Flasher LT

User’s Manual

Contents

2 Introduction

Flasher LT as a PassThru Device

3 GettingToKnowFlasherLT

4 SettingUpTheFlasherLT

Installing the Flasher LT

Updating the Drivers and Firmware

6 ReprogrammingWithJ2534

GM SPS

7 SpecicationsandPinout

Vehicle Connector

8 TroubleshootingandSupport

If you need to generate a logle for debugging

If all else fails...

Flasher LT User’s Manual | Version 2 | August 2008 Robert Bosch LLC

TableofContents|Flasher LT | 1

Introduction

The Flasher LT offers users a J2534 compliant device at a low cost.

The device features a direct connection to a laptop or desktop

PC via a USB2.0 full speed connection. All of the electronics are

contained in the OBD-II connector shell, making for a compact and

rugged vehicle communications solution.

The Flasher LT is powered by the USB interface, so there’s no

reinitialization necessary if the device is unplugged from the vehicle

interface.

For additional information regarding J2534 reprogramming visit our

website at www.boschdiagnostics.com.

Robert Bosch LLC Flasher LT User’s Manual | Version 2 | August 2008

2 | Flasher LT | Introduction

GettingtoKnowFlasherLT

There are 4 variants of the Flasher LT J2534 device:

The Flasher LT-Import supports CAN, ISO-9141, and ISO-14230/ f

KWP2000. (P/N# F00E900078)

The Flasher LT-GM supports CAN, J1850 VPW (GM Class 2), f

andGM Single-Wire CAN protocols. (P/N# F00E900075)

The Flasher LT-Ford supports CAN and J1850 PWM (Ford SCP) f

protocols. (P/N# F00E900076)

The Flasher LT-Chrysler supports CAN, J2610 (SCI), and J1850 f

VPW. (P/N# F00E900077)

Your Flasher LT kit includes: the Flasher LT hardware, a CD

including drivers, user’s manual, and quickstart guide.

Flasher LT User’s Manual | Version 2 | August 2008 Robert Bosch LLC

GettingtoKnowFlasherLT|Flasher LT | 3

SettingUptheFlasherLT

InstallingtheFlasherLT

NOTE:TheFlasherLTrequiresWindows2000orWindowsXPto

operate.Windows95/98isnotsupported.

Connect the Flasher LT cable to a USB port on your PC. Windows

will detect it automatically by plug-and-play

The Found New Hardware Wizard will open automatically. Select

“No, not this time” and click next. Then click “Install from a list or

specic location” and click next. Insert the Flasher LT drivers CD,

make sure “Search removable media” is selected and click next.

The wizard will install all necessary drivers. A dialog box may

pop-up to indicate that Flasher LT has not passed Windows Logo

testing. Click “Continue Anyway”.

UpdatingtheDriversandFirmware

Both the Windows drivers and Flasher LT rmware are eld

upgradable. The Windows J2534 drivers and the Flasher LT

rmware versions are locked to each other. If you update the

Windows drivers, you must update the Flasher LT to a matching

rmware version. Updates are regularly released which include

new features, improve performance, and correct problems. These

updates can be found at http://www.boschdiagnostics.com/

Robert Bosch LLC Flasher LT User’s Manual | Version 2 | August 2008

4 | Flasher LT | SettingUptheFlasherLT

UpdatingtheFlasherLTWindowsDrivers

Make sure the drivers are accessible on the PC being updated, f

either by having a drivers CD in the CD-ROM device or unzipping

the drivers le from the Bosch Diagnostics website to a known

location on the computer.

Connect the Flasher LT to a USB port on your PC. f

Open the Windows Control panel, double click on the System f

icon, choose the Hardware tab, and click on Device Manager.

From the Device Manager Window that opens up, click on the + f

sign next to Universal Serial Bus Controllers.

Locate and right-click the Flasher LT entry and choose Update f

Driver.

Choose “No, not this time” if prompted to connect to Windows f

Update to search for drivers.

If Windows XP, select “Install from a List or Known Location”, if f

Windows 2000 this will be automatic.

Check “Include this location in the search” and browse to the f

directory where the Bosch Diagnostics Drivers were unzipped to

and click NEXT

The new Windows drivers should install normally.

UpdatingtheFlasherLTFirmware

To update the Flasher LT Firmware from the Windows GUI:

Ensure the Flasher LT is not connected to a vehicle and plug it into

the USB port of a PC.

Navigate to the “Troubleshooting/Reash” directory of the Flasher

LT drivers. Double click the “mreash” program. A window will open

up and the rmware will download to the device. If the download

fails, an error message will be displayed.

Flasher LT User’s Manual | Version 2 | August 2008 Robert Bosch LLC

SettingUptheFlasherLT|Flasher LT | 5

ReprogrammingWithJ2534

Since J2534 allows multiple devices to be connected at once,

you must tell the software you want to use the Flasher LT. Every

application will have a different way to select the device, so consult

the OEM J2534 User’s Guide.

GMServiceProgramming(SPS)

If you are using GM’s TIS2WEB, login to the service site and click on

“Service Programming System” once the initial page has loaded. A

new window will open running TIS2WEB’s version of SPS

When using the FLASHER LT you can click “Skip” when 1.

confronted with the Tech2 software update window.

When the Service Programming System window appears, click 2.

on settings in the bottom left corner of the window.

Click on the “Diagnostic” tab at the top and select the “J2534 3.

FLASHER LT VPW/CAN” from the device drop down menu.

With the FLASHER LT connected to the vehicle and the key on, 4.

you can now check connectivity by clicking “Test Connection.”

Now click “Ok” at the bottom. Back at the Service Programming 5.

System window Select the “J2534 FLASHER LT VPW/CAN”

under the “Select Diagnostic Tool” heading. Select “Replace” or

“Replace and Program ECU,” and click next.

You can now re-ash the vehicle.6.

Robert Bosch LLC Flasher LT User’s Manual | Version 2 | August 2008

6 | Flasher LT | ReprogrammingWithJ2534

SpecicationsandPinout

VehicleConnector

Mating connector: Standard OBD-II

Pin#

Flasher

LT-Import

Flasher

LT-GM

Flasher

LT-Ford

Flasher-LT

Chrysler

1SWCAN

2J1850 J1850+ J1850

5 Signal GND Signal GND Signal GND

6CAN+ CAN+ CAN+ CAN+ / SCI RX

7K-Line SCI TX

9 SCI RX

10 J1850-

12 SCI RX

13 Prog Voltage

14 CAN- CAN- CAN- CAN- / SCI RX

15 L-Line SCI TX

16 Battery

Voltage

Battery

Voltage

Battery

Voltage

Battery

Voltage

Flasher LT User’s Manual | Version 2 | August 2008 Robert Bosch LLC

SpecicationsandPinout|Flasher LT | 7

TroubleshootingandSupport

IftheredLEDisoncontinuously,this usually indicates that the

drivers have either not been installed or have not been installed

correctly.

IfthegreenLEDisashing, but you cannot communicate with

the Flasher LT, use the “minfo” utility on the drivers disk. It will

show if the Flasher LT is connected, the type of Flasher LT, and the

revisions of the boot loader and rmware on the device. If “minfo”

indicates no devices are found, check the Control Panel Device

Manager to see if Windows is indicating some sort of error with the

device.

IfnoLEDsarelit, this may indicate a failure of the Flasher LT

device. Insure that the USB port that it is plugged into is good by

using another USB device on the USB port.

Note:LED’sarebestviewedthroughthetransparentexible

cordatthebaseoftheFlasherLThousing.LEDvisibilitymaybe

reducedindirectsunlight.

If these issues have been addressed, veried, and you are still

having trouble, please email:

Techsupport.Diagnostics@us.bosch.com

or call

BoschDiagnosticsTechsupportHotline@800-321-4889ext2

Robert Bosch LLC Flasher LT User’s Manual | Version 2 | August 2008

8 | Flasher LT | TroubleshootingandSupport

Flasher LT User’s Manual | Version 2 | August 2008 Robert Bosch LLC

Warranty

This product is warranted to be free of defects for one year. If this

product fails during the rst 12 months due to faulty material or

workmanship, it will be replaced or repaired free of charge, at the

discretion of the manufacturer.

Defective units being returned to your supplier or to the factory

should include proof of purchase date. Any testers that do not

function due to misuse or abuse will be subject to “out of warranty

service charges”.

Forwarrantyreturnauthorizationcall:

1-800-321-4889

Forwarrantyreturnsandrepairs,shiptothefollowingaddress:

Bosch Diagnostics

Robert Bosch LLC

Repair Dept.

2800 S. 25th Avenue

Broadview, IL 60155-4594

TroubleshootingandSupport|Flasher LT | 9
