BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: (877) 255-3976 • Fax: (866) 644-1354
Blodgett can often accommodate special or custom requirements. Contact
your Blodgett representative.
CAPACITY
Unit capacity
Model 20036RSB 4 pans
Model 20048RSB 4 pans
Model 20060RSB 6 pans
Model 20072RSB 8 pans
Model 20084RSB 8 pans
Model 20096RSB 12 pans
Model 20108RSB 12 pans
Drawer capacity
Each 18” drawer holds one pan front to back
Each 27” wide drawer holds two pans front to back
Each 31” wide drawer holds two pans side by side
STANDARD FEATURES
Self closing heavy duty drawers slide on stainless steel rollers
Drawers hold standard sized (12” x 20” x 4”) pans - not included
CFC-free refrigeration system ahs an expansion valve for rapid temperature
recovery (the remote condenser unit is NOT included)
Foamed-in-place CFC-free polyurethane insulation provides highest insulation
factor available
Self-closing drawers have easy-to-grasp handles
Rubber magnetic door gaskets provide a positive seal and easy cleaning
Stainless steel top, front, sides, back, drawers and interior cavity
6” adjustable stainless steel legs
Interior corners are coved for easy cleaning
Condensate drain (1/2” I.D. tube) with optional electric condensate evaporator
Adjustable thermostat with external dial thermometer
Mullion coils are coated to resist corrosion and provide maximum air flow for
even cooling
Operates on 120 volt, single phase, 50/60 Hz AC power
Warranty: two year parts and labor from date of purchase
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Electric condensate evaporator
Cool pan drop ins
Casters (in lieu of legs)
Open frame base with caster
RSB Series
Refrigerator Base with Remote Condenser
REFRIGERATOR W/REMOTE CONDENSER
Project
Item No.
Quantity
Model 20036RSB (36” wide with two 27” drawers)
Model 20048RSB (48” wide with two 31” drawers)
Model 20060RSB (60” wide with two 18” drawers and two 27” drawers)
Model 20072RSB (72” wide with two 27” drawers and two 31” drawers)
Model 20084RSB (84” wide with four 18” drawers and two 27” drawers)
Model 20096RSB (96” wide with six 27” drawers)
Model 20108RSB (108” wide with two 27” drawers and four 31” drawers)
The Blodgett refrigerator bases support modular sectional range tops. They
keep food refrigerated until the moment it is ready to be cooked. These
“remote condenser” models connect to a separate condenser unit (not
included). Battery-design assistance is available!
Model 20072RSB
Printed in U.S.A. NOTE: FOR COMMERCIAL USE ONLY
APPROVAL/STAMP
P/N BR00033 Rev C (7/07)
REFRIGERATOR W/REMOTE CONDENSER
SHORT FORM SPECIFICATIONS
The item shall be refrigerator base-section for a sectional range. Unit shall a have 430 stainless steel #3 polish top, front, sides, back, drawers and interior cavity. The item shall have
drawers that hold standard sized (12” x 20” x 4”) pans (not included). The drawer assemblies shall be removable for cleaning. The unit shall include a 6’ (152cm) power cord with ground-
ed plug to receive 50 or 60hz, single phase, 120VAC electric power. The unit shall use a remote condenser unit (not included). The unit shall be at most 32-1/2” deep and shall be 26”
high including adjustable 6” legs. Refrigerant is CFC-free R-404a. Provide options and accessories as indicated.
NOTE: The company reserves the right to make substitutions of components without prior notice
32-1/2 (826)*
Power
Cord
26
(660)
6 (152) Condensate
Drain Tube
RIGHT SIDE REAR VIEW
Minimum clearance on all sides is 3” (76mm). However, modular range-top sections can be mounted
directly on top using an insulated base adapter. Also, these refrigerated bases can be part of a
sectional battery provided that the adjoining base sections are insulated (or do not produce heat).
DIMENSIONS ARE IN INCHES (MM).
Model 20036RSB
36 (914)
Model 20060RSB
60 (1524)
Model 20108RSB
108 (2743)
Model 20048RSB
48 (1219)
Model 20084RSB
84 (2134)
96 (2438)
Model 20096RSB
Model 20072RSB
72 (1829)
SHIPPING INFORMATION
Approximate weight:
20036RSB 325 lbs (147 kg)
20048RSB 400 lbs (181 kg)
20060RSB 530 lbs (240 kg)
20072RSB 637 lbs (289 kg)
20084RSB 735 lbs (333 kg)
20096RSB 835 lbs (379 kg)
20108RSB 940 lbs (426 kg)
OTHER TECHNICAL INFORMATION
Avoid locating where the temperature will drop below 55°F
(13°C) or rise above 90°F (32°C).
Check local codes for fire and sanitary regulations.
Model Width Cooled Volume
ft3 (m3)
Cooling Capacity
BTU/hr
Electricity
120V amps
Recommended
Compressor
20036RSB 36” 7.3 (0.21) 1550 2.5 1/4 H.P.
20048RSB 48” 10 (0.28) 1775 2.5 1/4 H.P.
20060RSB 60” 13 (0.37) 1875 3 1/4 H.P.
20072RSB 72” 16 (0.45) 1920 3 1/3 H.P.
20084RSB 84” 19 (0.54) 1955 7 1/3 H.P.
20096RSB 96” 23 (0.65) 1955 4 1/2 H.P.
20108RSB 108” 26 (0.74) 2000 4 1/2 H.P.
TECHNICAL INFORMATION
BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA • Phone: (877) 255-3976 • Fax: (866) 644-1354
