Birch BD-408e Manuale utente

NOTICE

This equipment has been tested and found comply with the limits for

a Class A digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interface when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in accordance

with the instruction manual, may cause harmful interface to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interface in which case the user will be

required to correct the interface at his own expense.

All brand and trademark are belonged to their respective owner.

Specifications are subject change without notice.

This device complies with part 15 of the FCC

Rules. Operation is subject to the following two

condition: (1) This device may not cause

harmful interface, and (2) This device must

accept any interface received, including

Interface that may cause undesired operation.

Operation Manual

Index

1Instroduction«««««««««««««««««««««««««««««««««««««««««««««««« 4

Installation«««««««««««««««««««««««««««««««««««4

Recommended Steps«««««««««««««««««««« 4

Configuration Flowchart««««««««««««««««« 5

String Output Flowchart««««««««««««««««««5

Default Setting««««««««««««««««««««««««««««« 6

Manual Label Layout««««««««««««««««««««« 7

Frequent Question«««««««««««««««««««««««« 8

2Interface««««««««««««««««««««««««««««««««««««««««««««««««««««««« 10

Host Interface«««««««««««««««««««««««««««««« 10

Keyboard Wedge«««««««««««««««««««««««««« 11

RS-232C«««««««««««««««««««««««««««««««««««««15

Wand Emulation (Linker or Pen)«««««««18

OCIA««««««««««««««««««««««««««««««««««««««««« 20

3System Control««««««««««««««««««««««««««««««««««««««««««««« 21

4Code Option««««««««««««««««««««««««««««««««««««««««««««««««« 26

UPC-A««««««««««««««««««««««««««««««««««««««««26

UPC-E««««««««««««««««««««««««««««««««««««««««28

EAN-13 (ISBN/ISSN) «««««««««««««««««««« 30

EAN-8«««««««««««««««««««««««««««««««««««««««« 32

CODE-39 (CODE-32) ««««««««««««««««««« 34

Interleaved 2 of 5 (Odd S-code) «««««« 36

Industrial 2 of 5«««««««««««««««««««««««««««««38

Matrix 2 of 5«««««««««««««««««««««««««««««««« 40

China Post 2 of5«««««««««««««««««««««««««« 42

Codabar/NW7«««««««««««««««««««««««««««««« 44

Code-128««««««««««««««««««««««««««««««««««« 46

Code-93««««««««««««««««««««««««««««««««««««« 48

Code-11««««««««««««««««««««««««««««««««««««« 50

MSI/Plessey«««««««««««««««««««««««««««««««« 52

UK/Plessey««««««««««««««««««««««««««««««««« 54

Telepen«««««««««««««««««««««««««««««««««««««« 56

IATA«««««««««««««««««««««««««««««««««««««««««« 58

5String Format««««««««««««««««««««««««««««««««««««««««««««««««60

Preamble/Postamble««««««««««««««««««««« 60

Prefix/Suffix««««««««««««««««««««««««««««««««« 61

Character Insertion««««««««««««««««««««««««62

Other Control««««««««««««««««««««««««««««««« 64

6Cable Type««««««««««««««««««««««««««««««««««««««««««««««««««««66

7Test Chart««««««««««««««««««««««««««««««««««««««««««««««««««««« 68

8ASCII Code/Hexdecimal Table«««««««««««««««««««««««71

Installation

1) First of all, you must make sure that the power is disconnected

form your equipment before connecting the scanner. Beside, you

also have to check the cable connector of the scanner match

your equipment interface correctly.

2) Boot up your computer after connecting the scanner with your

equipment, the scanner will make a long music and light the LED,

above scanner to indicate a successful power on. Trigger the

button, the scan line in front of scanner will active. Now you can

start to set programming optimal usage.

If any of the above operation is not right, turn off the power

immediately and check any improper connections. Go through all

abovestepsagain.

Recommened Steps

When the required settings have been configured, all settings

are stored in non volatile memory of scanner after reading EXIT

label. There are recommended steps as follows.

1) Set right host interface for your scanner at

10.

(The scanner is in factory default as bold label)

2) Set interface to optimize protocol of scanner with your host in

Charter 2.

3) Set system control of scanner, such as specific adjustments

double confirm, power saving, indicator and scanning mode

which you prefer usage in Chapter 3.

4) Set code option of scanner for your usage in Chapter 4. You must

make sure to enable the symbology first, then Min./Max. code

length, code ID checksum and truncate digits are also convered.

5) Set string format of the scanner, such as preamble, postamble,

prefix, suffix, code ID and code name transmission for your

application in Chapter 5.

If any of the error step is processing, scanner will generate a 5

wanrrying beeps to indicate an invaild setting. You have to take care

this matter and set correctly again.

If still not work properly. Please contact with dealer.

Operation Manual

Configuration Flowchart

String Output Flowchart

Preamble

Prefix

Code Name

Code ID

Code Data

CodeLength

Suffix

Postamble

Enter

Programming

Mode

Finish ASCII

Code or Decimal

Value Setting

Select Function

Label

Interface Default

Exit & Interface Default

Function

PROGRAM

Decimal

(10'sValue)

Hexdecimal

(High Byte)

Decimal

(1'sValue)

Hexdecimal

(Low Byte)

SET

EXIT

ABORT

VERSION DATE

SETTING LIST

DEFAULT

Prefixor

Suffix

Only

Set ASCII Code

Set Decimal Value

Exit With Save

Exit Without Save

Exit & Default

Exit & Version List

Exit & Setting List

Introduction

Default Setting

Length TruncateCode

Type

Read

Enable

Min.

Max.

Leading

Ending

Code

UPC-A

- - 0 0 A

UPC-E

- - 0 0 E

EAN-13

- - 0 0 F

EAN-8

- - 0 0 FF

Code-39

0 0 0 0 M

Interleaved 2 of 5 6 0 0 0 I

Industrial 2 of 5 4 0 0 0 H

Matrix 2 of 5 4 0 0 0 G

China Post 2 of 5 11 11 0 0 J

Codabar/NW7

4 0 0 0 N

Code-128

0 0 0 0 K

Code-93 4 0 0 0 L

Code-11 4 0 0 0 O

MSI/Plessey 4 0 0 0 P

UK/Plessey 4 0 0 0 R

Telepen 4 0 0 0 S

IATA 4 0 0 0 Q

Adjustment Value Result

Beep Loudness 05 Level 5

Beep Tone 24 2.4 KHz

Beep Duration 06 60mSec

Beep Tone1 12 1.2 KHz

Beep Duration1 06 60mSec

Stand-byTime 15 15 Sec

Active Time 20 200mSec

Sleep Time 20 200mSec

Good-read Delay 50 500mSec

Double Confirm Times 01 Once

Inter-char. Delay 01 1mSec

Transmit Delay 00 0mSec

Response Delay 30 3 Sec

Add-on Wait Time 50 500mSec

Margin Delay 10 100mSec

Preamble Data1 0016 <NULL>

Preamble Data2 0016 <NULL>

Postamble Data1 0D16 <CR>

Postamble Data2 0A16 <LF>

Prefix Data(All Datas) 0016 <NULL>

Suffix Data (All Datas) 0016 <NULL>

Add-on Insertion (All Datas) 0016 <NULL>

Insertion1-4 (Position & All Datas) 0016 <NULL>

Concatenation Data 2916 <GS>

Operation Manual

Manual Label Layout

The scanner must be set by reading the barcode labels in

manual. The discription of label is as follows.

The factory default settings are indicated by bold symbols.

Disable DZA

*DZA*

Enable DZB

*DZB*

Spare Function

Disable DYA

*DYA*

Enable DYB

*DYB*

Truncate

Leading BAO

*BAO*

(Range:0010-1510)

Truncate Ending BAP

*BAP*

(Range:0010-1510)

Code ID AAA

*AAA*

(Range:0016-FF16 ASCIICode)

Specific Adjustments

Truncate Leading Zero

EXIT

UPC-A

*/$%END*

Code Option

Truncate Leading / Ending: The

leading or ending digits of barcode

data characters can be truncated

when these values are set to non

zero. It will be read nothing else only

beeps when the truncate value is

more than barcode data digits or the

value of Truncate Leading is overlap

with the Ending. The maximum value

of Truncate digits is 15.

Code ID: A Code ID is a character

Section

Title

Exit

Program

Command

For RS-232C

Selection

Label

Default

Setting

Selection

Description

Chapter

Number

Chapter

Title

Page

Number

Function

Title

Adjustment

(ASCII Code or

Decimal Value)

Group

Line

Selection

Label

Range

Description

Function

Description

Introduction

Frequent Question

Q: Why scanner block the keyboard operation?

A: Check the cable connection with your equipment, then turn power

on again.

Q: If scanner has a good read beep but nothing transferring

after read a label.

A: Using the SETTING LIST at

10 to show what current setting of

scanner is, or reset to Default, (or select right Interface default if

scanner to be change another interface used), then re-program

scanner again.

Q: If scanner dosen't need an Enter character addition after

each barcode label transmission.

A: Refer to postamble transmission at

60, then set Disable.

Q: If scanner needs to read single digit code.

A: Refer to Min. code length of code option use "01" in Chapter 4 for

single code readable.

Q: If scanner isn't able to discriminate an unknown label, but

read manual very well.

A: Refer to code name at

64 to set Enable, read a barcode label,

then you will know what symbology is read. Beside, it maybe

need to verify checksum. Refer to verify checksum of code option

in Chapter 4, and set Enable.

Q: If scanner transfers character very slow or loses some

characters on screen in keyboard interface after reading a

label.

A: You may set caps lock to be Alt+Keypad at

11. Otherwise, it

maybe mis-match of transmission rate, therefore, you can adjust

an appropriate Inter-char. Delay to match your equipment. See

11.

Q: If scanner want to read a label as function key for your

apprication.

A: Refer to function key simulation at

11 and set Enable, then

scanner can transmit a code as function key. It is used for

keyboard interface only. Beside, you must make sure that a label

is encoded as function key, and its ASCII code is from 0016 to

1F16 You can refer to ASCII code table at

71.

Operation Manual

Q:Could I change scanner into different type interface directly?

A: You can change factory interface default for other type interface.

By plug different cable, program scanner and set right interface to

exit, then the scanner will be change to another interface.

However, you must make sure what cable you need. Refer Cable

Type to /66, 67.

Q: How to configure scanner via RS-232C?

A: Next to the selection description, you will find a frame command,

such as AAB. These commands can be sent to scanner with

RS-232C interface. You must make sure that scanner is the same

protocal as your equipment of RS-232C, and light source of

scanner has been actived by pressing button.

Example Beep Loudness Level "10", Good-read Beep "Enable"

To configure the reguired commands proceed as follows:

Send as: <ESC>(1B16) ïCommand(s)ï<CR>(0D16)

Send <ESC>ïBACï%01ï%00ï%OKïCEBï<CR>

︸︸︸︸︸

Beep 1 0 SET Good-read

Londness Level Beep Enable

Call to the dealer if scanner dose not work properly.

Introduction

You can change factory

interface default for other type

interface. By plug different

cable, program scanner and

set right interface to exit, then

the scanner will be change to

another interface. However,

you must make sure what

cable you need. Refer Cable

Type to

66, 67.

DEFAULT: All settings are

reset as bold label, but

exclude interface setting.

VERSION DATE: You can get

the software date of decoder

on screen. It is important for

maintanace.

SETTING LIST: First it is

recommended that you need

to excute a text editor

program (such as PE2 and

Word) for keyboard interface,

or excute a terminal program

(such as Hyper Terminal) for RS-232. Then scanner will transmit

current settings on screen.

ABORT: If you have a mis-setting or want to skip this current

configuration during you are programming, using this function, all

front settings are aborted before you set EXIT to finish

programming.

Programming will be finished while each label of miscellany is

read.

Keyboard Wedge

*/$%C00*

RS-232C

*/$%C01*

WAND EMULATION

*/$%C02*

OCIA

*/$%C03*

Spare Interface

*/$%C04*

Interface Default

DEFAULT (without Interface)

*/$%DEF*

VERSION DATE

*/$%VER*

SETTING LIST

*/$%LST*

ABORT

*/$%ESC*

Miscellany

PROGRAM

*/$%STR*

Host Interface

Operation Manual

Indice

Altri manuali Birch Lettore di codici a barre

Birch

Birch CD-108E Manuale utente

Birch

Birch BP-8410M Manuale utente

Birch

Birch FD-011WU Manuale utente

Birch

Birch BP-525D Manuale utente

Birch

Birch BP-846M+ Manuale utente

Birch

Birch BX-211 Manuale utente

Manuali Lettore di codici a barre popolari di altre marche

POSMicro

POSMicro Datalogic PowerScan D7100 Manuale utente

Marson

Marson MT780 Guida rapida alla configurazione

NCR

NCR RealPOS Manuale utente

Motorola

Motorola SE3300 Guida rapida alla configurazione

Element

Element P130BT Manuale utente

Motorola

Motorola Symbol LS3008 Manuale di installazione e funzionamento

Meec tools

Meec tools OBD-II / VAG Manuale utente

SICK

SICK CLP 100 Manuale utente

Royal Tag SA

Royal Tag SA I-Read Manuale utente

Welch Allyn

Welch Allyn IMAGETEAM 3800 Manuale utente

Meteor

Meteor 8310 Manuale utente

Denso

Denso BHT-500B Manuale utente

Datalogic

Datalogic Heron HD3130 Manuale utente

Motorola

Motorola MP6000 Istruzioni di montaggio

Newland

Newland NLS-HR15-BT Manuale utente

ARTDEV

ARTDEV AS-1310 Manuale utente

Aopos

Aopos AS290 Manuale utente

ENS

ENS 367-5455 Manuale utente
