Bluetti EB70 Manuale utente
BLUETTI EB70
User Manual
Canada
USA
Mexico
Australia
Germany
Italy
Spain
South Africa
Nigeria
UK Sweden
Austria
Switzerland
Japan
China
Malaysia
Singapore
Philippines
New Zealand
Thank You
Thank you for making BLUETTI a part of your family.
From the very beginning, BLUETTI has tried to stay true to a sustainable future through green
energy storage solutions for both indoor and outdoor use while delivering an exceptional
eco-friendly experience for our homes and our world.
That's why BLUETTI makes its presence in 70+ countries and is trusted by millions of customers
across the globe.
CONTENTS
Before You Begin
Safety Instructions
What's In The Box
Standard Packaging
Product Overview
Diagram
Specifications
Operation
LCD Screen
Powering On/Off
Mode
Setting
Charging
Discharging
Appendix
FAQs (Frequently Asked Questions)
Technical Support
4
5
6
6
7
7
8
9
9
9
10
10
10
12
13
13
14
3
Before You Begin
The information contained herein is subject to change without notice.
For the latest version, please visit https://www.bluettipower.com/pages/user-guides.
The user manual contains instructions and notes on the operation and use of this unit.
BLUETTI recommends that you use genuine accessories from BLUETTI.
BLUETTI shall not be responsible for any damage or expense that might result from the use
of parts other than genuine parts from the BLUETTI.
For your safety and benefit, please read carefully before using and keep it handy for future
reference.
4
Failure to follow these guidelines may cause damage to your unit and injury to yourself or
others.
Keep this unit away from fire, humidity and dust.
Make sure the place where you are using the unit is well ventilated and spacious.
DO NOT place the unit on an unstable or tilted surface.
Turn off the unit IMMEDIATELY in case of malfunction.
When not using the unit for extended periods of time, power off the unit and disconnect the
AC adapter from the outlet.
Recommended storage temperature: 14-113OF/-10-45OC.
Charge the unit to 80% SOC every 3-6 months for long-term storage.
5
Safety Instructions
What's In The Box
6
2
AC Adapter
5
User Manual
6
Warranty Card
3
Car Charging Cable
4
Solar Charging Cable
1
Power Station
Standard Packaging
Note: Package details are subject to change without prior notice.
* AC Adapter: 120cm/47in.
Car Charging Cable: 72cm/28in. Cigarette lighter port to DC7909.
Solar Charging Cable: 150cm/59in. MC4 to DC7909.
Product Overview
7
Diagram
1. Charging Port
2. LCD Screen
3. Wireless Charging Pad
4. LED Lamp Button
5. LED Lamp
6. DC Power Button
7. USB-C Port
8. USB-A Port
9. DC5521 Port
10. Cigarette Lighter Port
11. AC Power Button
12. AC Outlet
8
Specifications
EB70
General
Battery Capacity
Cell Type
Dimensions (L*W*H)
Weight
Discharging Temperature
Charging Temperature
Working Humidity
716Wh
LiFePO4
12.6*8.5*8.7IN/320*216*221MM
21.4LB/9.7KG
-4-104°F/-20-40°C
32-104°F/0-40°C
10-90%
AC Output
AC Input
PV Input
Car Charging
DC Output
Power 120V
220-240V
800W
1000W
Surge
Frequency
1400W
50-60Hz
Cigarette Lighter Port *1
DC5521 *2
USB-A *2
Voltage
Current
Voltage
Current
Voltage
Current
Power
Power
Power
Voltage
Current
200W Max.
12-28VAC
8A Max.
Power
Open Circuit Voltage (OCV)
Current
Voltage
Current
12-24VDC
8A Max.
200W Max.
12-28VDC
8A Max.
12VDC
10A
12VDC
10A
5VDC
3A
100W Max. (5/9/12/15/20VDC, 3A; 20VDC, 5A)
15W Max.
USB-C PD3.0 *2
Wireless Charging *1
Operation
9
*The LCD screen is on for about 30-60 seconds. Please enable at least one of these ports (AC/DC)
if you want the display to stay on longer.
Note: Please turn on the DC power to enable the wireless charging.
Powering on: Press the AC/DC Power Button to start up corresponding output.
LCD Screen
a: ECO Mode
b: Battery Capacity
c: Input Power
d: Low-battery Alert
e: Temperature Anomaly Alert
f: Output Power
g: Overload Alert
h: Short-circuit Alert
Powering On/Off
Green light(on the button)
LCD Display
ON
ON*
10
Powering off: Press and hold power buttons to shut down corresponding output.
Setting Mode: When the AC output is off, press AC and DC power buttons simultaneously and
the frequency indicator flashes.
ECO Mode1:Under 'Setting Mode', press the DC power button to turn it on/off.
Green light(on the button)
LCD Display
OFF
OFF
AC Frequency2: Under 'Setting Mode', press the AC power button to switch.
Mode
Setting
1 When on this mode, the AC output will automatically turn off after 4-hour low (≤10W) or no load to save power.
2AC Frequency: The number of alternating cycles per second in an AC sine wave. The utility frequency is usually 50/60Hz.Charging
AC Charging
Simply plug the EB70 into a standard wall outlet and start charging.
AC Outlet
AC Adapter
