Upgrade Guide

BlackBerry Professional Software for Microsoft Exchange

Version: 4.1 | Service Pack: 4

SWD-356206-0912100551-001

Contents

1Upgrading from the BlackBerry Professional Software to the BlackBerry Enterprise Server............................ 5

Feature comparison for the BlackBerry Professional Software and the BlackBerry Enterprise Server......................... 5

Host server and database upgrade scenarios......................................................................................................................... 6

2System requirements.......................................................................................................................................................... 9

System requirements: BlackBerry Enterprise Server............................................................................................................. 9

System requirements: BlackBerry Attachment Service......................................................................................................... 11

System requirements: BlackBerry Manager............................................................................................................................ 12

System requirements: BlackBerry MDS Connection Service................................................................................................ 13

System requirements: BlackBerry MDS Integration Service................................................................................................ 14

System requirements: BlackBerry Router................................................................................................................................ 14

Supported environments............................................................................................................................................................ 15

Unsupported environments....................................................................................................................................................... 17

3 Preparing to upgrade from the BlackBerry Professional Software to the BlackBerry Enterprise Server......... 19

Obtain the BlackBerry Enterprise Server software files........................................................................................................ 19

Verify and record the name of the existing host computer for the BlackBerry Professional Software.......................... 19

Verify and record the name of the administration account for the BlackBerry Professional Software......................... 19

Verify the names of the existing BlackBerry Configuration Database and its host computer........................................ 20

Verify the existing SRP authentication information.............................................................................................................. 20

Verify the existing CAL key........................................................................................................................................................ 20

Back up the BlackBerry Professional Software registry settings......................................................................................... 21

Back up the BlackBerry Professional Software log files........................................................................................................ 21

Back up the BlackBerry Configuration Database................................................................................................................... 21

BlackBerry Configuration Database Backup Tool parameters......................................................................................... 23

4 Configuring a Microsoft Exchange 5.5, Microsoft Exchange 2000, or Microsoft Exchange 2003 messaging

environment......................................................................................................................................................................... 25

Identify and resolve any Microsoft Exchange known issues for wireless calendar synchronization............................. 25

5 Setting up the database connection............................................................................................................................... 27

Using the existing BlackBerry Configuration Database after the upgrade to the BlackBerry Enterprise Server........ 27

Specifying permissions when connecting to the BlackBerry Enterprise Server databases using Windows

authentication.............................................................................................................................................................................. 27

Assign Microsoft SQL Server permissions to the Microsoft Windows account.............................................................. 27

Configuring authentication to the BlackBerry MDS Integration Service database.......................................................... 28

6Performing the upgrade from the BlackBerry Professional Software to the BlackBerry Enterprise Server on

the existing host computer............................................................................................................................................... 29

Prerequisites: Upgrading from the BlackBerry Professional Software to the BlackBerry Enterprise Server on the

existing host computer............................................................................................................................................................... 29

Stop the BlackBerry Professional Software services.............................................................................................................. 29

Upgrade from the BlackBerry Professional Software to the BlackBerry Enterprise Server on the existing host

computer....................................................................................................................................................................................... 30

Improve the startup performance of the BlackBerry Enterprise Server after the upgrade.............................................. 30

7Performing the upgrade from the BlackBerry Professional Software to the BlackBerry Enterprise Server on

a new host computer.......................................................................................................................................................... 31

Prerequisites: Upgrading from the BlackBerry Professional Software to the BlackBerry Enterprise Server on a new

host computer.............................................................................................................................................................................. 31

Configuring the local permissions on the new host computer............................................................................................. 31

Moving the BlackBerry Configuration Database to the new host computer..................................................................... 32

Stop the BlackBerry Professional Software services.............................................................................................................. 32

Upgrade from the BlackBerry Professional Software to the BlackBerry Enterprise Server on a new host computer

........................................................................................................................................................................................................ 33

Improve the startup performance of the BlackBerry Enterprise Server after the upgrade.............................................. 33

8 Troubleshooting the BlackBerry Enterprise Server upgrade process...................................................................... 35

A third-party tool did not install successfully and the BlackBerry Enterprise Server setup application closed.......... 35

Previous version detected but no database available............................................................................................................ 35

The BlackBerry Collaboration Service does not connect to Microsoft Office Live Communications Server 2005...... 36

The setup application did not prompt you to change or confirm the MAPI profile.......................................................... 36

You cannot resolve errors that occur when you move users................................................................................................. 36

You encounter errors when you try to upgrade the BlackBerry Configuration Database............................................... 37

The setup application prompts you for access to the installation media for Microsoft .NET Framework version 1.1

Service failed to start, generating error 5305........................................................................................................................ 37

BlackBerry Router and BlackBerry Dispatcher do not install during the migration or upgrade process...................... 41

I am experiencing an issue after I install the BlackBerry Professional Software on the Windows Small Business

Server............................................................................................................................................................................................. 41

Microsoft Outlook Web Access no longer works after I install the BlackBerry Professional Software.......................... 42

Restore the BlackBerry Configuration Database.................................................................................................................... 42

9 Upgrading the BlackBerry Device Software.................................................................................................................. 45

Permitting users to upgrade the BlackBerry Device Software from their computers....................................................... 45

Configure a network drive...................................................................................................................................................... 46

Save the BlackBerry Device Software installation files to the network drive................................................................ 46

Verify the version of the application loader tool................................................................................................................ 46

Pushing the BlackBerry Desktop Software or BlackBerry Device Manager installation files to users' computers

.................................................................................................................................................................................................... 46

Synchronizing wireless data automatically......................................................................................................................... 47

Create the BlackBerry Device Software upgrade instructions for BlackBerry device users........................................ 47

Confirming that the BlackBerry Device Software upgrade process completed successfully...................................... 48

Upgrading the BlackBerry Device Software at a central computer.................................................................................... 48

Configure a network drive...................................................................................................................................................... 49

Save the BlackBerry Device Software installation files to the network drive................................................................ 49

Create a software configuration for the BlackBerry Device Software............................................................................ 49

Assign the software configuration to a user account........................................................................................................ 50

Upgrade the BlackBerry Device Software at a central computer.................................................................................... 50

Verify that the BlackBerry Device Software upgrade at a central computer completed successfully....................... 50

Pushing the BlackBerry Device Software and the BlackBerry Desktop Software to users' computers......................... 51

Configure a network drive...................................................................................................................................................... 51

Save the BlackBerry Device Software installation files to the network drive................................................................ 51

Save the BlackBerry Desktop Software installation files to the network drive............................................................. 52

Synchronizing wireless data automatically......................................................................................................................... 52

Send the installation files for the BlackBerry Desktop Software and the BlackBerry Device Software to users using

a third-party application........................................................................................................................................................ 52

Confirming that the BlackBerry Device Software upgrade process completed successfully...................................... 53

10 Troubleshooting the BlackBerry Device Software upgrade process........................................................................ 55

When users click the link to the application loader tool in the upgrade instructions, the upgrade process does not

start................................................................................................................................................................................................ 55

11 Glossary................................................................................................................................................................................ 57

12 Legal notice.......................................................................................................................................................................... 61

Upgrading from the BlackBerry Professional Software to

the BlackBerry Enterprise Server 1

Your organization can upgrade from the BlackBerry® Professional Software to a supported higher version of the BlackBerry®

Enterprise Server. The decision to upgrade might be influenced by factors such as the following:

• The number of BlackBerry device users in your organization is approaching the maximum of 30 users.

• The number of users or administrators in your organization requires group-based or role-based administration.

• Users need access to applications that were developed using the BlackBerry® MDS Studio or the BlackBerry® Plug-

in for Microsoft® Visual Studio®.

• Users want to use collaboration clients, such as the BlackBerry® Client for IBM® Lotus® Connections.

Feature comparison for the BlackBerry Professional Software and the

BlackBerry Enterprise Server

Feature BlackBerry Professional Software BlackBerry Enterprise Server

supported database engines • Microsoft® SQL Server®

• Microsoft® SQL Server® 2005

Express

• MSDE 2000

• Microsoft SQL Server

• Microsoft SQL Server 2005

Express (not supported by the

BlackBerry® MDS Integration

Service)

• MSDE 2000

installationpossibleonmessagingserver yes no

support for remote components no yes

BlackBerry MDS Runtime Application

support

no yes

support for collaboration clients no yes

BlackBerry Manager highlights the tasks that administrators

in smaller organizations most

frequently perform

full enterprise administration

number of users maximum of 30 users limited only by the scalability of the

system configuration

users Add Users wizard add users manually

Upgrade Guide Upgrading from the BlackBerry Professional Software to the BlackBerry Enterprise Server

Feature BlackBerry Professional Software BlackBerry Enterprise Server

groups user administration only group administration or user

administration

roles user administration only role-based administration

IT policy predefined IT policy bundles custom IT policies only

domains single domain only multiple domain administration

support for Wi-Fi® connections no yes

support for BlackBerry® Enterprise

Server Resource Kit

no yes

Host server and database upgrade scenarios

Hardware Scenario

host server The BlackBerry® Professional Software must be installed on the computer where you plan

to install the BlackBerry® Enterprise Server software.

• If the BlackBerry Professional Software is currently installed on a computer that is

separate from the messaging server, you can upgrade to the BlackBerry Enterprise

Server on the same computer.

• If the BlackBerry Professional Software is currently installed on the computer that

hoststhemessagingserver,youmustfirstinstallthe BlackBerry Professional Software

on the computer where you plan to install the BlackBerry Enterprise Server software.

You can then upgrade to the BlackBerry Enterprise Server on this computer.

•If you plan to install the BlackBerry Enterprise Server components on more than one

computer, you must install the BlackBerry Professional Software on each computer

that you plan to use. You can then upgrade to the BlackBerry Enterprise Server on

each computer.

database • If the computer that hosts the messaging server currently also hosts the BlackBerry

Configuration Database, you do not have to move the BlackBerry Configuration

Database when you upgrade to the BlackBerry Enterprise Server.

• If you plan to move the existing BlackBerry Configuration Database to a new

Microsoft® SQL Server®, you must perform the move before you begin the upgrade

process.

Upgrade Guide Host server and database upgrade scenarios

Hardware Scenario

•If the BlackBerry Configuration Database is currently installed on a computer that is

separate from the messaging server, you can configure the connection to the

BlackBerry Configuration Database during the BlackBerry Enterprise Server upgrade

process.

• If you are adding a large number of users, or if you expect a significant increase in

the number of email messages that users send and receive, consider moving the

BlackBerry Configuration Database to its own host computer. You perform this move

before you begin the upgrade process.

For information about moving the BlackBerry Configuration Database, visit

www.blackberry.com/support to read article KB03112.

Upgrade Guide Host server and database upgrade scenarios

Altri manuali per PROFESSIONAL SOFTWARE FOR MICROSOFT EXCHANGE

Indice

Altri manuali Blackbe;rry Software

Blackbe;rry

Blackbe;rry PRD-07630-011 - Enterprise Server - PC Manuale utente

Blackbe;rry

Blackbe;rry PRD-10459-035 - Enterprise Server For MDS Manuale di istruzioni

Blackbe;rry

Blackbe;rry ENTERPRISE SOLUTION SECURITY - ERASING FILE SYSTEMS ON DEVICES -... Guida all'installazione

Blackbe;rry

Blackbe;rry AH0QIKO - Lotus Domino Enterprise Server Manuale di installazione e funzionamento

Blackbe;rry

Blackbe;rry Windows Live Messenger for BlackBerry Smartphones... Manuale di istruzioni

Blackbe;rry

Blackbe;rry WALLET - LEARN MORE Manuale utente

Blackbe;rry

Blackbe;rry ENTERPRISE INSTANT MESSAGING 2.5.46 - S Manuale di istruzioni

Blackbe;rry

Blackbe;rry ENTERPRISE SOLUTION SECURITY - - ACRONYM... Manuale utente

Blackbe;rry

Blackbe;rry CLIENT FOR IBM LOTUS SAMETIME 2.5.40 - S Manuale di istruzioni

Blackbe;rry

Blackbe;rry JAVA DEVELOPMENT ENVIRONMENT - - MULTIMEDIA - DEVELOPMENT... Manuale utente

Blackbe;rry

Blackbe;rry TWITTER - LEARN MORE Manuale utente

Blackbe;rry

Blackbe;rry TIVO - LEARN MORE Manuale utente

Blackbe;rry

Blackbe;rry CLIENT FOR USE WITH MICROSOFT OFFICE COMMUNICATIONS SERVER 2007 2.5.40 -... Manuale di istruzioni

Blackbe;rry

Blackbe;rry ENTERPRISE SOLUTION SECURITY - SECURITY FOR DEVICES WITH BLUETOOTH WIRELESS TECHNOLOGY -... Guida all'installazione

Blackbe;rry

Blackbe;rry MEDIA SYNC - - RELEASE NOTES Manuale di istruzioni

Blackbe;rry

Blackbe;rry TWITTER FOR BLACKBERRY SMARTPHONES 1.0 Manuale di istruzioni

Blackbe;rry

Blackbe;rry MEDIA SYNC Manuale utente

Blackbe;rry

Blackbe;rry PROFESSIONAL SOFTWARE FOR MICROSOFT EXCHANGE - - MIGRATION... Manuale utente

Blackbe;rry

Blackbe;rry GOOGLE TALK FOR SMARTPHONES Manuale utente

Blackbe;rry

Blackbe;rry APP WORLD STOREFRONT 2.0 - RELEASE NOTES Manuale di istruzioni

Blackbe;rry

Blackbe;rry APP WORLD - SPORT CASE Manuale utente

Blackbe;rry

Blackbe;rry MYSPACE - VERWENDEN DES BROWSERS AUF IHREM... Manuale utente

Blackbe;rry

Blackbe;rry WALLET 1.2 - RELEASE NOTES Manuale di istruzioni

Blackbe;rry

Blackbe;rry AMAZON MP3 - ANNEXE 472 V1.0 Manuale utente

Manuali Software popolari di altre marche

COMPRO

COMPRO COMPROFM Manuale utente

Muratec

Muratec OFFICEBRIDGE ONLINE Manuale utente

Oracle

Oracle Contact Center Anywhere 8.1 Manuale utente

Adobe

Adobe 65007312 - Photoshop Lightroom Manuale

Avaya

Avaya NULL One-X for RIM Blackberry Manuale utente

HP ProLiant BL420c Manuale utente

PS Audio

PS Audio PowerPlay Manuale del proprietario

Brady

Brady LOCKOUT PRO 3.0 Manuale di servizio

Avaya

Avaya Interaction Center Manuale utente

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuale

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuale utente

Oracle

Oracle Application 9i Manuale utente

Acer

Acer RDM Manuale utente

Canon

Canon Vixia HF21 Manuale utente

Canon

Canon ZR950 Manuale utente

Samsung

Samsung Auto Backup Manuale utente

Polycom

Polycom Vortex EF2201 Istruzioni per l'installazione e il funzionamento

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuale utente
