AMAX

2100 / 3000 / 4000

en User Guide

Table of contents

1Safety 5

2Short information 6

2.1 Introduction 6

2.2 Keypads 7

2.3 Keypad Indicators 8

2.4 Quick Keypad Operations Instructions 10

2.5 User Menu 13

3Arming and Disarming the System 14

3.1 Arming the System 14

3.1.1 Arming in AWAY Mode 14

3.1.2 Arming in STAY Mode 15

3.1.3 Forced Arming 15

3.1.4 Arming with a Master Keypad 16

3.2 Disarming the System 17

3.2.1 Disarming with Code 17

3.2.2 Disarming with Key Switch 17

3.2.3 Disarming with RADION RF Keyfob 17

3.2.4 Disarming with a Master Keypad 17

4Changing the Menu Language 18

5System Test 19

5.1 Siren Test 19

5.2 Communication Test 19

5.3 Walk Test Mode 19

6Bypassing 20

6.1 Bypassing/Unbypassing Zones 20

6.1.1 How to Bypass/Unbypass a Zone via Text Keypad 20

6.1.2 How to Bypass/Unbypass a Zone via LED/LCD Keypad 20

6.2 Bypassing Faults or Tamper Conditions 20

7Schedules 21

8Macros 22

8.1 Recording Macros 22

8.2 Playing Macros 23

9Codes 24

9.1 Add/Change User Codes 24

9.2 Change Individual Code 25

10 Keypad Alarm Operation Commands 26

10.1 Keypad Panic Alarm 26

10.2 Keypad Fire Alarm 26

10.3 Keypad Medical Alarm 26

11 Domestic Dialing 27

11.1 Domestic Dialing Alarm 27

11.2 Confirming the Domestic Call 27

12 Event Log Recall Mode 28

12.1 How to Select All Event Log Recall Mode 28

12.2 How to Select EN Event Log Recall Mode 28

12.3 How to Select Dialer Event Log Recall Mode 28

AMAX Table of Contents | en 3

Bosch Sicherheitsysteme GmbH User Guide 2014.09 | 03 | F.01U.295.569

13 Faults and Tamper Conditions 29

13.1 System Fault or Tamper Analysis Mode via Text Keypad 29

13.2 System Fault or Tamper Analysis Mode via LED/LCD Keypad 29

14 Resetting the Control Panel 33

15 Troubleshooting 34

4en | Table of Contents AMAX

2014.09 | 03 | F.01U.295.569 User Guide Bosch Sicherheitsysteme GmbH

Safety

Danger!

Electricity

Injuries due to electricity are possible if the system is not operated correctly or if the system

is opened or modified.

– Never open or modify the system.

– Please contact your installer if you want to get your system modified.

Caution!

Sensitive components

Damage of sensitive components is possible if the system is not handled carefully or if the

system is opened or modified.

– Always handle the system carefully.

– Never open or modify the system.

–Please contact your installer if you want to get your system modified.

AMAX Safety | en 5

Bosch Sicherheitsysteme GmbH User Guide 2014.09 | 03 | F.01U.295.569

Short information

Introduction

This User Guide contains information on how to operate the system easily and quickly. The

guide describes the main steps required for operation of the AMAX panel 2100/3000/4000

together with a text and/or a LED/LCD keypad described in Keypads, page 7. It is possible

to add an optional text keypad as a master keypad.

Detailed information about the installation of this and other modules and devices, advanced

settings and programming can be found in the Installation Guide. Information on the main

steps required for basic system installation and setup can be found in the Quick Start Guide.

2.1

6en | Short information AMAX

2014.09 | 03 | F.01U.295.569 User Guide Bosch Sicherheitsysteme GmbH

Keypads

The following text keypad can be used for operating AMAX panel 2100/3000/4000.

IUI-AMAX4-TEXT

The following LED/LCD keypads can be used for operating AMAX panel 2100/3000/4000.

IUI-AMAX3-LED8 IUI-AMAX3-LED16

IUI-AMAX-LED8 IUI-AMAX-LCD8

Notice!

Only a text keypad can be used as a master keypad.

2.2

AMAX Short information | en 7

Bosch Sicherheitsysteme GmbH User Guide 2014.09 | 03 | F.01U.295.569

Keypad Indicators

The following table shows an overview and a description of the keypad indicator icons.

Keypad Indicator

Icons

Status Definition

1 2 3 ….

ZONE (1-8)

on Zone is triggered.

off Zone is normal.

Fast flash (0.25 seconds lights on/

0.25 seconds lights off)

Zone was alarmed or is in alarm

status.

Slow flash (1 second lights on/1

second lights off)

Zone is manually bypassed or

interior Zone is in STAY arm mode.

AWAY

on System is armed in AWAY mode.

off System not armed in AWAY mode.

Slow flash (1 second lights on/1

second lights off)

Exit time.

Fast flash (0.25 seconds lights on/

0.25 seconds lights off)

Programming mode or code

function mode. STAY indicator

flashes simultaneously.

STAY

on System is armed in STAY mode.

off System not armed in STAY mode.

Slow flash (1 second lights on/1

second lights off)

Exit time.

Fast flash (0.25 seconds lights on/

0.25 seconds lights off)

Programming mode or code

function mode. AWAY indicator

flashes simultaneously. When

bypass function is performed, only

the STAY indicator flashes.

MAINS

on AC main power is normal.

Slow flash (1 second lights on/1

second lights off)

AC main power supply failed.

FAULTS

on System fault or Tamper condition

is present.

off System is in normal status.

Flashes System fault or tamper condition

must be acknowledged.

on System is disarmed.

2.3

8en | Short information AMAX

2014.09 | 03 | F.01U.295.569 User Guide Bosch Sicherheitsysteme GmbH

The following table shows an overview and a description of the keypad sound icons.

Sound Indicator Definition

Short beep A keypad button has been pressed.

Short beep, followed by a one-second

beep

The requested operation is refused. Incorrect

operation signal.

Two short beeps The system accepted the code. The system executed

the requested function.

One short beep every minute Fault tone, unacknowledged system failure.

One short beep every two seconds Exit time started.

Continued sound – Last 10 seconds on exit time

–Keypad fault or tamper sound (fault or tamper

to be acknowledged)

–Keypad alarm sound

Continuous 0.5 second beep, stops

for 0.5 seconds

– Entry delay time (until alarm ends or system is

disarmed)

– Exit delay time (stops 10 seconds before exit

delay stops)

AMAX Short information | en 9

Bosch Sicherheitsysteme GmbH User Guide 2014.09 | 03 | F.01U.295.569

Quick Keypad Operations Instructions

The following table shows an overview of the quick keypad operations and the corresponding

user permissions. For information on changing codes and defining user permission levels,

please refer to Codes, page 24.

Function Command

Default User Code = 2580

D A B S M

Arm/Disarm

AWAY Arm [code] + [#] / [#] for 3 sec. (quick arm) √ √ √ √ √ √ √

AWAY Arm All Areas (only

on master keypad)

[code] + [0] [0] + [#] √ √ √ √ √ √ √

Direct AWAY Arm (only on

master keypad

[code] + [2-digit area no.] + [#] √ √ √

STAY Arm [code] + [*] / [*] for 3 sec. (quick arm) √ √ √ √ √ √ √

STAY Arm All Areas (only

on master keypad)

[code] + [0] [0] + [*] √ √ √ √ √ √ √

Direct STAY Arm (only on

master keypad

[code] + [2-digit area no.] + [*] √ √ √

Disarm [code] + [#] √ √ √ √ √ √

Disarm All Areas (only on

master keypad)

[code] + [#] √ √ √ √ √ √

Display

Display Info (Fault/Tamper

Analysis)

[code] + [2] [1] + [#] √ √ √

Bypass

Bypass/Unbypass Zone [code] + [3] [1] + [#] + [2-digit zone no.]

+ [#]

√√√√√

Bypass Fault/Tamper [code] + [3] [4] + [#] √ √ √

Reset

Reset Fault/Tamper (In

some country versions only

the installer can reset a

tamper alarm)

[code] + [6] + [#] √ √ √

Macros

Record Macro 1 [code] + [8] [1] + [#] + operation + [#]

for 3 sec.

√ √ √ √

2.4

10 en | Short information AMAX

2014.09 | 03 | F.01U.295.569 User Guide Bosch Sicherheitsysteme GmbH
