1.2.19 In terms of immunity to industrial radio disturbance, the module meets the requirements of Test
Severity Level III as per GOST R 50009.
1.2.20 The module withstands radio-frequency electromagnetic field in 80 through 100 MHz range as per
GOST 30804.4.3.
1.2.21 The module withstands electrostatic discharge of Test Severity Level III as per GOST 30804.4.2.
1.3 Standard Delivery
Table 1.3.1 represents the content of S2000-AR2 Rev.02 standard delivery.
Table 1.3.1
Item Quantity, pc(s).
S2000-AR2 Rev.02 Addressable Double-Input Module 10
S2000-AR2 Rev.02 Operations Manual 1
Resistor MF 1/4W-10k-5% 20
Woodscrew 1-3x25.016 GOST 1144-80 20
Wall Plug 6x30 20
Individual packing 10
Group packing 1
2INTENDED USAGE
Detailed information on operational restrictions, design, mounting, wiring, setting, and operability /
performance test procedures is contained in S2000-AR2 Rev.02 User’s Manual, which can be found online
at bolid.ru in the PRODUCTS section on the page of S2000-AR2 Rev.02.
3MAINTENANCE
3.1 The module shall be maintained by personnel with Safety Qualification Level II of higher.
3.2 The module shall be maintained according to a scheduled-preventive system which provides annual
service.
3.3 Maintenance works are described in S2000-AR2 Rev.02 User’s Manual, which can be found online at
bolid.ru in the PRODUCTS section on the page of S2000-AR2 Rev.02.
4ROUTINE REPAIR
4.1 Routine repair of defective equipment is to be performed by the manufacturer or in authorized repair
centers. The product shall be sent for repair in line with established procedures.
4.2 An equipment failure resulted from consumer’s not observing rules of mounting and operation is not a
reason for claims and warranty repair.
4.3 Claims shall be submitted to the following address:
NVP Bolid, #4 Pionerskaya Str., Korolyov, Moscow Region, 141070, Russia
Tel./fax: +7 (495) 775-71-55 (PBX), E-mail: info@bolid.ru.
4.4 In case of any issue related to use of the product, please contact the technical support:
ATTENTION
The equipment shall be submitted for repair being assembled and clean and along with all
the parts listed in the documentation.
Claims are accepted only if a reclamation report describing the failure is applied to the
submitted equipment.
