Boston Acoustics G110 Manuale utente

Key System Benefits

•1

3⁄4-inches of peak-to-peak

excursion for deep, accurate,

and powerful bass

• 2-inch, 4-layer voice coil

• Patented RadialVent®cooling, for

increased power handling

• SureSet™impedance selection

system and overdrive protection

Key Installation Benefits

•Optimized for small, sealed

enclosures. Like the G5 and G2,

only 1.0ft.3is required for the

12-inch, and 0.5ft.3for the 10-inch

• Slim chassis design allows G1 to

fit where others cannot such as

truck boxes and slim enclosures

•Integral sealing gaskets simplify

both standard and inverted mounting

• Multiple enclosure types and

tuning options make it possible

for G1 woofers to be tailored

to any application

Value Driven Performance

Introducing the newest member of the Boston Acoustics subwoofer family—the G1.

G1 woofers sport a 2-inch, 4-Layer voice coil, patented RadialVent®cooling, and unique

SureSet™impedance selection/overdrive protection; features that not only allow the

woofer to handle more power but also add a level of reliability not available from

competitors at any price point. Like all Boston subwoofers, G1 uses an extremely

efficient design allowing for high output with small to moderate power amplifiers. Most

importantly,with a depth of only 4 3⁄4-inches for the 10-inch and 5-inches for the 12-inch,

its shallow design helps G1 fit where other woofers won't, such as truck boxes. Add in

stunning design, high-end features like spring loaded terminals, and the flexibility to

work with multiple enclosure types and you have a subwoofer that redefines entry level.

G1 Subwoofer Specifications

Mounting RMS Power Frequency Enclosure Enclosure

Model Size Impedance Depth Handling Response* Size (Sealed) Size (Ported)

G112-44 12” 2Ω/8Ω5” 200 Watts 20Hz-350Hz 1.0 Ft32.0 Ft3(4” x 13” Port)

G112-4 12” 4Ω5” 200 Watts 20Hz-350Hz 1.0 Ft32.0 Ft3(4” x 13” Port)

G110-44 10” 2Ω/8Ω43⁄4” 200 Watts 24Hz-350Hz 0.5 Ft31.3 Ft3(3” x 10” Port)

G110-4 10” 4Ω43⁄4” 200 Watts 24Hz-350Hz 0.5 Ft31.3 Ft3(3” x 10” Port)

*In-car response

logo, and RadialVent are registered trademarks of Boston Acoustics, Inc. All specifications are subject to change.

Boston Acoustics, Inc. 300 Jubilee Drive, Peabody, MA 01960 Phone # 978-538-5000 Fax # 978-538-5100 Web : www.bostonacoustics.com

Patented RadialVent®cooling

Integrated vents and the woofer’s own pistonic action re-circulate fresh cooling air

around the woofer voice coil. As a result, it can handle more power.

SureSet™

Using mini ATC fuses, the SureSet™system allows for simple

impedance selection (dual 4-ohm only) as well as momentary

overdrive protection.

Rugged input terminals

Spring loaded input terminals accept bare 8-gauge wire or

pin connectors.

Single or dual 4-ohm voice coil versions

G1 subwoofers are available in both single 4-ohm or dual 4-ohm

versions, allowing the user to optimize the impedance load to the

amplifier, regardless of the number of subwoofers used in the system.

2-inch voice coil

The G1 uses a 2-inch, four-layer voice coil for great power handling,

uncommonly large for its price point.
