6. Verify display switch data to table height
Alta Digital Handset Operation Continued
7. Lock the stroke
8. Unlock the stroke
and hold▼, keep about 3 seconds and inches
2 Release the buttons completed
Values in inches will be displayed in increments of 0.5" inches. Values in
centimeters will be displayed in 1.0 centimeter increments.
Step Operation Motion
1 Set the table at any height,
recommended at the bottom position
Measure the table actual height and write down the number in
inches or in centimeters
2 Press and hold button S, then press
and hold ▲, keep about 3 seconds
The first number is flashing on the screen
3 Release the buttons, then click ▲or
▼to change the first number
The first number is being increased or decreased to the first
number you measured
4 Click button S The second number is flashing on the screen
5 Click ▲or▼to change the number The second number is being increased or decreased to the
second number you measured
6 Click button S The third number is flashing on the screen
7 Click ▲or▼to change the number The third number is being increased or decreased to the third
number you measured
8 Click button S Completed
Step Operation Motion
1 Press and hold ▲or▼, then release Run the legs to the position you want the table surface to be
2 Press and hold button S, then press
and hold 1, keep about 3 seconds
Letter “L” is indicated on the screen. That means the position is
locked at the lowest position that the table can be moved to
3 Release the buttons Completed
1.Legs aren’t able to run below the locked position.
2.Any saved memory positions that are below the locked position will be lost even
after the table is unlocked.You will need to follow SET MEMORY POSITIONS to reset
them.
Step Operation Motion
1 Press and hold button S, then press
and hold 2, keep about 3 seconds
Letter “C” is indicated on the screen. That means the table’s
unlocked and can be moved in full range
2 Release the buttons Completed
