Black Box SW722A-R2 Manuale utente

QUICK START

Following is a guide to quickly install and operate your ServSwitch.

Refer to the connection diagram on the following page.

1- Connect your CPUs to the ServSwitch using an appropriate

CPU Adapter Cables. Connect the DB25M end of the CPU

Adapter Cable to the DB25F connector labeled CPU x on the

ServSwitch’s rear panel. Connect the keyboard, mouse, and

video card connectors to your CPUs keyboard, monitor, and

mouse ports.

2- Connect your KVM station to the ServSwitch using an

appropriate KVM Adapter Cable. Connect the DB25M end

of the KVM Adapter Cable to the DB25F connector labeled

monitor / keyboard / mouse on the ServSwitch’s rear panel.

Connect the other end of the KVM Adapter Cable to the

mouse, keyboard, and monitor cables.

3- Connect the power adapter to ServSwitch and a power

source.

4- Turn on ServSwitch

5- Turn on the KVM monitor

6- Sequentially boot the CPUs starting with CPU #1

(You should see the boot up sequence on CPU #1 on the

KVM monitor)

7- Press the #2 select button on the front panel and boot CPU

#2. (You should see CPU #2’s boot up sequence on the

KVM monitor)

8- Press the #3 select button on the front panel and boot CPU

#3. (You should see CPU #3’s boot up sequence on the

KVM monitor)

9- Press the #4 select button on the front panel and boot CPU

#4. (You should see CPU #4’s boot up sequence on the

KVM monitor)

This completes the easy installation process. Refer to the

Installation manual for an expanded explanation of the

installation process and for additional commands.

Below shows a basic example of connecting a CPU, a keyboard. A monitor, and a

mouse to the ServSwitch. Connections will vary depending on the types of

equipment you are installing.
