Boss Audio Systems BV9993 Manuale utente

BV9993

SRC

ANGLE

REL

AUX

BV9993

SRC REL

AUX

Accessory

Wiring Diagram

SETUP NEED PASSWORD 25

Accessory

Accessory Quantity

User Manual 1PC

Wire

USB Cable

Keys

Install metal bar

Remote controller

Warranty card

2PCS

1PC

2PCS

Setup need password

During actual operation, when you enter TV setup,

system setup, radio area and touch calibration, you

need to enter the password "888888".

DVD Parental control function：The default set

for DVD is #8 adult, which means all grades of

DVD can be read without entering password.To

change the default grade,you need to follow the

below procedure: Press SETUP button on the

remote, display will show the system set up menu

and the submenu,select password and enter

0000, you will be able to choose the DVD

grade as default.

SETUP NEED PASSWORD

Wiring Diagram

This player is equipped with ISO standard connector, please follow below instruction:

● Yellow – 12 V Constant

● Black – Ground wire

● Blue - Power Antenna / Remote Amp Turn On

● Orange – Back-Up Camera Trigger (+)

● Red - ACC ON (+12V)

● White/White black - Left front speaker (+-)

● Purple/Purple black - Right rear speaker (+/-)

● Green/Green black - Left rear speaker (+/-)

● Grey/Grey black - Right front speaker (+/-)

RESET SD

PIC

1/INT

2/RPT

3/RDM

4/ OS D

FM /A M

DVD

AUX

BV9993

SRC

IR REL

ANGLE

PROBLEM CAUSE SOLUTION

After ignition switch

off ,setting

information all lose

Reset information and save

Change battery or fuse

Cannot power on

Change fuse same as the old one

Some factors cause MPU

wrong operation

Press RES button on the panel by

penpoint, then, power on

Poor performance

of radio station

Connot load disk There is a disk inside Remove disc before inserting another one

Weak signal Move the car to another place, then research

Cannot play disc

Disc is scratched Change new disc

Put wrong side of disc into

the unit Insert in the disk with sign side up

Clean lens by lens clean disc

Lens is dirty

Cannot switch

language/subtitle There is only one language/

subtitle in disc

If disc is not with multi-language/subtitle,

it cannot switch language/subtitle

No image Other factors cause MPU

wrong operation Press [RES] button on the panel by

penpoint, then, power on

Cannot watch

image during

driving

It’s not allowed to watch image

during driving

Park the car in a safe place, put the car stall

in “ P ” postion, pull up the hand brake,

parking brake wire must be grounded

Check fuse

AUX

1/INT

2/RPT

3/RDM

4/ OS D

FM /A M

DVD

(Detachable front panel)

19 20

3 4

17 17

BV9993

REL

SRC

10.

2. Sound effect setup

Repeatedly short press the button to select:

Bas→Tre→Bal→Fad→Bright→Hue→Cont→Sharp→Vol

You can make setup as you like, once a certain function is selected, work with the encoder

knob to adjust.

13.

15.

16.

17.

18.

20.

22.

23.

14.

21.

19.

AUX

12.

11.
