Black & Decker BFF16B Manuale utente

Page 1

INSTRUCTION MANUAL

16 IN. FLOOR FAN

CATALOG NUMBER

BFF16B

Thank you for choosing BLACK+DECKER!

PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY

REASON.

If you have a question or experience a problem with your BLACK+DECKER purchase, go

to www.blackanddecker.com/instantanswers

If you can’t find the answer or do not have access to the Internet, call

844-299-0879 from 9:00 a.m. to 7:00 p.m. EST Mon. - Fri. to speak with an agent. Please

have the catalog number available when you call.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Page 3

CONTENTS

SAFETY INFORMATION

Important Safety Instructions..........................................................................................................................................4-5

Electrical Requirements....................................................................................................................................................... 5

SET UP & USE

Parts & Features .......................................................................................................................................................................6

Operation Of Your Fan ........................................................................................................................................ 7

Replacing the Fuse................................................................................................................................................. 8

CLEANING & CARE...............................................................................................................................................8

TROUBLESHOOTING & WARRANTY

Before You Call For Service................................................................................................................................ 9

Customer Service.................................................................................................................................................... 9

Troubleshooting .................................................................................................................................................... 10

Limited Warranty.....................................................................................................................................................................11

Thank you for purchasing our

BLACK+DECKER product. This

easy-to-use manual will guide you

in getting the best use of your fan.

Remember to record the model and

serial numbers. They are on a label

on the rear.

Staple your receipt to your manual.

You will need it to obtain warranty service.

Model number

Serial number

Date of purchase

PRODUCT REGISTRATION

Page 4

1. READ ALL INSTRUCTIONS BEFORE USE

2. Never insert ngers, pencils, or any other object through the grill

when fan is running

3. Disconnect fan when moving from one location to another.

4. Disconnect fan when not in use and before cleaning and servicing.

5. To protect against risk of electrical shock, do not immerse fan in

water or any other liquid.

6. Do not let cord hang over edge of table or counter.

7. Be sure fan is on a stable surface when operating to avoid

overturning.

8. Do not use fan in window. Rain may create electrical hazard.

9. Close supervision is necessary when any appliance is used by or near

children.

10. This product employs overload protection (fuse). A blown fuse

indicates an overload or short-circuit situation. If the fuse blows,

unplug the product from the outlet. Replace the fuse as per the user

manual (follow product marking for proper fuse rating) and check

the product. If the replacement fuse blows, a short-circuit may be

present and the product should be discarded or returned to an

authorized service facility for examination and/or repair.

11. Do not operate any fan with a damaged cord or plug. Discard fan or

return to an authorized service facility for examination and/or repair.

12. Do not run cord under carpeting. Do not cover cord with throw rugs,

runners, or similar coverings. Do not route cord under furniture or

appliances. Arrange cord away from trafc area and where it will not

be tripped over.

13. To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan

With Any Solid-State Speed Control Device.

14. Do not use outdoors.

IMPORTANT SAFETY INSTRUCTIONS

SAFETY INFORMATION

WARNING

WARNING - Hazards or unsafe

practices which COULD result in

severe personal injury or death

DANGER

DANGER - Immediate hazards

which WILL result in severe

personal injury or death

CAUTION

CAUTION - Hazards or unsafe

practices which COULD result in

minor personal injury

WARNING

When using electrical appliances, basic safety precautions

should be followed, including the following

Page 5

SAFETY INFORMATION

READ AND SAVE THESE

INSTRUCTIONS

HOUSEHOLD USE ONLY

ELECTRICAL REQUIREMENTS

This appliance has a polarized plug (one blade is wider than the other). To reduce the

risk of electric shock, this plug is intended to t into a polarized outlet only one way.

If the plug does not t into the outlet, reverse the plug. If it still does not t, contact a

qualied electrician. Do not attempt to modify the plug in any way.

DOUBLE INSULATION

Double insulated appliances are constrcuted througout with two separate layers

of electrical insulation or one single layer of reinforced insulation between the user

and the appliance’s electrical system. Products built with this insulation system are

not intended to be grounded. As a result, this appliance is equipped with a two-

prong plug which permits it to be used without concern for maintaining a ground

connection.

NOTE: Double insulation does not take the place of normal safety precautions when

operating this appliance. The secondary insulation system is for protection

against injury resulting from a possible failure of the primary insulation within

the product.

CAUTION: WHEN SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS.

POWER SUPPLY CORD

1. If the power supply cord is too short, do not use an extension cord. Have a qualiﬁed

electrician or service person install an outlet near the appliance.

Page 6

SET UP & USE

PARTS & FEATURES

FRONT

BACK

Base

Front Guard

Tilt Adjustment Knob

Speed Control

Page 7

SET UP & USE

OPERATION OF YOUR FAN

SPEED CONTROL

The speed control is located on the rear side of the fan in the center of the grill. Turn

the knob to move from OFF to either HIGH MEDIUM or LOW speed.

Turn the knob to the OFF position at any time to power off the unit.

WARNING: To avoid injury when directing airow, do not rest hands on base while

pushing on guards.

Page 8

SET UP & USE

REPLACING THE FUSE

CAUTION: Turn off fan and disconnect plug from power source before replacing

fuse.

• Open fuse cover located on the side of the power cord plug by sliding it toward

the plug blades

• Remove fuse carefully by taking a small tool and slowly prying out one end. Once

you have one end out, slowly pry out the other end.

• To avoid the risk of re, replace only with 2.5 Amp, 125V fuse.

• Close fuse cover by sliding cover toward the top of the plug.

CAUTION: Risk of re. Do not replace attachment plug. Contains a safety device

(fuse) that should not be removed. Discard product if the attachment

plug is damaged.

CLEANING AND MAINTENANCE

WARNING: Be sure to turn off fan and unplug from the electrical supply source

before cleaning.

Be sure not to get water or any other liquid inside the motor.

Do not disassemble the fan for cleaning.

• To ensure adequate air circulation to the motor, keep vents at the rear of the

motor housing free of dust, debris, etc. Unplug fan before using a vacuum cleaner

to clean these vents. Do not disassemble the fan motor to clean.

• Plastic parts of the fan should be cleaned with mild soap and a damp cloth or

sponge. Rinse with clean water to remove any soapy lm residue.

• Be sure not to get water or any other liquid inside the motor.

Fuse

Fuse cover

Page 9

TROUBLESHOOTING & WARRANTY

BEFORE YOU CALL FOR SERVICE

IF THE APPLIANCE FAILS TO OPERATE:

A) Check to make sure that the appliance is plugged in securely. If it is not, remove

the plug from the outlet, wait 10 seconds and plug it in again securely.

B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to

be operating properly, test the outlet with another appliance.

IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED

TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE APPLIANCE YOURSELF.

IMPORTANT

DO NOT RETURN THIS PRODUCT TO THE STORE

If you have a problem with this product, please contact the

BLACK+DECKER Customer Satisfaction Center at

844-299-0879 or [email protected].

DATED PROOF OF PURCHASE, MODEL # AND SERIAL #

REQUIRED FOR WARRANTY SERVICE

Page 10

TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY

Appliance does not turn on

Appliance is not plugged in Check that appliance is

plugged into a working outlet

The fuse cover may be open Disconnect the plug from

outlet and close the cover of

the fuse.

Troubleshoot your problem by using the chart below. If the appliance still does not

work properly, contact W Appliance Co. customer service center or the nearest

authorized service center. Customers must never troubleshoot internal components.

SPECIFICATIONS

BFF16B

• Unit Dimensions (W x D x H): 20.55” x 6.38” x 19.17”

• Net Weight: Approx. 5.5 lb

TROUBLESHOOTING & WARRANTY
