INSTRUCTIONS FOR USE

Fresh, healthy juice in seconds

Squeezed™

Model JC7

Breville is a registered trademark of Breville Pty. Ltd.

ABN 98 000 092 928

Due to continual improvements in design or otherwise,

the product you purchase may differ slightly from

the one illustrated in this booklet.

Breville Customer Service Centre

Australian Customers

✉Breville Customer Service Centre

Locked Bag 2000

Botany NSW 2019

AUSTRALIA

☎Customer Service: 1300 139 798

Fax (02) 9384 9601

Email Customer Service askus@breville.com.au

New Zealand Customers

✉Breville Customer Service Centre

Private Bag 94411

Greenmount

AUCKLAND, NEW ZEALAND

☎Customer Service: 09 271 3980

Fax 0800 288 513

Email Customer Service askus@breville.com.au

www.breville.com.au

PRINTED ON

RECYCLED PAPER

Model JC7

Issue 1/03

Page

Breville Recommends Safety First 4

Know Your Breville Juicer 5

Operating Your Breville Juicer 6

Care and Cleaning 7

Squeezed

CONTENTS

Congratulations

on your purchase of your new Breville Juicer

••Do not immerse the motor base, plug

or cord in water or any other liquid.

••Always use the appliance on a dry,

level surface.

••Always turn the power off at the power

outlet and then remove the plug when

the appliance is not being used and

before cleaning.

••Regularly inspect the supply cord, plug

and actual appliance for any damage. If

found damaged in anyway, immediately

cease use of the appliance and return the

entire appliance to the nearest authorised

Breville Service Centre for examination,

replacement or repair.

••The appliance is not intended for use

by young children or infirm persons

without supervision.

••Do not leave the appliance unattended

when in use. Young children should be

supervised to ensure that they do not play

with the appliance.

••Do not let the cord hang over the edge of

a table or counter, touch hot surfaces, or

become knotted.

••Do not place this appliance on or near

a hot gas or electric burner, or where it

could touch a heated oven.

••This appliance is for household use

only. Do not use this appliance for

anything other than its intended use.

Do not use outdoors.

••The installation of a residual current

device (safety switch) is recommended to

provide additional safety protection when

using electrical appliances. It is advisable

that a safety switch with a rated residual

operating current not exceeding 30mA be

installed in the electrical circuit supplying

the appliance. See your electrician for

professional advice.

BREVILLE RECOMMENDS SAFETY FIRST

We at Breville are very safety conscious. We design and manufacture consumer products with

the safety of you, our valued customer, foremost in mind. In addition, we ask that you exercise

a degree of care when using any electrical appliance and adhere to the following precautions:

IMPORTANT SAFEGUARDS

KNOW YOUR BREVILLE JUICER

Storage lid

Large cone ideal for extracting

the maximum juice from large

citrus fruits, such as grapefruit

and large oranges

Small cone perfect for smaller citrus

fruits, such as lemons and limes

Stainless steel strainer dish allows

the juice to flow through whilst

straining the pulp and seeds

Juicer surround

Juice outlet with stainless steel

lip and anti drip stop

Powerful motor automatically starts

when pressure is applied to the cone

Motor base with cord storage

BEFORE FIRST USE

Remove all promotional labels and wash

the juicer components in warm, soapy water.

Dry thoroughly.

1. Place the filter surround on the motor

base then sit the stainless steel strainer

dish on top of the filter surround.

2. Fit the small cone (fig 1) onto the drive

shaft and push down lightly. For larger

fruits, place the large cone on top of the

small cone, after the small cone has

been correctly positioned onto the

drive shaft (fig 2).

3. Ensure that the anti-drip stop is

pushed down.

4. Plug the juicer into a 230/240v power

outlet and switch on.

5. Cut the citrus fruit in half and press

fruit down onto the cone.

The motor will automatically start and

the juicing cone will begin to rotate.

To stop, lift the fruit off the cone.

Juicing will automatically stop.

HANDY HINTS

••Move the fruit from side to side against

the cone whilst juicing to extract

maximum juice.

••More juice is obtained from fruit juiced

at room temperature.

DO NOT PRESS SO HARD AS TO STOP THE MOTOR.

••After each use, switch off the juicer at

the power outlet and unplug.

••Disassemble the unit and wash all

removable parts in warm, soapy water.

••Do not place these parts in the

dishwasher as the high water temperature

and harsh detergents will ultimately warp

or scratch these parts. It is best to rinse

or wash all removable parts immediately

as dried citrus pulp is difficult to remove

and may stain. If any staining does occur,

wipe the affected part/s with undiluted

dishwashing liquid and rinse thoroughly.

••Wipe the motor base with a damp cloth.

CARE AND CLEANING

Never immerse the motor

base in water or any other

liquid. Do not use harsh

abrasives or detergents.

fig.1

fig.2

OPERATING YOUR BREVILLE JUICER
