BRIO 3 Stage System Manuale utente
3 Stage System
Filter Change
Step By Step Guide On Changing Your Filters
Let us help!
1-844-257-4103
cs@organize.com
R
Materials Needed
Materials Included
A
B
C
F
1
1
1
1
1
Part Description Quantity
A
B
C
D
E
Filter Flushing Tube
Shut-O Valve Tube (7 FT.)
Filter Housing (For Filter Flushing)
Sediment Filter
Carbon Filter
FFeed Water Adapter 1
If there is a drop in water pressure in your home
or on the pressure gauge, it is usually a sign that it is time
to replace your filters. It is recommended to replace filters
when the pressure has dropped between 10-20 PSI.
Handy Tip!
Enjoy consistent access to pure and refreshing
water when you replace filters in a timely manner.
On average, each filter is good for 6 months,
depending on various factors. The amount of
time varies greatly depending on the quality
of water, temperature and pressure of your
water supply. Due to these factors, filter
lifespan may be longer or shorter.
Thank you! D E F
Step 2 : Turn O Cooler
COLD HOT
Turn o the switches
located on the back
of the unit. Once the
switches have been
flipped to the o position,
unplug the unit from the outlet.
Step 3 : Drain Cooler Tank
Place a large bucket beneath
the drain outlet located on the
back of the dispenser and
remove the drain cover, begin
to drain water.
Locate the cold water
supply and shut o the
flow of water.
Step 1 : Turn O Water Supply
B
Step 4 : Remove Inlet Line
Once the cooler has been
drained, unplug the inlet line.
As a precaution, place a towel
underneath the inlet line to
absorb any potential water left
in the cooler.
C
D
B
A. Connect the filter (D)
to the filter housing
(C) by twisting the
filter (D) clockwise.
B
Step 5 : Flush New Filter
Flush each filter for a
minimum of 5 minutes.
The recommended rate
is 1.5-3 gallons of water
(about 10 minutes) or
until the water is clear in
appearance.
Shut o the valve at the
water source and remove
the filter housing from the
tube (B).
D.
E.
B.
C. Connect the filter
flushing tube (A) to the
right side of the filter
housing (C) and lay the
open end of the flushing
tube (A) over a sink or
receptacle to collect water.
Repeat process with the
second filter (E) and third filter (F).
Connect the tip of the
shut-o value tube (B)
to the left side of the
filter housing (C).
A
C
B
Step 6: Re-Install Inlet Line
Connect the tip of the
shut-o valve tube (B)
into the water inlet hole
on the back of the
dispenser. Once
connected, ensure the
valve on the tube (B) is
on and turn on the water
supply line.
Enjoy Your Water!
Once all the steps have
been followed and all the
connections have been
secured, turn on the water
supply line. Let water flow
through the cooler and
ensure that there are no
leaks at any of the
connection points. When
all points have been checked,
enjoy purified water in every cup!
Step 9 : Turn On Water Supply
Remove filters after turning
o the water supply. Simply
twist each filter clockwise in
the filter housings located
inside the dispenser cabinet.
Step 7 : Remove Used Filter
Twist each filter counter
clockwise into the filter
housings located inside
the dispenser cabinet.
Stage 1 goes on the left.
Stage 2 goes on the
right.
Step 8 : Install New Filter
