Thank you for purchasing a Braun product.

We hope you are completely satisfied with

your new Braun shaver.

If you have any questions, please call:

US residents 1-800-BRAUN-11

1-800-272-8611

Canadian residents 1-800-387-6657

Merci d’avoir fait l’achat d’un produit Braun.

Nous espérons que vous serez entièrement

satisfait de votre nouveau rasoir Braun.

Si vous avez des questions, veuillez appeler

Braun Canada au : 1-800-387-6657

Gracias por haber comprado un producto

Braun.

Esperamos que quede completamente

satisfecho con su nueva afeitadora Braun.

Si tiene alguna duda, por favor llame al:

01(800) 508-5800

English 4

Français 16

Español 23

96369260/VI-13

USA/CDN/MEX

96369260_740s-6_NA_S2.indd 196369260_740s-6_NA_S2.indd 1 05.06.13 14:0205.06.13 14:02

trimmer

Series 7

trimmer

off

trimmer

Series 7

wet & dry

wet&dry

96369260_740s-6_NA_S3.indd 196369260_740s-6_NA_S3.indd 1 16.05.13 08:1316.05.13 08:13

English

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions should

always be followed, including the following:

Read all instructions before using this appliance.

When disconnected, the hand-held part of this shaving

appliance may be used in a bath or shower. For safety

reasons, the appliance can only be operated cordlessly.

DANGER

To reduce the risk of electric shock:

1. The charger unit is not for immersion in water or for use in

shower.

2. Do not reach for a charger that has fallen into water. Unplug

immediately.

3. Do not place, store or charge the appliance where it can fall or

be pulled into a tub or sink. Do not place in or drop into water or

other liquid.

4. Except when charging, always unplug this appliance from the

electrical outlet immediately after using.

5. This appliance is provided with a special cord set with

integrated Safety Extra Low Voltage power supply. Do not

exchange or manipulate any part of it.

6. Do not use an extension cord with this appliance.

96369260_740s-6_NA_S4-38.indd 496369260_740s-6_NA_S4-38.indd 4 05.06.13 14:0705.06.13 14:07

WARNING

To reduce the risk of burns, fire, electric shock, or injury to

persons:

1. Close supervision is necessary when this appliance is used by,

on, or near children or persons with disabilities.

2. Use this appliance only for its intended use as described in

this manual. Do not use attachments not recommended by the

manufacturer.

3. Never operate this appliance if it has a damaged cord or plug,

if it is not working properly, if it has been dropped or damaged,

or if the power supply has been dropped into water. Return the

appliance to a service center for examination and repair.

4. Keep the cord away from heated surfaces.

5. Never drop or insert any object into any opening of the

appliance.

6. Do not use outdoors or operate where aerosol (spray)

products are being used or where oxygen is being

administered.

7. Do not use this appliance with a damaged or broken foil, as

serious skin injuries may occur.

8. Always attach plug to appliance first, then to outlet.

To disconnect, turn all controls off, then remove plug from

outlet.

9. When plugging to an electrical outlet outside North America,

use a plug adapter to match the outlet’s pin configuration.

10. Caution: The battery used in this device may present a fire or

chemical burn hazard if mistreated. Do not disassemble, heat

above 100 °C (212 °F), or incinerate.

11. Only use the special electric cord set provided with the

appliance.

12. Oil bottle

Keep out of reach of children. Do not swallow. Do not apply to

eyes. Dispose of properly when empty.

SAVE THESE INSTRUCTIONS

96369260_740s-6_NA_S4-38.indd 596369260_740s-6_NA_S4-38.indd 5 05.06.13 14:0705.06.13 14:07

Our products are designed to meet the highest

standards of quality, functionality and design.

We hope you enjoy your new Braun Shaver.

This appliance is designed for household use

only.

Description

1Foil & Cutter cassette

2Cassette release button

3Shaver head lock switch

4Pop-out long hair trimmer

5On/off switch

6(–) setting button (sensitive)

7(+) setting button (intensive)

8Reset button

9Shaver display

0Shaver power socket

qTravel case

w Special cord set

Charging

Recommended ambient temperature for

charging is 41 °F to 95 °F / 5 °C to 35 °C.

The battery may not charge properly or at

all under extreme low or high temperatures.

Recommended ambient temperature for shaving

is 60 °F to 95 °F / 15 °C to 35 °C.

Do not expose the shaver to temperatures higher

than 122 °F / 50 °C for extended periods of time.

• Using the special cord set w, connect the

shaver to an electrical outlet with the motor

switched off and charge it for at least one hour.

• A full charge provides up to 50 minutes

of cordless shaving time. This may vary

according to your beard growth.

Shaver display

The shaver display 9shows the charge status

of the battery. During charging or when using the

shaver, the respective green charge status will

blink. When the battery is fully charged the green

charge status will light up continuously, provided

the shaver is connected to an electrical outlet.

Some minutes after completing the charging,

the shaver switches to the stand-by-mode:

The display turns off.

96369260_740s-6_NA_S4-38.indd 696369260_740s-6_NA_S4-38.indd 6 05.06.13 14:0705.06.13 14:07

The red indicator ﬂashes when the battery is

running low, provided the shaver is switched on.

The remaining capacity will then be sufﬁcient for

2 to 3 shaves.

Using your shaver

Personalizing your shaver

With the (–) 6and (+) 7buttons you can choose

the best setting for shaving different areas of

your face and as per your speciﬁc needs.

The different settings are indicated by the pilot

light incorporated in the on/off switch 5:

• dark blue (powerful shave)

• light blue (normal)

• white (for a thorough comfortable shave in

sensitive areas of your face such as neck)

For a thorough and fast shave we recommend

the (+) setting.

When switching on next time, the last used

setting will be activated.

Tips for the perfect dry shave

For best shaving results, Braun recommends you

to follow 3 simple steps:

1. Always shave before washing your face.

2. At all times, hold the shaver at right angles

(90°) to your skin.

3. Stretch your skin and shave against the direc-

tion of your beard growth.

How to use

Press the on/off switch 5to operate the shaver:

• The pivoting shaver head and ﬂoating foils

automatically adjust to every contour of your

face.

• To shave hard to reach areas (e.g. under the

nose) slide the shaver head lock switch 3to

the back position to lock the pivoting head at

an angle.

• To trim sideburns, moustache or beard, slide

the pop-out long hair trimmer 4upwards.

+normal

release

90°

lock

trimmer

lock

96369260_740s-6_NA_S4-38.indd 796369260_740s-6_NA_S4-38.indd 7 05.06.13 14:0705.06.13 14:07

Cleaning

Regular cleaning ensures better shaving

performance. Rinsing the shaver head under

running water after each shave is an easy and

fast way to keep it clean:

• Switch the shaver on (cordless) and rinse the

shaver head under hot running water until all

residues are removed. You may use liquid soap

without abrasive substances. Rinse off all foam

and let the shaver run for a few more seconds.

• Next, switch off the shaver, press the release

button 2to remove the Foil & Cutter cassette

1and let it dry. The shaver shall not be used

until it has dried.

• If you regularly clean the shaver under

water, then once a week apply a drop of

light machine oil on top of the Foil & Cutter

cassette.

Alternatively, you may clean the shaver with a

brush:

• Switch off the shaver. Remove the Foil & Cutter

cassette 1and tap it out on a ﬂat surface.

Using the brush, clean the inner area of the

pivoting head. However, do not clean the foil

and cutter cassette with the brush as this may

damage it.

Keeping your shaver in top shape

Replacing the Foil & Cutter cassette / reset

To maintain 100% shaving performance,

replace the Foil & Cutter cassette 1, when the

replacement symbol lights up on the shaver

display 9(after about 18 months) or when

cassette is worn.

The replacement symbol will remind you during

the next 7 shaves to replace the Foil & Cutter

cassette. Then the shaver will automatically reset

the display.

After you have replaced the Foil & Cutter

cassette, use a ball-pen to push the reset button

8for at least 3 seconds to reset the counter.

While doing so, the replacement light blinks and

goes off when the reset is complete. The manual

reset can be done at any time.

trimmer

Series 7

Series

click!

clic!

Series 7

Series 7 70S

96369260_740s-6_NA_S4-38.indd 896369260_740s-6_NA_S4-38.indd 8 05.06.13 14:0705.06.13 14:07

Accessories

Available at your dealer or Braun Service

Centers:

• Foil & Cutter cassette 70S

Environmental notice

This appliance contains rechargeable

batteries. To protect the environment,

do not dispose of the appliance in the

household waste at the end of its useful life.

Disposal can take place at a Braun Service

Center or appropriate collection sites.

Subject to change without notice.

For electric speciﬁcations, see printing on the

special cord set.

96369260_740s-6_NA_S4-38.indd 996369260_740s-6_NA_S4-38.indd 9 05.06.13 14:0705.06.13 14:07

Trouble-Shooting

Problem: Possible reason: Remedy:

SHAVER

Unpleasant

smell from the

shaver head.

Shaver head is cleaned

with water.

When cleaning the shaver head

with water only use hot water and

from time to time some liquid soap

(without abrasive substances).

Remove Foil & Cutter cassette to

let it dry.

Battery

performance

dropped

significantly.

1. Foil and cutter are

worn which requires

more power for each

shave.

Shaver head is

regularly cleaned with

water but not

lubricated.

1. Renew Foil & Cutter cassette.

2. If the shaver is regularly cleaned

with water, apply a drop of light

machine oil on top of the foil

once a week for lubrication.

Shaving

performance

dropped

significantly.

1. Foil and cutter are

worn.

2. Personal setting of

shaving performance

has been changed.

3. Shaving system is

clogged.

1. Renew Foil & Cutter cassette.

2. For a thorough and fast shave

we recommend the green

(intensive) setting.

3. Soak the Foil & Cutter cassette

into hot water with a drop of

dish liquid. Afterwards rinse it

properly and tap it out. Once

dry apply a drop of light

machine oil on the foil.

Shaver turns off

with fully

charged battery.

Foil and cutter are worn

which requires more

power than the motor

can deliver. The

appliance turns off.

– Renew Foil & Cutter cassette.

– Regularly oil the shaving

system, especially when

cleaning with water only.

Battery

segments in the

display are

skipped with

decreasing

battery capacity.

Foil and cutter are worn

which requires more

power for each shave.

– Renew Foil & Cutter cassette.

– Regularly oil the shaving

system, especially when

cleaning with water only.

Shaving parts

have been

changed recently

but replacement

symbol lights up.

Reset button has not

been pushed.

– Push the reset button for at

least 3 seconds to reset the

counter.

96369260_740s-6_NA_S4-38.indd 1096369260_740s-6_NA_S4-38.indd 10 05.06.13 14:0705.06.13 14:07

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Braun Rasoio elettrico

Braun

Braun Flex Integral 6550 Guida rapida

Braun

Braun Prosonic 9566 Manuale utente

Braun

Braun BGK 7090 Manuale utente

Braun

Braun BS1000 Manuale utente

Braun

Braun MG5090 Manuale utente

Braun

Braun 9359PS Manuale utente

Braun

Braun Exact Power EP 60 Manuale utente

Braun

Braun Flex XP 5720 Manuale utente

Braun

Braun Gillette 3 Series Manuale utente

Braun

Braun MGK 3020 Manuale utente

Braun

Braun 5715 Manuale utente

Braun

Braun BS7497 Manuale utente

Braun

Braun 9 SERIES Manuale utente

Braun

Braun 310 wet&dry Manuale utente

Braun

Braun Contour Pro Special Edition Series Manuale utente

Braun

Braun 5647 Manuale utente

Braun

Braun 5673 Manuale utente

Braun

Braun Pro Wet&Dry 9470cc Manuale utente

Braun

Braun Exact Power battery EP 15 Manuale utente

Braun

Braun 340s-3 Manuale utente

Braun

Braun 9 Pro 9470CC Manuale utente

Braun

Braun 3775 Manuale utente

Braun

Braun MGK5260 Manuale utente

Braun

Braun 9460cc Manuale utente

Manuali Rasoio elettrico popolari di altre marche

Philips

Philips MicroAction 4402LC Manuale utente

Philips

Philips HQ7740 Manuale utente

Philips

Philips Norelco BG2022 Bodygroom Manuale utente

Norelco

Norelco Quadra 7610X Manuale utente

Philips

Philips 7616X Manuale utente

Philips

Philips HQ802 Manuale utente

Philips

Philips HQ7363/17 Manuale utente

Philips

Philips NORELCO S7371 Manuale utente

Daga

Daga MT-400 Manuale

Philips

Philips RQ119x Manuale utente

Remington

Remington BHT100 Manuale utente

Philips

Philips Bodygroom BG2000 Manuale utente

Kompernass

Kompernass KH 5537 Manuale utente

Remington

Remington BHT6100 Manuale utente

Philips

Philips qc5365 Manuale utente

MIA

MIA Aqua Body Manuale utente

Philips

Philips NORELCO AT880 Manuale utente

Matheo

Matheo MLR 15 Manuale utente
