Braun 5647 Manuale utente

Activator 8970-75 NA KURTZ DESIGN 15.03.06

off

trim fix on

8975

0 20 40 60 80 100

reset

replace foil + cutter

Type 5647, 5649

Modèle 5647, 5649

Modelo 5647, 5649

8975

8970

www.braun.com/register

5-647-448/00/III-06

5647448_Com_8975_NA_S1 Seite 1 Donnerstag, 16. März 2006 1:27 13

English 4

Français 12

Español 19

USA/CDN/MEX

Printed in Germany

Thank you for purchasing a Braun product.

We hope you are completely satisfied with

your new Braun shaver.

If you have any questions, please call:

US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun.

Nous espérons que vous serez pleinement

satisfaite de votre nouveau rasoir Braun.

Si vous avez des questions, veuillez appeler

Braun Canada : 1-800-387-6657

Gracias por haber comprado un producto

Braun.

Esperamos que Ud. quede completamente

satisfecha con su nueva afeitadora Braun.

Si Ud. tiene alguna duda, por favor llame al:

01(800) 508-5800

5647448_Com_8975_NA_S2 Seite 1 Donnerstag, 16. März 2006 1:28 13

off

trim fix on

8970

reset

replace foil+ cutter

off

trim fix on

8975

reset

replace foil+ cutter

Activator plus 8975/8970 NA Explo KURTZ DESIGN 15.03.06

8000

Series

0 20

empty charge

40 60 80 100

8000

Series

8975

8970

360°Complete

5647448_Com_8975_NA_S3 Seite 1 Donnerstag, 16. März 2006 1:29 13

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should always be

followed, including the following:

Read all instructions before using this appliance.

DANGER

To reduce the risk of electric shock:

1. Do not reach for an appliance that has fallen into water.

Unplug immediately.

2. Do not use while bathing or in a shower when the appliance is connected to an

electrical outlet.

3. Do not place, store or charge the appliance where it can fall or be pulled

into a tub or sink. Do not place in or drop into water or other liquid.

4. When not using for a longer period of time, unplug this appliance from the

electrical outlet.

5. Unplug this appliance before cleaning.

6. This appliance is provided with a special cord set with integrated Safety Extra

Low Voltage power supply. Do not exchange or manipulate any part of it.

FOR HOUSEHOLD USE

SAVE THESE INSTRUCTIONS

English

5647448_Com_8975_NA Seite 4 Donnerstag, 16. März 2006 1:41 13

WARNING

To reduce the risk of burns, ﬁre, electric shock, or injury to persons:

1. Close supervision is necessary when this appliance is used by, on, or near

children or invalids.

2. Use this appliance only for its intended use as described in this manual.

Do not use attachments not recommended by the manufacturer.

3. The appliance should never be exposed to temperatures of less than

32 ºF / 0 ºC and more than 105 ºF/+40ºC for longer than a few hours.

Be sure to completely dry appliance after use. Keep cord and adapter dry at

all times. Do not store in a damp environment. To avoid damage do not wind

the cord around the appliance. It is important to check the cord for damage

periodically particularly at each end where the cord enters the plug.

4. Never operate this appliance if it has a damaged cord or plug, if it is not wor-

king properly, if it has been dropped or damaged, or dropped into water.

Return the appliance to a service center for examination and repair.

5. Keep the cord away from heated surfaces.

6. Never drop or insert any object into any opening.

7. Do not use outdoors or operate where aerosol (spray) products are being

used or where oxygen is being administered.

8. Do not use this appliance with a damaged or broken foil, as serious facial

injuries may occur.

9. Always attach plug to appliance ﬁrst, then to outlet.

To disconnect, turn all controls to «off», then remove plug from outlet.

5647448_Com_8975_NA Seite 5 Donnerstag, 16. März 2006 1:41 13

Description

1 Foil protection cap

2 Shaver foil

3 Cutter block

4 Release buttons

5 Long hair trimmer

6 Switch

7 Charging lights (green)

8 Low charge light (red)

9 Replacement light for shaving parts

10 Reset button

11 Pilot light

12 Shaver socket

13 Special cord set

Charging the shaver

• When charging for the first time: Using the special cord

set, connect the shaver to an electrical outlet.

The shaver must be switched off. Charge it for at least

4 hours (special cord set and shaver might get warm).

Once the shaver is completely charged, shave until

fully discharged. Then recharge to full capacity again

(1 hour).

• A full charge will give up to 50 minutes of cordless

shaving time, depending on your beard growth.

However, the maximum battery capacity will only be

reached after several charging/discharging cycles.

• Best environmental temperature range for charging is

from 60 °F to 95 °F / 15 °C to 35 °C.

• When fully discharged, you may also shave with the

shaver connected to an electrical outlet via the special

cord set.

Indicator lights

Pilot light (11): The shaver is connected to an electrical

outlet.

Model 8975: When the shaver is fully charged, all five

charging lights (7) will light up (20% per light), provided

the shaver is connected to an electrical outlet or switched

on.

8975

reset

replac

0...20 40 6

0...20 40 60 80

100

replace foil+cutt

replace foil+cu

empty charge

5647448_Com_8975_NA Seite 6 Donnerstag, 16. März 2006 1:41 13

Model 8970: The green single charging light (7) shows that

the shaver is being charged. When fully charged, the

charging light flashes or goes off. If later on, the charging

light comes on again, this indicates that the shaver is

being recharged to maintain its full capacity.

The red low charge light (8) flashes when the battery

capacity has dropped below 20%, provided the shaver is

switched on. The remaining capacity will then be sufficient

for 2 to 3 shaves.

Shaving

Switch positions

off = (switch is locked)

Press and push up the switch to operate the shaver:

on = Shaving with the pivoting head

(the pivoting cutting system automatically adjusts

to every contour of your face).

fix = Shaving with the pivoting head locked at an angle

(to permit shaving in difficult areas, e.g. under the

nose).

trim= The long hair trimmer is activated

(for trimming sideburns, moustache and beard).

Tips for the perfect shave

• It can take up to 14-21 days for your beard to adjust

to the new shaving system.

• Shave before washing your face or taking a shower,

as skin tends to swell after washing.

• The drier the skin, the closer the shaving results will

be.

• Hold the shaver at right angles (90°) to the skin.

Stretch the skin and shave against the direction of

beard growth.

• To maintain 100% shaving performance, replace

your foil and cutter block, when the replacement light

(9) comes on (after about 18 months), or when worn.

0...20 40 60 80

100

replace foil+cut

replace foil+cu

empty charge

fix on

trim fix on

5647448_Com_8975_NA Seite 7 Donnerstag, 16. März 2006 1:41 13

Cleaning

Never use water to clean the shaver.

For easy cleaning after each shave, switch the shaver off.

Press the release buttons to lift the shaver foil (do not

remove the foil completely). Switch on the shaver for

approx. 5–10 seconds so that the shaved stubbles can

fall out.

Then remove the shaver foil and tap it out on a flat surface.

Using the brush, clean the inner area of the pivoting head.

However, do not clean the shaver foil nor the cutter block

with the brush as this may damage them.

Put a drop of light machine oil onto the long hair trimmer

and the shaver foil.

Replacement light for shaving parts / Reset

To maintain 100% shaving performance, replace your foil

and cutter block, when the replacement light for shaving

parts (9) comes on (after about 18 months) or when worn.

Change both parts at the same time for a closer shave with

less skin irritation.

(Shaver foil and cutter block: 8000 series)

The replacement light will remind you during the next 7

shaves to replace the shaving parts. Then the shaver will

automatically reset the display.

After you have replaced the shaving parts (foil and cutter

block), use a ball-pen to push the reset button (10) for at

least 3 seconds to reset the counter.

While doing so, the replacement light blinks and goes off

when the reset is complete. The manual reset can be done

at any time.

fix on off

on off

oil

fix on

off

fix on

off

0...20 40 60 80

treplace foil

8000

Series

360°Complete

5647448_Com_8975_NA Seite 8 Donnerstag, 16. März 2006 1:41 13

Preserving the batteries

In order to maintain the optimum capacity of the re-

chargeable batteries, the shaver has to be fully discharged

(through normal use) every 6 months approximately.

Then recharge the shaver to full capacity. Do not expose

the shaver to temperatures higher than 50 °C for extended

periods of time.

Environmental notice

This appliance is provided with nickel-hydride batteries.

They do not contain any harmful heavy metals.

Nevertheless, in the interest of recycling raw materials,

please do not dispose of this appliance in the household

waste at the end of its useful life. Disposal can take place

at a Braun Service Center of appropriate collection sites.

Subject to change without notice.

For electric specifications, see printing on the special cord

set.

5647448_Com_8975_NA Seite 9 Donnerstag, 16. März 2006 1:41 13

FOR USA ONLY

2 year limited warranty (foil and cutter block excluded)

Braun warrants this Braun shaver (except foil and cutter block) to be free of

defects in material and workmanship for a period of two years from the date of

original purchase.

If the shaver exhibits such a defect, Braun will, at its option, either repair or replace

it for the consumer without charge.

Please call 1-800-Braun 11 (800-272-8611) to be referred to the authorized Braun

Service Center closest to you.

This warranty does not cover foils, cutter blocks or damage resulting from

accident, misuse, abuse, dirt, water, tampering, unreasonable use, normal wear,

servicing performed or attempted by unauthorized service agencies or failure to

provide reasonable and necessary maintenance, including recharging.

ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF

MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, ARE

LIMITED IN DURATION TO 2 YEARS FROM DATE OF ORIGINAL PURCHASE.

IN NO EVENT WILL BRAUN BE RESPONSIBLE FOR CONSEQUENTIAL

DAMAGES RESULTING FROM THE USE OF THIS PRODUCT. Some states

do not allow the exclusion or limitation of incidental or consequential damages, so

the above limitation or exclusion may not apply to you.

This warranty gives you specific legal rights, and you may also have other

legal rights which vary from state to state.

5647448_Com_8975_NA Seite 10 Donnerstag, 16. März 2006 1:41 13

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Braun Rasoio elettrico

Braun

Braun 3030 Manuale utente

Braun

Braun InterFace 3610 Manuale utente

Braun

Braun MGK 3085 Manuale utente

Braun

Braun BT 5050 Manuale utente

Braun

Braun Series 5 540 Manuale utente

Braun

Braun 360 Complete 8995 Manuale utente

Braun

Braun ContourX Pro Manuale utente

Braun

Braun 5542 Manuale utente

Braun

Braun DigiFrame 1008 Manuale utente

Braun

Braun 9 Pro Series Manuale utente

Braun

Braun 5644 Manuale utente

Braun

Braun Gillette 3 Series Manuale utente

Braun

Braun 7 Manuale utente

Braun

Braun Pro Wet&Dry 9419s Manuale utente

Braun

Braun Gillette FreeControl 190 Manuale utente

Braun

Braun SensoFlex 5762 Manuale utente

Braun

Braun BT 7050 Manuale utente

Braun

Braun cruzer 5 Manuale utente

Braun

Braun Flex Integral 5312 Manuale utente

Braun

Braun BT 5070 Manuale utente

Braun

Braun Exact Power EP 100 Manuale utente

Braun

Braun MGK 3085 Manuale utente

Braun

Braun BS 8995 Manuale utente

Braun

Braun Silk-epil 5-541 Manuale utente

Manuali Rasoio elettrico popolari di altre marche

Philips

Philips MicroAction 4402LC Manuale utente

Philips

Philips HQ7740 Manuale utente

Philips

Philips Norelco BG2022 Bodygroom Manuale utente

Norelco

Norelco Quadra 7610X Manuale utente

Philips

Philips 7616X Manuale utente

Philips

Philips HQ802 Manuale utente

Philips

Philips HQ7363/17 Manuale utente

Philips

Philips NORELCO S7371 Manuale utente

Daga

Daga MT-400 Manuale

Philips

Philips RQ119x Manuale utente

Remington

Remington BHT100 Manuale utente

Philips

Philips Bodygroom BG2000 Manuale utente

Kompernass

Kompernass KH 5537 Manuale utente

Remington

Remington BHT6100 Manuale utente

Philips

Philips qc5365 Manuale utente

MIA

MIA Aqua Body Manuale utente

Philips

Philips NORELCO AT880 Manuale utente

Matheo

Matheo MLR 15 Manuale utente
