Bettcher Whizard 210 Guida
Operating Instructions And Spare Parts List
UNIVERSAL BLADE SHARPENER
MODEL 210
(115 Volt)
For Assistance Contact:
BETTCHER INDUSTRIES, INC.
Post Office Box 336
Vermilion, Ohio 44089
Fax: 440-328-4535
Call: 1-800-321-8763
MANUAL NO. *113985
RE-ISSUED 06/15/2018
TMC # 828
www.bettcher.com
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page i
Information in this document is subject to change without notice.
No part of this document may be reproduced or transmitted in any form or any
means, electronic or mechanical, for any purpose, without the express written
permission of Bettcher Industries, Inc.
Written permission to reproduce in whole or part is herewith granted to the
legal owners of the Whizard® Universal Blade Sharpener Model 210, 115V
which with these Operating Instructions have been supplied.
Operating Instructions in other languages are available on request. Additional
copies of this Operating Instruction is available by calling or writing the local
Representative or by contacting :
BETTCHER INDUSTRIES, INC.
P.O. Box 336
Vermilion, Ohio 44089
U.S.A.
Telephone: 1-440-965-4422
(In the U.S.A.): 1-800-321-8763
Fax: 1-440-328-4535
The Information Provided In These Operating Instructions
Are Important To Your Health, Comfort And Safety.
For Safe And Proper Operation, Read This Entire
Manual Before Using This Equipment.
Copyright 2018 By Bettcher Industries, Inc.
All Rights Reserved.
Original Instructions
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page ii
Table Of Contents
SECTION 1.0 Machine Specifications 1
SECTION 2.0 Designated Use 1
2.1 Recommended Operation 1
2.2 Warning 2
SECTION 3.0 Function 2
3.1 Machine Functions 2
3.2 Safety Recommendations And Warnings 2
SECTION 4.0 Safety Features 3
SECTION 5.0 Ergonomics And Environment 3
SECTION 6.0 Unpacking 4
6.1 Included With Your Machine 4
SECTION 7.0 Installation 6
7.1 Work Station & Lighting 6
SECTION 8.0 Instructions For Operation 6
8.1 Attaching The Blade Holder 6
8.2 Attaching The Steeling Device 7
8.3 Installing Blade Into Blade Holder 7
8.4 Grinder Feed Control 8
8.5 Positioning Grinder To Sharpen Blade 8
8.6 Grinder Wheel 8
8.7 Sharpening The Blade 9
8.8 Lower Grinder After Sharpening & Steeling Blade 11
8.9 Removing The Blade 11
8.10 Check Blade Wear 12
8.11 Fault Detection And Correction 13
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page iii
Table Of Contents
(continued)
SECTION 9.0 Maintenance/Cleaning 14
SECTION 10.0 Spare Parts List
10.1 Cabinet Assembly 16
10.2 Grinder Motor Assembly 18
10.3 Drive Motor Assembly 20
10.4 Blade Holders 22
10.5 Steeling Devices 24
10.6 Grinder Wheels 26
10.7 Bettcher® Whizard® Blade Wear Gauges 27
10.8 Wiring Diagram` 28
SECTION 11.0 About These Operating Instructions 29
SECTION 12.0 Contact Address & Phone 30
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard® Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page 1
SECTION 1.0 Machine Specifications
General Information:
Weight: 45 lbs. (20 Kg)
Overall Size (With Eyeshield): 10” wide x 21” deep x 17.5” high
(254mm) x (534mm) x (445mm)
Power Cord Length: 6 feet
Electrical Specifications:
Grinder Motor: 115 VAC/1/50-60 Hz 1/10 HP 1.5 Amps
8000 RPM
Blade Drive Gear Motor: 115 VAC/1/50-60 Hz 1/50 HP 0.6 Amps
162 RPM
Power Source: 115 VAC / 1 Phase / 60 Hz
SECTION 2.0 Designated Use
2.1 Recommended Operation
The Whizard® Universal Blade Sharpener Model 210 was designed and built
to sharpen only Bettcher Whizard® blades.
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page 2
2.2 Warning
Any use in applications other than those for which the Whizard® Universal
Blade Sharpener Model 210 was designed and built may result in equipment
damage and/or serious injuries.
WARNING
THE MANUFACTURER ASSUMES NO LIABILITY FOR ANY
UNAUTHORIZED DESIGN CHANGES, MODIFICATIONS, OR
USE OF PARTS NOT SUPPLIED BY THE MANUFACTURER
OR
THE USE OF PARTS NOT DESIGNED FOR USE ON
THIS SPECIFIC MODEL, AND INCLUDES CHANGES IN OPERATING
PROCEDURES MADE BY THE OWNER
OR ANY OF HIS PERSONNEL.
FOR SAFE AND PROPER OPERATION, READ THE
ENTIRE MANUAL BEFORE USING THIS EQUIPMENT.
SECTION 3.0 Function
3.1 Machine Function
The Whizard® Universal Blade Sharpener is a precision grinding unit that is
easy to operate and maintain. As with any cutting device in meat packing,
the Whizard® is only as effective as the cutting edge is sharp.
Proper use of this sharpener will eliminate the guesswork as to whether or not
the blade edge is ground to the correct angle and is sharp. A properly
sharpened Whizard® blade will reduce operator fatigue and pay off big in
increased trimming yields.
3.2 Safety Recommendations And Warnings
WARNING
ELECTRICAL SHOCK MAY OCCUR! ALWAYS DISCONNECT
UNIT FROM POWER SUPPLY PRIOR TO SERVICING.
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page 3
3.2 Safety Recommendations And Warnings (Continued)
WARNING
SHARP BLADE MAY CAUSE CUT INJURY!
FOR PROPER PROTECTION OF HANDS, PROTECTIVE
GLOVES SHOULD BE WORN WHEN OPERATING THIS EQUIPMENT
AND DURING THE HANDLING THE BLADES.
WARNING
ELECTRICAL SHOCK MAY OCCUR!
USE ONLY 3-WIRE GROUND TYPE CONNECTOR.
THIS MUST BE CONNECTED TO A PLANT GROUND VIA
A SUITABLE GROUNDED THREE CONDUCTOR RECEPTACLE. AVOID
USE OF THIS MACHINE IN STANDING WATER.
WARNING
EYE INJURY MAY OCCUR!
NEVER OPERATE THIS MACHINE WITHOUT THE EYE SHIELD IN
PLACE AND PROPER EYE PROTECTION WORN.
SECTION 4.0 Safety Features
The Whizard® Universal Blade Sharpener Model 210 is equipped with an eye
shield to deflect grinding particles away from the operator.
SECTION 5.0 Ergonomics And Environment
This equipment should be operated while standing in a comfortable and secure
position.
The noise emission value is less than 75 dB(A).
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page 4
SECTION 6.0 Unpacking
6.1 Included With Your Machine
The following parts and assemblies are included with your Whizard®
Universal Blade Sharpener Model 210 except as noted. Due to the wide
variety of blade sizes and styles, the blade holder (Item 14) and the steeling
device (Item 6) must be ordered separately. Please check when unpacking
and advise your local Bettcher Industries representative if the delivery is
incomplete.
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page 5
6.1 Included With Your Machine (Continued)
Item Number Description
1 Eye Shield
2 Blade Holder Motor Switch
3 Grinder Motor Switch
4 Steeling Device Pin
5 Steeling Device Base
6 Steeling Device (Not Included)
7 Steeling Device Shaft (Included With Item 6)
8 Pedestal Knob
9 Positioner Plate
9A Positioner Arm
10 Positioner Shaft
11 Grinder Pivot
12 Grinder Motor
13 Grinder Wheel
14 Blade Holder (Not Included)
15 Blade Holder Pin (Included With Item 14)
16 Blade Holder Screws
Operating Instructions and Spare Parts Manual
COMPANY CONFIDENTIAL
Operating BETTCHER Whizard®Universal Blade Sharpener Model 210, 115V
Instructions INDUSTRIES, INC. Rev. 05/17/2019
Page 6
SECTION 7.0 Installation
7.1 Work Station & Lighting
Place the universal sharpener on a bench surface of standard working position
height. Appropriate lighting should be available. Head and hands to be kept
at a safe distance from the grinding wheel and blade during operation.
SECTION 8.0 Instructions For Operation
Read Complete Operating Instructions Before Attempting To Sharpen Any Blades.
8.1 Attaching The Blade Holder
Refer to Section 6.1 for item callouts.
The blade holders and steeling devices are labeled to indicate the model
blade(s) they are related to. See Sections 10.2 and 10.3.
CAUTION
THE BLADE HOLDER HAS A PILOT BORE ON THE BOTTOM WHICH LOCATES ON
THE DRIVE SHAFT AND A BORE ON TOP WHICH LOCATES THE BLADE. CARE
SHOULD BE TAKEN NOT TO DAMAGE THESE SURFACES AS WELL AS THE DRIVE
SHAFT. ALWAYS CHECK THAT THESE SURFACES ARE FREE OF DIRT AND DUST
PRIOR TO ASSEMBLY.
First lower the grinder (#12) to its rest position.
Hold the grinder pivot (#11) with your left hand and press in the knob of the
positioner shaft (#10) with your thumb to release the grinder from the
positioner arm (#9A).
Then slowly swing the grinder down until it comes to a stop.
Do not let the grinder drop freely.
COMPANY CONFIDENTIAL
