Model 14 Oxygen Analyzer
Chapter1:
Introduction
1.1 Introduction
The Model 14 Dissolved Oxygen Analyzer is a single-
channel analyzer for the measurement of dissolved oxy-
gen in fermentation vessels and bioreactors, as well as
in municipal applications.
1.2 Principle of Operation
The measurement of dissolved oxygen is based on the
well-known Clark cell principle. An oxygen-permeable
membrane isolates the electrodes from the sample,
thus eliminating the need for sample conditioning.
Other reducible or oxidizable ions do not interfere,
because they cannot pass through the gas-permeable
membrane.
A constant voltage supply powers two electrodes, main-
taining each at a constant potential. A platinum work-
ing electrode (cathode) reduces the dissolved oxygen
to hydroxyl ions :
O2+ 2H2O + 4e-=4OH-
A large silver counter electrode (anode) provides the
oxidation reaction:
4Ag++ 4Cl-=4AgCl + 4e-
The reduction of oxygen is the current limiting reac-
tion, thus making the cell current linearly proportional
to the dissolved oxygen concentration.
Electrochemical reactions and diffusion rates are tem-
perature-sensitive. The measuring cell, therefore, is
equipped with a temperature sensor which allows an
automatic temperature compensation.
1-1
Model 14 Oxygen Analyzer
1.3 Main Characteristics
■ Range: 0 - 299.99% saturation; 0 - 29.99 ppm
■ Calibration in the air
■ Temperature compensation
■Programmable alarm levels, outputs on relays
■ 4-20 mA, 0-20 mA analog outputs
(standard)
■ Wall- , panel- and pipe mounting
1.4 Technical Specifications
Power Supply 90 – 265 VAC , 50/60 Hz, Self-adjusting
Power Consumption 25 VA
Connections Terminal blocks
Fuse 5x20 mm cartridge - T2AL - 250V ANALYSIS
Number of Inputs 1
Measuring Range 0 – 299.99% saturation
Accuracy ± 1% full scale
Reproducibility ± 0.1% of range
Response Time (90 %) 0 – 95% full scale, <45 seconds
Ambient Temperature -20 – 60 °C (-4 … 140°F)
Relative Humidity 10 – 90% TRANSMITTER
1-2
Electrical Characteristics
Analysis
Model 14 Oxygen Analyzer
Display Display in concentration units or % saturation
Display of the direct cell current in nA
Display of the sample temperature in °C/°F
Programming via menus
Units nA, ppm-mg/l, °C, °F, % saturation
Calibration Electrical zero, chemical zero, slope calibration in the
air, slope process calibration by comparison with a
laboratory measurement
Analog Outputs 2 x 0/4 - 20 mA isolated from input signal, 800 ohms
load maximum
- Measurement or temperature
- Mode : linear, bi-linear
- Accuracy : 0.1 mA Alarms - Number : 4
- Functions : alarm - system alarm - timer
- Hysteresis : 0 - 10%
- Delay : 0 - 999 seconds
- Breaking power : 250 VAC, 3A maximum
30 VDC, 0.5A maximum
Temperature Compensation Automatic in the range of 0 - 80 °C
RS485 (option) Speed : 300 - 9600 bauds
Insulation : galvanic
Station number : 32 maximum
Transmitter Protection IP 65 and NEMA 4X
Error Reports Cell current > 999 nA
Sample temperature > 80 °C
Ambient temperature > 80 °C
Slope calibration error
Zero calibration error (offset)
Immunity Against Electromagnetic Interferences EN 50082-2 and EN 50082-1
Electromagnetic Emission EN 50081-1 and EN 50081-2
Low Voltage Standard IEC61010-1 MATERIALS
Working Electrode Cathode : platinum
Counter Electrode Anode : silver
Membrane Holder PPS & silicone
Membrane PTFE
Transmitter Epoxy coated aluminum
Probe Body Stainless steel 316L MAI
NTE
NANCE
Cleaning Clean the instrument with a soft tissue.
DO NOT use any aggressive agent.
1-3
Transmitter
Electromagnetic Compatibility
Materials
Maintenanace
Model 14 Oxygen Analyzer
1.5 Dimensions
(Dimensions are in mm and inches)
1-4
Esc Enter
33.5 mm
24 mm 0.936"
1.319"
24 mm 0.945" 28 mm 1.102" 73mm2 Pg13 2 Pg112.874"
117 mm 4.606" 144 mm 5.669"
144 mm 5.669"
Model 14 Oxygen Analyzer
Chapter2:
Description of the Analyzer
2.1 Transmitter
2.1.1 Presentation of the Transmitter
2-1
The electronic unit amplifies the signal of the amperometric measuring cell and converts it into a direct digital
readout in ppm, mg/l or % saturation. The transmitter is comprised of the following items:
■Potentiostat which maintains the working electrode potential constant
■Amperometric measuring module
■Analog multiplexer
■Microprocessor unit
The analog multiplexer allows measurement inputs from the measuring cell, temperature sensor and internal
checkpoints. Furthermore, the microprocessor operates the relays, the RS485 interface (optional) and the ana-
log outputs.
The unit has an internal concentration auto-ranging feature and a microprocessor-operated calibration routine.
The output of the potentiostat is monitored for possible overdriving of the potentiostat-output stage. This condi-
tion can occur when the connections to the measuring cell are due to an inoperable electrode or a defective ref-
erence electrode.
Model 14 Oxygen Analyzer
2-2
2.1.2 Transmitter Schematic:
1 : Programmable potentiostat 6 : Auxiliary input
2 : Polarization voltage amplifier 7 : Multiplexer
3 : Reversing switch for a 2 or 3 electrode 8 : A/D converter
operation.
4 : Temperature measurement circuit 9 : Microprocessor
5 : Measurement circuit current amplifier
REFERENCE
ANODE
TEMP +
TEMP -
CATHODE
AUX
49
875
6
2
1
3
U
Panel mounting
Panel cut-out: 138 mm x 138 mm (5.4” x 5.4”)
Front panel dimensions: 144 mm x 144 mm (5.7” x 5.7”)
Included hardware: 2 flat head screws, 4 mm x 18 mm long, for panels up to 6 mm thick
Model 14 Oxygen Analyzer
2.2 Application Fields
Easy to use, install and program, this instrument is suitable for the following applications:
- Fermentation / biotech
- Municipal
2.3 Standard Mounting Options (using the red clamping bow)
The transmitter housing conforms to norm DIN 43700.
2-3
Wall mounting
Included hardware: 2 pan head screws, 4 mm x 60 mm long for red clamping bow (a)
Additional required hardware: 2 flat head screws, 4 mm x 60 mm long (b)
Placed 3.15 “ (80 mm) on center
80 mm (3.15")
8 mm (0.315”) max.
285 mm (11.22”) max.
(a)
(b)
