Binatone CAPRICE CAPRICE 600 Manuale utente

2. Installation

1. Locating the Base unit

The Base unit should be placed on a level surface, in a position where:

the mains adapter plug will reach an easily accessible 230-V AC

switch mains supply socket - never try to lengthen the mains power cable.

the telephone line cable will reach your telephone line socket or

extension socket.

it is not close to a sink, bath or shower, or anywhere else where it

might get wet.

it is not close to other electrical equipment - fridges, washing

machines, microwave ovens, TVs, fluorescent lights, etc.

2. Plug the coiled handset cord into the Handset. Plug the other end into

the jack on the left side of

the Base unit.

3. Place the Handset in the Base unit.

4. Plug the telephone line cord into the PHONE

LINE jack at the back of the Base unit.

Plug the other end into a

modular wall

jack.

5. Plug the power supply

cord into the POWER

jack at the back of the

Base unit. Plug the

other end to a 230 V

AC, 50 Hz mains

socket, with the switch

on the socket set to

OFF.

6. Switch ON the mains

power at the socket.

7. Lift the Handset and

check for Dial tone

in the earpiece.

Always use the telephone line

cord supplied with your Caprice

600. Other telephone line cords

may not work.

The Caprice 600 Base unit must

be used only with the supplied

mains adapter. Using any other

adapter may damage the unit.

Note: The Base unit

does not require a

battery.

3. Desk/Wall mount installation

To place the Caprice 600 on a desk, connect

the stand to the bottom of the phone in the

slots near the ringer cover as shown below.

Desk Mount

Insert the rigid clips of the stand into the slots

on the bottom of the phone (near the ringer

cover). Press down firmly until the flexible

clips clicks into place.

To remove the stand, (1) pinch the flexible

clips, (2) pull back the stand, and then (3)

slide up and forward (3) as shown below.

To place the Caprice 600 on a wall, connect

the stand to the bottom of the phone in the

slots near the battery cover as shown below.

Wall Mount

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Desk/Wall mount installation continue...

Insert the rigid clips of the stand into the slots

on the bottom of the phone (near the battery

cover). Press down firmly until the flexible

clips clicks into place.

To remove the stand, (1) pinch the flexible

clips, (2) pull back the stand, and then (3)

slide up and forward as shown below.

Mark two points on the wall that are 137mm

apart to lay the fixing centers as shown below.

BE CAREFUL to check that there are no

electrical wires hidden in the wall.

Fix two screws (supplied with the unit) at the

marked locations, leaving approximately 7mm

between the wall and the the screw head.

Hang the cradle unit on the screws using the

wall mount slots. You may need to remove the

telephone from the wall and tighten the

screws so that the cradle is securely fixed and

does not wobble. Place the Handset on the

cradle with the parking hook on the cradle

arranged to fit in the parking recess under the

earpiece on the Handset.

4. Setting up the Caprice 600

The following section details how to set up your

telephone. Press the MENU button to enter the

Options menu and then use the UP or DOWN

buttons to cycle through the following options:

SET LANGUAGE

SET TIME/DATE

SET FLASH TIME

LCD CONTRAST

MESSAGE LENGTH

RINGS TO ANSWER

REMOTE ACCESS

EXIT OPTION

Note: The system will time out if you leave

more than 15 seconds between key presses.

With the phone in standby mode;

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP button to go to the language setting.

ÖThe display shows

SET LANGUAGESET LANGUAGE

SET LANGUAGE

3 Press MENU button to confirm.

4 Press UP or DOWN button to select ENGLISH

(default), FRANCAIS, or ESPANOL.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

SET

LANGUAGE

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

SET TIME/DATESET TIME/DATE

SET TIME/DATE

3 Press MENU button to confirm.

ÖThe ‘year’ icon will be blinking.

SET TIME/

DATE

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

Setting up continue...

4 Press UP or DOWN button to set the year.

5 Press MENU button to confirm.

ÖThe ‘month’ icon will be blinking.

6 Press UP or DOWN button to set the month.

7 Press MENU button to confirm.

ÖThe ‘date’ icon will be blinking.

8 Press UP or DOWN button to set the date.

9 Press MENU button to confirm.

ÖThe ‘hour’ icon will be blinking.

10 Press UP or DOWN button to set the hour.

ÖWhen setting the ‘hour’, the ‘AM’ or ‘PM’

icon will automatically turn ON to correspond

the hour time.

11 Press MENU button to confirm.

ÖThe ‘minute’ icon will be blinking.

12 Press UP or DOWN button to set the minute.

13 Press MENU button to confirm the TIME and

DATE setting.

14 Continue with programming, or press EXIT

button to return to standby mode.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

SET FLASH TIMESET FLASH TIME

SET FLASH TIME

3 Press MENU button to confirm.

4 Press UP or DOWN button to select 100MS

(default), 300MS, or 600MS.

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

SET FLASH

TIME

Setting up continue...

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

LCD CONTRASTLCD CONTRAST

LCD CONTRAST

3 Press MENU button to confirm.

4 Press UP or DOWN button to select your

comfortable display viewing level (1~5). The

default setting is 3.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

LCD

CONTRAST

To set the recording time for ICM and memo

messages of the Answering machine.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

MESSAGE LENGTHMESSAGE LENGTH

MESSAGE LENGTH

3 Press MENU button to confirm.

4 Press UP or DOWN button to select 1, 2, 3,

or 4 minutes. The default setting is 2 minutes.

5 Press MENU button to confirm the MESSAGE

LENGTH setting.

6 Continue with programming, or press EXIT

button to return to standby mode.

MESSAGE

LENGTH

Setting up continue...

Binatone Help Line - 0845 345 9677Binatone Help Line - 0845 345 9677

Binatone Help Line - 0845 345 9677

Calls are charged at Local Call rate.

To set the number of rings before the machine

answers a call;

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

RINGS TO ANSWERRINGS TO ANSWER

RINGS TO ANSWER

3 Press MENU button to confirm.

4 Press UP or DOWN button to select TOLL

SAVER, 2, 3, 4, 5, 6, 7, 8, or 9 rings. The

default setting is 6.

ÖUse ‘TOLL SAVER’ when checking your

Caprice 600 for messages from a remote

location using long distance service or from a

pay phone. The Answering machine responds

after the 2nd ring only if you have a new

message waiting. If there are no new messages,

the phone will answer after the 4th ring. You

can then hang up after the 3rd ring to avoid

paying for the call.

5 Press MENU button to confirm.

6 Continue with programming, or press EXIT

button to return to standby mode.

RINGS TO

ANSWER

The REMOTE ACCESS is a three-digit code

you need if you call away from home to check

your messages. The default is 321. You can

change it to any three digits you want.

1 Press MENU button.

ÖThe display shows

OPTIONS MENUOPTIONS MENU

OPTIONS MENU

2 Press UP or DOWN button until the display

shows

REMOTE ACCESSREMOTE ACCESS

REMOTE ACCESS

3 Press MENU button to confirm.

ÖThe first digit of the code will be blinking.

4 Press UP or DOWN button to set the first digit

of the REMOTE ACCESS code.

REMOTE

ACCESS
