Black Box SW614A Manuale utente
JUNE 2001
SW614A
SW616A
SW617A
SW619A
FREE tech support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746.
Mailin address: Black Box Corporation, 1000 Park Dr., Lawrence, PA 15055-1018
World-Wide Web: www blackbox com • E-mail: info@blackbox com
© Copyri ht 2001. Black Box Corporation. All ri hts reserved.
Customer Support Information:
1
THE SERVSWITCH™ FAMILY
Welcome to the ServSwitchTM Family!
Thank you for purchasing a BLACK BOX®ServSwitch™Brand KVM switch! We
appreciate your business, and we think you’ll appreciate the many ways that your
new ServSwitch keyboard/video/mouse switch will save you money, time, and
effort.
That’s because our ServSwitch family is all about breaking away from the
traditional, expensive model of computer management. You know, the one-size-
fits-all-even-if-it-doesn’t model that says, “One computer gets one user station, no
more, no less.” Why not a single user station (monitor, keyboard, and mouse) for
multiple computers—even computers of different platforms? Why not a pair of
user stations, each of which can control multiple computers? Why not multiple
user stations for the same computer?
With our ServSwitch products, there’s no reason why not. We carry a broad line
of robust solutions for all these applications. Do you have just two PCs, and need
an economical alternative to keeping two monitors, keyboards, and mice on your
desk? Or do you need to share dozens of computers, including a mix of IBM®PC,
RS/6000®, Apple®Macintosh®, Sun Microsystems®, and SGI®compatibles among
multiple users with different access levels? Does your switch have to sit solidly on a
worktable and use regular everyday cables? Or does it have to be mounted in an
equipment rack and use convenient many-to-one cables? No matter how large or
small your setup is, no matter how simple or how complex, we’re confident we
have a ServSwitch system that’s just right for you.
The ServSwitch™family from Black Box—the one-stop answer for all your KVM-
switching needs!
*
This manual will tell you all about your new Multi-Head ServSwitch™, including
how to install, operate, and troubleshoot it. For an introduction to the Switch, see
Chapter 2. The Multi-Head ServSwitch product codes covered in this manual are:
SW614A SW616A
SW617A SW619A
This manual also includes information about the Remote-Control Module
accessory, which has its own installation and operation sheet. The Remote-Control
Module product codes mentioned in this manual are:
KV6REM KV6REM-25 KV6REM-50 KV6REM-75
2
MULTI-HEAD SERVSWITCH™
TRADEMARKS USED IN THIS MANUAL
BLACK BOX and the logo are registered trademarks, and ServSwitch and
Multi-Head ServSwitch are trademarks, of Black Box Corporation.
Apple and Macintosh are registered trademarks of Apple Computer, Inc.
Compaq and Alpha are registered trademarks of Compaq Computer Corporation.
Hewlett-Packard, HP, and Vectra are registered trademarks of Hewlett-Packard.
IBM, PC/AT, PS/2, RS/6000, and ThinkPad are registered trademarks, and
PC/XT is a trademark, of International Business Machines Corporation.
Microsoft, IntelliMouse, MS-DOS, Windows, and Windows NT are registered
trademarks or trademarks of Microsoft Corporation in the United States and/or
other countries.
Sun Microsystems is a registered trademark of Sun Microsystems, Inc. in the
United States and other countries.
Any other trademarks mentioned in this manual are acknowledged to be the property of the
trademark owners.
3
FCC/IC STATEMENTS
FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA
RADIO-FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested
and found to comply with the limits for a Class A computing device in accordance
with the specifications in Subpart J of Part 15 of FCC rules, which are designed to
provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a
residential area is likely to cause interference, in which case the user at his own
expense will be required to take whatever measures may be necessary to correct the
interference.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Shielded cables must be used with this equipment to maintain compliance with
radio-frequency energy-emission regulations and ensure a suitably high level of
immunity to electromagnetic disturbances.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le
brouillage radioélectrique publié par Industrie Canada.
4
MULTI-HEAD SERVSWITCH™
EUROPEAN UNION DECLARATION OF CONFORMITY
This equipment has been tested and found to comply with the limits for a class B
computing device in accordance with the specifications in the European standard
EN55022. These limits are designed to provide reasonable protection against
harmful interference. This equipment generates, uses and can radiate radio
frequency energy and if not installed and used in accordance with the instructions
may cause harmful interference to radio or television reception. However, there is
no guarantee that harmful interference will not occur in a particular installation. If
this equipment does cause interference to radio or television reception, which can
be determined by turning the equipment on and off, the user is encouraged to
correct the interference with one or more of the following measures:
(a) Reorient or relocate the receiving antenna.
(b)Increase the separation between the equipment and the receiver.
(c) Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
(d)Consult the supplier or an experienced radio/TV technician for help.
Shielded cables must be used with this equipment to maintain compliance with
radio-frequency energy-emission regulations and ensure a suitably high level of
immunity to electromagnetic disturbances.
5
NOM STATEMENT
NORMAS OFICIALES MEXICANAS (NOM)
ELECTRICAL SAFETY STATEMENT
INSTRUCCIONES DE SEGURIDAD
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para
referencia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de
operación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca
de la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc.
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá
a lo descrito en las instrucciones de operación. Todo otro servicio deberá ser
referido a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no
interfiera su uso. La colocación del aparato eléctrico sobre una cama, sofá,
alfombra o superficie similar puede bloquea la ventilación, no se debe colocar
en libreros o gabinetes que impidan el flujo de aire por los orificios de
ventilación.
10. El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor
como radiadores, registros de calor, estufas u otros aparatos (incluyendo
amplificadores) que producen calor.
11. El aparato eléctrico deberá ser connectado a una fuente de poder sólo del
tipo descrito en el instructivo de operación, o como se indique en el aparato.
6
MULTI-HEAD SERVSWITCH™
12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13. Los cables de la fuente de poder deben ser guiados de tal manera que no
sean pisados ni pellizcados por objetos colocados sobre o contra ellos,
poniendo particular atención a los contactos y receptáculos donde salen del
aparato.
14. El equipo eléctrico debe ser limpiado únicamente de acuerdo a las
recomendaciones del fabricante.
15. En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16. El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17. Cuidado debe ser tomado de tal manera que objectos liquidos no sean
derramados sobre la cubierta u orificios de ventilación.
18. Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su
desempeño; o
E: El aparato ha sido tirado o su cubierta ha sido dañada.
7
TABLE OF CONTENTS
Contents
Chapter Page
1. Specifications ............................................................................................. 9
2. Introduction ............................................................................................. 12
2.1 Features and Benefits ....................................................................... 12
2.2 The Complete Package ..................................................................... 13
2.3 The Multi-Head ServSwitch Illustrated ............................................ 14
2.4 Safety Concerns ................................................................................. 15
3. Installation ................................................................................................ 16
3.1 What You Will Need .......................................................................... 16
3.2 Placement .......................................................................................... 17
3.3 Connecting Your Equipment ........................................................... 17
3.3.1 Basic Systems with a Single Switch ......................................... 18
3.3.2 Synchronized Switch Systems for
CPUs with up to Eight Video Outputs .............................. 19
3.3.2 Cables and Adapters ............................................................... 21
3.4 Powering the Switch .......................................................................... 23
4. Configuration ........................................................................................... 24
4.1 Configuring Your PCs ....................................................................... 24
4.2 Configuring the Multi-Head ServSwitch .......................................... 25
4.2.1 Entering Configuration Mode ............................................. 25
4.2.2 Setting the Screen-Saver Timeout ....................................... 26
4.2.3 Autoscanning: Setting the Scan Mode and Pause Time ..... 27
4.2.4 Enforcing Mouse Speed ....................................................... 28
4.2.5 Setting Mouse-Mode Reporting and
Enabling/Disabling Mouse Switching ............................ 29
4.2.6 Choosing Active Ports or All Ports for
Keyboard-Tab and Mouse Switching .............................. 30
4.2.7 Setting the Hotkey Sequence ............................................... 31
4.2.8 Viewing the Firmware Revision, Restoring Mouse
Function, or Resetting to Factory Defaults ..................... 32
4.2.9 Setting the Password ............................................................. 33
4.2.10 Exiting Configuration Mode ................................................ 33
8
MULTI-HEAD SERVSWITCH™
Contents (continued)
Chapter Page
5. Operation ................................................................................................. 34
5.1 Power Status ..................................................................................... 34
5.2
The Front-Panel Pushbutton and the Remote-Control Module
... 35
5.3 The Status Display ........................................................................... 36
5.4 Things to Keep in Mind About the Keyboards and Mice ............. 37
5.5 Keyboard Control: Hotkey Commands ......................................... 38
5.6 Mouse Control ................................................................................. 40
5.7 Re-Enabling a Disconnected PS/2 Mouse ..................................... 41
5.8 Hot-Plugging Devices Into the Multi-Head ServSwitch and
Re-Enabling Disconnected CPU PS/2 Mouse Ports ................ 41
5.9 RS-232 Control ................................................................................ 43
5.10 Performing a Warm Reset .............................................................. 43
5.11 Upgrading the Switch’s Firmware .................................................. 44
6. Troubleshooting ...................................................................................... 46
6.1 Things to Try ..................................................................................... 46
6.2 Calling Black Box .............................................................................. 48
6.3 Shipping and Packaging ................................................................... 48
Appendix: Cable Guidelines .......................................................................... 49
A.1 Cabling from the Keyboard, Mouse, and Monitors to the
Multi-Head ServSwitch .................................................................. 49
A.2 Cabling from the Multi-Head ServSwitch to the CPUs ................... 49
A.3 Cabling Attached to the OPTIONS Port ......................................... 52
9
CHAPTER 1: Specifications
1. Specifications
Compliance: CE (EN55022 Class B); FCC Part 15 Subpart J Class A,
IC Class/classe A
Standards: VGA, SVGA, XGA, XGA-2, SXGA, or UXGA video;
supports VESA DDC, DDC1, and DDC2 signaling
Interfaces: Video: VGA;
Keyboard and mouse: IBM PS/2 compatible; with
appropriate adapters, also supports IBM PC/AT type
keyboards, CPUs with PC/AT keyboard ports, and
CPUs with EIA/TIA RS-232 mouse ports;
OPTIONS port: EIA/TIA RS-232 proprietarily pinned on
DB15
Resolution: Up to 1600 x 1280 noninterlaced at up to 100 Hz
Protocol: RS-232: Asynchronous
Data Format: RS-232: 8 data bits, no parity, 1 stop bit
Data Rate: RS-232: 1200 bps
Flow Control: RS-232: None
Maximum
Distance: 10 m (32 ft.) to any attached keyboard, mouse, or
monitor;
30 m (100 ft.) to any attached CPU
User Controls: Keyboard commands;
Mouse-click functions;
(1) Front-mounted pushbutton for channel change and
configuration mode;
(1) Bottom-mounted 8-position DIP switch for reset and
firmware upgrade
Indicator: (1) Front-mounted 7-segment status display
Questo manuale è adatto per i seguenti modelli
3
Indice
Altri manuali Black Box Interruttore
Black Box
Black Box SW459A-ST Manuale utente
Black Box
Black Box KV814A Manuale utente
Black Box
Black Box KV6108SA-R2 Manuale utente
Black Box
Black Box ServSwitch CX Quad IP Manuale utente
Black Box
Black Box SERVSWITCH Series Istruzioni di installazione e manutenzione
Black Box
Black Box ServSelect III KV22016A Manuale utente
Black Box
Black Box KV1044A-R2 Manuale utente
Black Box
Black Box ServSwitch KV780A Manuale utente
Black Box
Black Box ServSwitch ACR1000A-CTL Manuale utente
Black Box
Black Box LGB1126A-R2 Manuale utente
Black Box
Black Box SW111A Manuale utente
Black Box
Black Box SW621A-R3 Manuale utente
Black Box
Black Box SW056A Manuale utente
Black Box
Black Box KV2004A Manuale utente
Black Box
Black Box LIG1014A Manuale utente
Black Box
Black Box LBG1000A-R2 Manuale utente
Black Box
Black Box KV7118SA Manuale utente
Black Box
Black Box LGH1004A Manuale utente
Black Box
Black Box LGB1152A Manuale utente
Black Box
Black Box CAT5 ClassWork Plus Multiloop Manuale utente
