1 Browser connection

A computer with Microsoft Internet Explorer is used to receive live images, control the unit,

and replay stored sequences. The unit is configured over the network using the browser.

1.1 Systems requirements

Our recommendations are:

– Computer with Intel Skylake processor or better

– Intel HD530 graphic card with performance that matches or is better than the resolution

of the camera

– Windows7 or later operating system

– Network access

– Internet Explorer version 11 or later

– or –

Application software, for example, VideoSecurityClient, BoschVideoClient or Bosch

Video Management System.

Note:

To see live images in your browser it might be necessary to download and install the MPEG-

ActiveX from the Bosch download store.

1.2 Establishing the connection

The unit must have a valid IP address to operate on your network and a compatible subnet

mask.

By default, DHCP is pre-set at the factory to On plus Link-Local so a DHCP server assigns an

IP address or, if no DHCP server is available, a link-local address (auto-IP) is assigned within

the range 169.254.1.0 to 169.254.254.255.

You can use IP Helper or Configuration Manager to find the IP address. Download the software

from http://downloadstore.boschsecurity.com.

1. Start the Web browser.

2. Enter the IP address of the unit as the URL.

3. During initial installation, confirm any security questions that appear.

If a RADIUS server is used for network access control (802.1x authentication), you must

configure the device before the device can communicate with the network.

To configure the device, connect it directly to a computer using a network cable and then set

the service-level password.

Note:

If you cannot connect, the unit may have reached its maximum number of connections.

Depending on the device and network configuration, each unit can have up to 50 web browser

connections, or up to 100 connections via BoschVideoClient or Bosch Video Management

System.

1.3 Password protection in camera

The device is password-protected. The first time that any user accesses the device, the device

will prompt the user to set a password at the service level.

The camera requires a strong password. Follow the prompts in the dialog box, which specifies

what is required. The system measures the strength of the password that you enter.

MIC IP fusion 9000i Browser connection | en 7

Bosch Security Systems User Manual 2017.11 | 0.20 | F.01U.349.011

When you use Configuration Manager to access your device for the first time, you must set the

initial password of the device in Configuration Manager. The Users section (General > Unit

Access > Users) displays the message, "Before you can use this device you have to secure it

with an initial password."

Note: After you set the initial password, a "lock" icon appears next to the device name in the

Devices list in Configuration Manager.

You can also launch the device webpage directly. In the device webpage, an initial password

page appears, displaying input fields and a password strength gauge.

Enter the user name (“service”) and a password in the appropriate fields. Refer to the section

User Management for more information.

After a service-level password is set for the device, the device displays a dialog box that

prompts users to enter the user name (“service”) and the service-level password every time

that they access the device.

1. Fill in the fields User name and Password.

2. Click OK. If the password is correct, the desired page appears.

8en | System overview MIC IP fusion 9000i

2017.11 | 0.20 | F.01U.349.011 User Manual Bosch Security Systems

2 System overview

When a connection is established, the Live page is initially displayed.

The application bar displays the following icons:

Live To view the live video stream, click this icon.

Playback To play back recorded sequences, click this icon.

This link is only visible if a storage medium has been

configured for recording. (With VRM recording this

option is not active.)

Configuration To configure the unit, click this icon.

Links To navigate to the Bosch download store, click this

icon.

To get context sensitive help for a particular page, click

this icon.

Note: None of the pages are accessible until after you set a service-level password.

2.1 Live page

The Live page is used to display the live video stream and control the unit.

2.2 Configuration

The Configuration page is used to configure the unit and the application interface.

Making Changes

Each configuration screen shows the current settings. You can change the settings by entering

new values or by selecting a predefined value from a list field.

Not every page has a Set button. Changes to pages without a Set button are set immediately.

If a page does show a Set button, you must click the Set button for a change to take effect.

Notice!

Save each change with the associated Set button.

Clicking the Set button saves the settings only in the current field. Changes in any other fields

are ignored.

Some changes only take effect after the unit is rebooted. In this case, the Set button changes

to Set and Reboot.

1. Make the desired changes.

2. Click the Set and Reboot button. The camera reboots and the changed settings are

activated.

All settings are backed up in camera memory so they are not lost even if the power fails. The

exception is the time settings, which are lost after 1 hour without power if no central time

server is selected.

2.3 Playback

The Playback page is used for playing back recorded sequences.

MIC IP fusion 9000i Operation via the browser | en 9

Bosch Security Systems User Manual 2017.11 | 0.20 | F.01U.349.011

3 Operation via the browser

3.1 Live page

3.1.1 Connection

Video

Select the appropriate camera from which to view live video.

Camera 1 is the visible image, and Camera 2 is the thermal image.

Stream

Select the appropriate live video stream.

Stream 1

Select this option to display stream 1 of the camera.

Stream 2

Select this option to display stream 2 of the camera.

M-JPEG

Select this option to display the M-JPEG stream of the camera.

3.1.2 PTZ

Pan and tilt controls

– To tilt the camera up: Click and hold the up arrow.

– To tilt the camera down: Click and hold the down arrow.

– To pan the camera left: Click and hold the left arrow.

– To pan the camera right: Click and hold the right arrow.

– To pan and tilt the camera at the same time (variable pan/tilt): Click and drag the center

area (that resembles a point stick or a trackball on a computer keyboard) around the PTZ

control in the direction that you want to move the camera.

Notice!

If the camera will not pan in either direction, or pans in one direction only, refer to the “Error

Codes” section of the manual.

Zoom

Click the + button to zoom in.

Click the - button to zoom out.

Iris

Click (Iris close) to close the iris.

Click (Iris open) to open the iris.

Focus

Click to focus near.

Click to focus far.

10 en | Operation via the browser MIC IP fusion 9000i

2017.11 | 0.20 | F.01U.349.011 User Manual Bosch Security Systems

3.1.3 Pre-positions

The camera displays Pre-position 1 through Pre-position 6. Select the appropriate pre-

position to view the video image for that pre-position/scene. In the lower left of the video

image, the OSD displays the Camera number (title), the Pre-position number, and the Pre-

position number stored.

Below the list of pre-positions/scenes is a drop-down list showing the stored pre-positions/

scenes.

Select the appropriate pre-position (1 through 6). Click to store the pre-position.

Note: If the pre-position is already stored, a dialog box displays the message, “Overwrite

current pre-position?” Click OK to overwrite, or click Cancel to cancel the operation.

Click to display the selected pre-position in the video image.

3.1.4 AUX Control

With the tab AUX Control you can enter pre-programmed keyboard control commands. These

commands are composed of a command number plus the appropriate function key (Show pre-

position, Set pre-position, AUX on, or AUX off). A valid combination either issues a command

to the device or displays an on-screen menu.

(Refer to the “Keyboard Commands“ section of the manual for a list of all AUX commands for

your camera.)

Show pre-position

Click this button to display a pre-position.

Set pre-position

Click this button to set a pre-position.

AUX on

Click this button to activate an AUX command.

AUX off

Click this button to deactivate an AUX command.

3.1.5 Intelligent Tracking

Options for tracking objects within the region of interest appear in the panel.

When Intelligent Tracking is active, the tracking icon appears on the image along with

the lines that track moving objects.

Select Off, Auto or Click. If Click is selected, click on an object to track it.

3.1.6 Special Functions

Scan 360°

Click this button to start a continuous 360° pan. To stop the continuous pan, click a

directional control in the View Control tab.

Autopan

Click this button to pan the camera between user-defined limits.

Tour A / Tour B

Click one of these buttons to start the continuous playback of a recorded (guard) tour. A

recorded tour saves all manual camera movements made during the recording, including its

rate of pan, tilt and zoom speeds, and other lens setting changes.

To stop a tour, click a directional control in the View Control tab.

Note: Tour B is now intended for use with the 'IVA while moving' functions.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Bosch Sistema di sicurezza

Bosch

Bosch ISW-BMC1-S135X Manuale utente

Bosch

Bosch NBN-733 Istruzioni per il montaggio

Bosch

Bosch LTC 1311/20 FlexiDome I Manuale utente

Bosch

Bosch AMAX panel 2000 ICP-AMAX-P Manuale utente

Bosch

Bosch Solution 144 Manuale utente

Bosch

Bosch DIVAR DIP-6080-00N Manuale utente

Bosch

Bosch Security System Manuale utente

Bosch

Bosch IRIS-Net Manuale utente

Bosch

Bosch D9412GV4 Manuale utente

Bosch

Bosch BE 300 LSN Manuale utente

Bosch

Bosch 2212 Manuale utente

Bosch

Bosch DS860 Series Manuale utente

Bosch

Bosch Security System Manuale utente

Bosch

Bosch D222TD Manuale utente

Bosch

Bosch 844 Manuale utente

Bosch

Bosch Radion B810 Manuale utente

Bosch

Bosch Dinion LTC 0385 Manuale utente

Bosch

Bosch AVENAR all-in-one 4000 Manuale utente

Bosch

Bosch Plena Power Amplifier Manuale utente

Bosch

Bosch LTC 9441 Series Manuale utente

Bosch

Bosch FMC-300RW-GSGRD Manuale utente

Bosch

Bosch FLM-420-RLE-S Manuale utente

Bosch

Bosch APC-AMC2-4W Manuale utente

Bosch

Bosch PRAESENSA Manuale utente

Manuali Sistema di sicurezza popolari di altre marche

Inner Range

Inner Range Concept 2000 Manuale utente

Climax

Climax Mobile Lite R32 Istruzioni per il montaggio

CADDX

CADDX NX-6 Manuale utente

FBII

FBII XL-31 Series Manuale utente

Johnson Controls

Johnson Controls PENN Connected PC10 Manuale utente

Aeotec

Aeotec Siren Gen5 Manuale utente

Blaupunkt

Blaupunkt SA 2700 Manuale utente

IDEAL

IDEAL Accenta Manuale del proprietario

AJAX

AJAX DoubleButton Manuale utente

Swann

Swann SW-P-MC2 Manuale utente

Ecolink

Ecolink Siren+Chime Manuale utente

Digital Monitoring Products

Digital Monitoring Products XR150 Manuale utente

EDM

EDM Solution 6+6 Wireless-AE Manuale utente

Highway Safety Group

Highway Safety Group EA401 Manuale utente

Siren

Siren LED GSM Manuale utente

Detection Systems

Detection Systems 7090i Istruzioni per il montaggio

Se-Kure Controls

Se-Kure Controls MicroMini SK-4841 Manuale utente

Siemens

Siemens FDM273 Manuale utente
