Billion BIPAC-840 Manuale del proprietario

BIPAC-840

Billion BIPAC-7560

Powerline WLAN

ADSL Router and Adapter

VoIP ADSL Modem/Router

Broadband Router

SHDSL Bridge / Router Wireless ADSL Router

Wireless Client

High-speed Internet Access with SHDSL

The BIPAC-840 complies with SHDSL standards for worldwide deployment and supports symmetric rates of up to

2.3Mbps. It is designed for office users, enabling high-speed Internet connections. User can enjoy SHDSL services

and broadband multimedia applications such as interactive gaming, video streaming and real-time audio much

easier and faster than ever before

High-speed Back-to-back Connectivity

The BIPAC-840 can be configured as RT/COT (client/server) mode for back-to-back applications. With symmetric

transmission auto-detect speed of up to 2.3Mbps, it can offer a cost-effective way for bandwidth-consuming

applications, such as distance learning and video conferencing.

SOHO Firewall Security with DoS

Along with the built-in NAT natural firewall feature, the BIPAC-840 also provides advanced hacker pattern-filtering

protection. It can automatically detect and block Denial of Service (DoS) attacks, such as IP Spoofing, Ping of

Death, etc.

Virtual Private Network (VPN)

The BIPAC-840 supports embedded VPN protocols, including PPTP client and IPSec (IKE, DES and 3DES), for

establishing a private encrypted tunnel over the public Internet to ensure transmission security between two or

more sites.

SHDSL Firewall Bridge/Router

with 4-port Switch

Securely share your high speed SHDSL connection

• Symmetric Transmission Auto-detect Speed of up to 

2.3Mbps

• High-speed Back-to-back Connectivity for Bandwidth-

consuming Applications

• High-speed Internet Access with SHDSL

• SOHO Firewall Security with DoS Prevention

• Virtual Private Network (VPN)

• Web-based Configuration and Management

• Integrated with 4-port Ethernet Switch

• Ideal for office users

ADSL Modem / Router

Feature & Specification

Billion Electric Co., Ltd.

8F, No.192, Sec.2, Chung Hsing Road,

Hsin Tien City, Taipei Hsien, Taiwan

TEL : +886-2-2914-5665

FAX : +866-2-2918-6731,+886-2-2918-2895

E-mail : [email protected]

www.billion.com

Specifications are subject to change without notice.

ATM and PPP Protocols

• ATM Adaptation Layer Type 5 (AAL5)

• Multiple Protocol over AAL5 (RFC 2684, formerly 

RFC 1483)

• Bridged or routed Ethernet encapsulation

• VC and LLC based multiplexing

• PPP over Ethernet (PPPoE)

• PPP over ATM (RFC 2364)

• Classical IP over ATM (RFC 1577)

• OAM F4/F5

Network Protocols and Features

• NAT, static routing and RIP-1/2

• Transparent bridging

• Virtual Server and DMZ

Management

• Web-based GUI for remote and local management

• Embedded Telnet server for remote and local 

management

• Support DHCP server/client

Operating Environment

• Operating temperature: 0 ~ 45ºC

• Storage temperature: -20 ~ 70ºC

• Humidity: 20 ~ 95% non-condensing

SHDSL Compliance

• Compliant with ITU 991.2 standard

• Symmetric auto-detect/manual-selectable rate of up 

to 2.3Mbps

Firewall

• Built-in NAT firewall

• Prevent DoS attacks including IP Spoofing, Land 

Attack, Smurf Attack, Ping of Death, TCP SYN 

Flooding, etc.

• Packet filtering – port, source IP address and 

destination IP address

• URL filtering – string or domain name detection in 

URL string

Virtual Private Network (VPN)

• Embedded IPSec & PPTP client protocols

• IKE key management

• DES and 3DES encryption for IPSec

• L2TP/PPTP/IPSec pass through

Hardware Specification

Physical Interface

• WAN: SHDSL port

• Console: RS-232

• LAN: 4-port 10/100Mbps auto MDI/MDI-X Switch

• Power jack

Physical Specification

• Dimensions: 8.30" x 5.80" x 1.26"

(210mm x 147mm x 32mm)

Power Requirement

• Input: 12V DC, 1A
