of the thermometer is aligned with the forehead, and

the distance is 3 to 5 cm.

(4) Aer 2 seconds, the prompt sounds, indicang that the measurement

is completed, and the measurement data on the screen can be read.

2 Mode selecon

In the power-on state, press the "Set" key to select the measurement of

body temperature and surface temperature, and the screen will show the

body temperature and surface temperature; press and hold to switch

between "

°C

" and "

F" modes.(The temperature measured in the surface

temperature mode is the surface temperature of the object, and the

temperature measured in the body temperature mode is the human body

temperature.)

3 Memory query

In standby mode, press the "+" key to query the memory upwards, and

press the "-" key to query the memory downwards. A total of 32 sets of

memory can be queried.

(5) Do not use the instrument outdoors or in a place with strong sunlight.

(6) Do not hold the front of the thermometer during measurement.

(7) The measurement site must not be covered by hair. If there is sweat,

please wipe it with a dry towel and measure it later. Otherwise it will aﬀect

the measurement result.

(8) Cold measurement of the forehead of a fever paent, sweang, and

other cooling measures will make the measurement result low, and

measurement should be avoided in this case.

(9) Comparison of diﬀerent temperature measurement methods.

The body temperature measured by diﬀerent temperature measurement

methods will be diﬀerent.

Precauons:

1.When opening the baery cover to replace the baery, pay special

aenon to the polarity of the baery. Misplacement may cause damage

to the product.

2. When not in use for a long me, please remove the baery to prevent the

thermometer from being damaged due to baery leakage.

3. Do not use when the baery is leaking or moldy.

4.Do not place the baery near a ﬁre source or throw it into a ﬁre,

otherwise the baery may explode.

5.Do not store the baery in a high temperature or high humidity environment.

6.To avoid short circuit, do not put the baery together with metal objects

such as coins or keys in the same pocket or other containers that may

short the baery.

VII Baery replacement

The instrument uses a 3V baery. Generally, it can be used connuously for

more than 4,000 mes. When a baery symbol appears on the top of the

screen and ﬂashes, it indicates that the baery is insuﬃcient and the baery

needs to be replaced as soon as possible.

(1)Open the baery cover and replace the baery. Pay aenon to the

correct posion of the posive and negave electrodes. The product is

designed with a baery an-reverse device, even if the baery is installed in

the opposite polarity, it will not cause damage to the product, but will

not work.

(2)Do not use rechargeable baeries. Use disposable baeries. Use alkaline

baeries whenever possible.

(3)When the instrument is not working, the stac current is extremely small,

but when it is not used for a long me, it is recommended to remove the

baery to prevent baery leakage from damaging the product.

VIII Roune maintenance

During the use of the product, please follow the prompts when you ﬁnd the

following condions.

(1)External contaminaon: Wipe the contaminated area with a clean so cloth,

or use coon swabs with medical alcohol Wiping, rubbing with medical

alcohol can also have sterilizaon. Be careful not to add too much water or

alcohol to prevent damage to the inside of the product.

(2) Internal dirt: The lens of the internal probe is an important device. Do not

touch or press with your ﬁngers or other objects, otherwise it will aﬀect

the preparaon of the measured result. When the lens surface is found to

be dirty, wipe the lens surface with a coon swab moistened with 95% or

more absolute alcohol. Tip: Do not use 75% disinfectant alcohol to wipe the

lens (there will be traces of residual water). Do not use other chemical wipes

to wipe the lens (which will cause damage to the lens).

(3)Storage: Keep in a dry and dark place out of direct sunlight.

IX Error message and soluon

FAQ 1: LCD display message "HI"

Answer: Using infrared forehead temperature mer, the

LCD may display the message HI. The analysis shows that

the measurement range is exceeded: 1. The mode is

selected incorrectly; 2. The temperature exceeds 42.5

°C.

The following informaon appears when the message "L0" or "HI" appears:

Reason for the message "L0"

or "HI"

Suggeson

Temperature value is aﬀected

by hair and sweat

Ensure that there are no obstrucons

during temperature measurement

Temperature value is aﬀected

by air ﬂow

Ensure the air is stable during temperature

measurement

The measurement distance is

too far

Pay aenon to measuring distance

(at 3 ~ 5CM)

Enter indoors from low or high

temperature outdoors

Please wait for 10 minutes and wait for the

subject's temperature to adapt to the

measurement environment before

measuring

FAQ 2: LCD display message "L0"

Answer: Using infrared forehead temperature mer, LCD may display

message L0.The analysis shows that it is lower than the measurement range:

1. The mode is selected incorrectly; 2. The temperature is lower than 32

°C

Thank you for using Besiter Products!

We will provide warranty service aer conﬁrming your proof of purchase

according to the warranty terms. Please keep this warranty card properly.

When you apply for repair, please purchase the invoice and warranty card.

In order to get the technical support service in a mely manner, please

contact the distributor of the product you purchased ﬁrst aer

encountering a failure, and we will uniformly guarantee it.

1. For products purchased and sold by Shenzhen Best Technology Co., Ltd.

in mainland China, the warranty period is subject to the date of purchase

cerﬁcate, which is valid for 12 months.

2. During the warranty period, the product sent by our maintenance personnel

determines that the failure occurs under normal use, and free repair will be

provided.

3. During the warranty period, defects in materials and workmanship of the

product will be repaired and replaced free of charge. All replacement parts

belong to our company.

Warranty Policy

Please ﬁll in the following informaon truthfully：

Name

Bought

from

Error

descripon

Bought on

Model#

State

Year Month Date

City County

Tel

Warranty Card

4.During the warranty period, the following condions will not be able to

enjoy the free maintenance service provided by our company:

Surface coang and appearance damage are not covered by the warranty.

Failure or damage caused by the user's incorrect installaon, storage, and

use in accordance with the instrucons of the user.

Failure or damage caused by disassembly by agencies or personnel not

authorized by our company.

Failure or damage due to accidental factors, human reasons, environmental

factors (operaon errors, bumps, handling, unreasonable power supply

voltage, moisture).

Failure or damage caused by force majeure such as natural disasters

(earthquake, ﬁre, tsunami).

Product packaging and product accessories are not covered by the warranty.

5. Our company does not provide any warranty and repair services in the

following cases:

Products not manufactured by our company;

Products not sold by our company in regular channels in mainland China;

the idenﬁcaon of these two types of products shall be determined by our

technicians

For the expired warranty period (with warranty card and shopping invoice),

our company will provide paid repair service.

Important maers

The user must ﬁll in the user informaon column in English with the oﬃcial

ﬁle aer purchasing the product, and stamp the dealer's seal;

When sending the product for repair, the user must present the warranty

card, and the warranty is valid;

The repair service is limited to the aer-sales center of our company, and

does not provide on-site repair services; the two-way freight and

transportaon protecon of the repaired product are your responsibility;

Our company is not responsible for any unlimited joint and several liability

for accidents and accidents, including loss of personnel or property, and only

provides free repair or replacement of products caused by quality problems

to users who purchase products;

Our company reserves the right to interpret the terms of this warranty and

reserves the right to modify these terms without noce.

Packing list

SN Ite Quanty Unit

1IR Thermometer 1 Set

2 User Manual 1 Set

... ... ... ...

A.02

See the boom of the

package

Cerﬁcate of conformity

Aer inspecon, the product

Inspected by

Inspecon date

Made in China

Registrant / Manufacturer Shenzhen Besiter Power Bank Co., Ltd.

Residence /

Producon Address

Building 66, Longwangmiao Industrial Zone,

Baishixia Community, Fuyong Street, Baoan

District, Shenzhen

Service Tel 400 0918 777

Medical equipment

producon permit

Medical Device

Registraon Cerﬁcate

Product technical

requirements number

Manufacturing measuring

instrument license number

Producon date

Use period

Preparaon / revision date February 20, 2020

5 years

see box boom

Indice

Manuali Termometro popolari di altre marche

Delton

Delton 981A Manuale utente

Baker

Baker MM2P Manuale utente

Tarmo

Tarmo 320281 Manuale utente

Citizen

Citizen CTD 504 Manuale utente

TFA

TFA 14.1500 Manuale utente

Vive

Vive DMD1010 Manuale utente

Gotemp

Gotemp THB4002 Manuale utente

GREISINGER

GREISINGER G 1202 Manuale utente

Amprobe

Amprobe TMD-53W Manuale utente

Trotec

Trotec BP10 Manuale utente

Radiance instruments

Radiance instruments RT616 Series Manuale utente

Eurolec

Eurolec IR151 Manuale utente

Scaneo

Scaneo TS42B Manuale utente

Sper scientific

Sper scientific 800043 Manuale utente

Microlife

Microlife NC 200 Manuale di istruzioni

Motorola

Motorola MBP69SN Guida alla configurazione

The MeatStick

The MeatStick The MeatStick Manuale utente

Hama

Hama TH35-A Manuale utente
