BOXLIGHT Cinema 12SF Manuale utente

Cinema 12SF

USER’S

GUIDE

USER’S

GUIDE

5466User.qxd 11/1/01 11:36 AM Page 1

Cinema 12SF

ser’s

uide

5466User.qxd 11/1/01 11:36 AM Page 2

FCC Warning

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential instal-

lation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which can be deter-

mined by turning the equipment off and on, the user is encouraged to try to cor-

rect the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

Canada

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Can-

ada.

Safety Certifications

UL, CUL, TÜV, NOM, IRAM

Declaration of Conformity

Manufacturer:BOXLIGHT

19332 Powder Hill Place, Poulsbo, Washington, USA

We declare under our sole responsibility that the Studio Experience Cinema 12SF

projector conforms to the following directives and norms:

EMC Directive 89/336/EEC, Amended by 93/68/EEC

EMC: EN 55022

EN 55024

EN 61000-3-2

EN 61000-3-3

Low Voltage Directive 73/23/EEC, Amended by 93/68/EEC

Safety: EN 60950: 1992 + A1 + A2 + A3 + A4: 1997

November, 2001

Trademarks

Apple, Macintosh, and PowerBook are trademarks or registered trademarks of

Apple Computer, Inc. IBM and PS/2 are trademarks or registered trademarks of

International Business Machines, Inc. Microsoft, PowerPoint, and Windows are

trademarks or registered trademarks of Microsoft Corporation. Digital Light Pro-

cessing is a trademark or registered trademark of Texas Instruments. Faroudja is a

trademark or registered trademark of Faroudja Laboratories, Inc.

TA B L E O F C O N T E N T S

Safety Instructions iii

Introduction 1

Image Resolution 1

Compatibility 1

Unpacking the Projector 1

Usage Guidelines 4

If You Need Assistance 4

Warranty 4

Setting up the Projector 5

Connecting the Enhanced Connectivity Module 7

Connecting a Video Device 9

Displaying a TV signal 11

Displaying a DVD or VHS tape 15

Projecting HDTV 19

Projecting a video game 21

Connecting a camcorder 21

Connecting a Computer 23

Displaying your Computer Source 24

Turning Off the Projector 26

Using the Projector 27

Basic Image Adjustment 27

Adjusting the Projector 27

Using the Remote Control 29

Using the Keypad and Remote Buttons 30

Using the On-Screen Menus 33

Display Menu 34

Audio Menu 36

Image Menu for Video Sources 37

Image Menu for Computer Sources 42

Color Management Menu 44

Control Menu 45

Advanced Menu 46

Language Menu 47

Status Menu 48

Ta b l e o f C o n t e n t s

Maintenance & Troubleshooting 49

Cleaning the Lens 49

Replacing the Projection Lamp 49

Cleaning the Projection Lamp Filter Screens 52

Replacing the Batteries in the Remote Control 53

Troubleshooting 54

Appendix 61

Specifications 61

Accessories 62

Audio/video inputs on the Enhanced Connectivity Module 63

Projected Image Size 64

Index 67

iii

SAFETY INSTRUCTIONS

Please read and follow all safety instructions provided BEFORE

using your new projector. Failure to comply with safety instruc-

tions may result in fire, electrical shock, or personal injury and

may damage or impair protection provided by equipment. Please

save all safety instructions.

Safety Definitions:

•Warning: Statements identify conditions or practices that

could result in personal injury.

•Caution: Statements identify conditions or practices that could

result in damage to your equipment.

Safety Symbols:

Attention: For information about usage of a feature, please

refer to the User’s Guide.

Warning: Hot surface. Do not touch.

An arrow pointing to the lamp door on the projector.

Safety Terms:

•Warning: Don’t look directly into the lens when the lamp is

turned on.

•Warning: To replace the lamp, turn off the projector

and unplug the power cord. To avoid burns, wait 30

minutes before opening the lamp door. Follow all instructions

provided in this User’s Guide.

•Warning: Please use the power cord provided. Connect

the power cord to a receptacle with a protective safety

(earth) ground terminal.

Safety Instructions

•Warning: Refer all service to qualified service personnel. Ser-

vicing your own projector will void the warranty. See below

for the technical support contact information.

•Caution: Don’t block ventilation openings. Use of an unautho-

rized ceiling mount may lead to ventilation blockage and/or

personal injury.

•Caution: Don’t subject projector to prolonged exposure to

smoke.

•Caution: Don’t set liquids on the projector. Spilled liquids may

damage your projector.

•Caution: Don’t place the projector on a hot surface or in direct

sunlight.

•Caution: Do not drop the projector. Transport the projector in

a Studio Experience-approved case; see page 63 for a list of

cases.

Important Operating Considerations

Do not place the projector on a tablecloth or other soft covering

that may block the vents. Use only a Studio Experience-approved

ceiling mount. In the unlikely event of the bulb rupturing, thor-

oughly clean the area around the projector and discard any edi-

ble items placed in that area.

Technical Support

If you need assistance, call BOXLIGHT Technical Support at

1-800-762-5757 or 360-779-7901.

Do not place objects in

this area in front of the projector

2ft(.6m)
