2. Installation

1. Locating the Base unit

The Base unit should be placed on a level surface, in a position where:

the telephone line cable will reach your telephone line socket or

extension socket.

it is not close to a sink, bath or shower, or anywhere else where it

might get wet.

it is not close to other electrical equipment - fridges, washing

machines, microwave ovens, TVs, fluorescent lights, etc.

2. Plug the coiled handset cord into the Handset. Plug the other end into

the jack on the left side of the Base unit.

3. Place the Handset in the Base unit.

4. Plug the telephone line cord into the

PHONE LINE jack at the back of the

Base unit. Plug the other end

into a modular wall jack.

5. Lift the Handset and

check for Dial tone in

the earpiece.

Always use the telephone

line cord supplied with your

SpeakEasy 5. Other telephone

line cords may not work.

Installing Backup

batteries

1. Remove the Battery cover and insert

3 X 1.5V AA size alkaline batteries

(not included) into the battery

compartment paying attention to the

polarity marking as shown inside the

compartment.

2. Replace the battery cover until it

clicks into place.

Note: The Caller display will not work without batteries installed.

Warning: Disconnect the telephone

from the telephone line before

changing the batteries.

3. Desk/Wall mount installation

To place the SpeakEasy 5 on a desk, connect

the stand to the bottom of the phone in the

slots near the ringer cover as shown below.

Desk Mount

Insert the rigid clips of the stand into the slots

on the bottom of the phone (near the ringer

cover). Press down firmly until the flexible

clips clicks into place.

To remove the stand, (1) pinch the flexible

clips, (2) pull back the stand, and then (3)

slide up and forward (3) as shown below.

To place the SpeakEasy 5 on a wall, connect

the stand to the bottom of the phone in the

slots near the battery cover as shown below.

Wall Mount

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Desk/Wall mount continue...

Insert the rigid clips of the stand into the slots

on the bottom of the phone (near the battery

cover). Press down firmly until the flexible

clips clicks into place.

To remove the stand, (1) pinch the flexible

clips, (2) pull back the stand, and then (3)

slide up and forward as shown below.

Mark two points on the wall that are 137mm

apart to lay the fixing centers as shown below.

BE CAREFUL to check that there are no

electrical wires hidden in the wall.

Fix two screws (supplied with the unit) at the

marked locations, leaving approximately 7mm

between the wall and the the screw head.

Hang the cradle unit on the screws using the

wall mount slots. You may need to remove the

telephone from the wall and tighten the

screws so that the cradle is securely fixed and

does not wobble. Place the Handset on the

cradle with the parking hook on the cradle

arranged to fit in the parking recess under the

earpiece on the Handset.

4. Setting up your phone

The following section details how to set up your

telephone. Press the MENU button to enter the

Options menu and then use the UP or DOWN

buttons to cycle through the following options:

SET LANGUAGE

SET TIME/DATE

LCD CONTRAST

SET FLASH TIME

EXIT OPTION

Note: The system will time out if you leave

more than 15 seconds between key presses.

With the phone in standby mode:

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP button to go to the language setting.

ÖThe display will show

SET LANGUAGESET LANGUAGE

SET LANGUAGE

3 Press MENU button to confirm.

4 Press UP or DOWN button to select one of the

11 languages: ENGLISH, FRENCH, SPANISH,

GERMAN, ITALY, PORTUGUESE, TURKISH,

DANISH, POLISH, SWEDISH, and DUTCH.

5 Press MENU button to confirm.

6 Continue with programming, or press RECALL

button to return to standby mode.

SET

LANGUAGE

The date and time on your phone can be

synchronized with the local date and time if

you have subscribed to the Caller Display

service from your telephone company. (This

feature is only available for an analogue PSTN

(not ISDN) line).

However, you can set the date and time manually:

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU .

SET TIME/

DATE

Setting up continue...

2 Press UP or DOWN button until the display

shows

SET TIME/DATESET TIME/DATE

SET TIME/DATE

3 Press MENU button to confirm.

ÖThe ‘year’ icon will be blinking.

4 Press UP or DOWN button to set the year.

5 Press MENU button to confirm.

ÖThe ‘month’ icon will be blinking.

6 Press UP or DOWN button to set the month.

7 Press MENU button to confirm.

ÖThe ‘date’ icon will be blinking.

8 Press UP or DOWN button to set the date.

9 Press MENU button to confirm.

ÖThe ‘hour’ icon will be blinking.

10 Press UP or DOWN button to set the hour.

ÖWhen setting the ‘hour’, the ‘AM’ or ‘PM’

icon will automatically turn ON to correspond

the hour time.

11 Press MENU button to confirm.

ÖThe ‘minute’ icon will be blinking.

12 Press UP or DOWN button to set the minute.

13 Press MENU button to confirm the TIME and

DATE setting.

14 Continue with programming, or press RECALL

button to return to standby mode.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

LCD CONTRASTLCD CONTRAST

LCD CONTRAST

LCD

CONTRAST

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Setting up continue...

3 Press MENU button to confirm.

4 Press UP or DOWN button to select your

comfortable display viewing level (1~6). The

default setting is 3.

5 Press MENU button to confirm the LCD

CONTRAST setting.

6 Continue with programming, or press RECALL

button to return to standby mode.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

SET FLASH TIMESET FLASH TIME

SET FLASH TIME

3 Press MENU button to confirm.

4 Press UP or DOWN button to select 100MS

(default), 300MS, or 600MS.

5 Press MENU button to confirm.

6 Press RECALL button to return to standby

mode or wait until the program times out.

SET FLASH

TIME

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

5. Telephone Operation

Ringer volume The Ringer High-Low switch located at the

back of the Base unit allows you to adjust the

volume of the ringer.

- High volume

- Low volume

1 Lift the handset, or press SPEAKERPHONE

button on the Base unit.

ÖCheck for dial tone.

2 Dial the telephone number.

ÖThe display shows the duration of the call in

minutes and seconds.

Using the Pre-dial mode

1 Dial the telephone number.

2 Lift the Handset or press SPEAKERPHONE

button on the Base unit to dial out the

number.

Notes:

When using the Speakerphone, speak clearly

into the Base unit microphone from a distance

of 15 cm (6 in.)

To make a

call

When the phone rings:

Lift the Handset, or press SPEAKERPHONE

button on the Base unit.

ÖThe display shows the duration of the call in

minutes and seconds .

To answer a

call

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.
